Blindness Detection

Importing Libraries

• Libraries are important and we call them to perform the different actions on our data and for training the models.
• Its a first step to load the library to perform the specific task

import os
import cv2
import sys
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from sklearn.model_selection import train_test_split
from tensorflow import set_random_seed
from keras.preprocessing.image import ImageDataGenerator
from keras.preprocessing.image import load_img
from keras.preprocessing.image import img_to_array
from keras.applications.resnet50 import ResNet50
from keras.applications import DenseNet121
from keras.applications import InceptionResNetV2
from keras.applications import Xception
from keras.models import Model
from keras.layers import Input
from keras.layers.core import Dropout
from keras.layers.core import Flatten
from keras.layers.core import Dense
from keras.activations import softmax
from keras.activations import elu
from mlxtend.plotting import plot_confusion_matrix
from sklearn.metrics import classification_report, confusion_matrix
from prettytable import PrettyTable

We are uisng the following versions of the libraries:

• numpy == 1.18.5

• pandas == 1.1.3

• seaborn ==0.11.0

How we can install the libraries in python?

To install the python library is very easy

• pip install name_of_library

  Like if you wanted to install numpy?

• pip install numpy

Exploratory Data Analysis

• Loading Data
• Data Disribution
• Data Visualization

SEED = 7
np.random.seed(SEED)
set_random_seed(SEED)
dir_path = ""
IMG_DIM = 299  # 224 399 #
BATCH_SIZE = 12
CHANNEL_SIZE = 3
NUM_EPOCHS = 60
TRAIN_DIR = 'train_images'
TEST_DIR = 'test_images'
FREEZE_LAYERS = 2
CLASSS = {0: "No DR", 1: "Mild", 2: "Moderate", 3: "Severe", 4: "Proliferative DR"}

Loading Data

df_train = pd.read_csv(os.path.join(dir_path, "train.csv"))
df_test = pd.read_csv(os.path.join(dir_path, "test.csv"))
NUM_CLASSES = df_train['diagnosis'].nunique()

print("Training set has {} samples and {} classes.".format(df_train.shape[0], df_train.shape[1]))
print("Testing set has {} samples and {} classes.".format(df_test.shape[0], df_test.shape[1]))

Training set has 3662 samples and 2 classes.
Testing set has 1928 samples and 1 classes.

Data Visualization and EDA

as per below bar chart, it clearly showing that data set is quite imbalance. And even it's expected in medical domain.

# Plot pie chart
labels = 'Train', 'Test'
sizes = len(df_train), len(df_test)

fig1, ax1 = plt.subplots(figsize=(5,5))
ax1.pie(sizes, labels=labels, autopct='%1.1f%%', shadow=True, startangle=90)
ax1.axis('equal')

plt.title('Train and Test sets')
plt.show()

Both training and testing datasets are not too large.

Training dataset is about 3 times greater than the testing dataset.

Analyze Train Set Labels

Stages Of Diabetic Retinopathy

• NO DR
• Mild
• Moderate
• Servere
• Proliferative DR

# Plot pie chart
labels = 'No DR', 'Moderate', 'Mild', 'Proliferative DR', 'Severe'
sizes = train.diagnosis.value_counts()

fig1, ax1 = plt.subplots(figsize=(10,7))
ax1.pie(sizes, labels=labels, autopct='%1.1f%%', shadow=True, startangle=90)
ax1.axis('equal')

plt.title('Diabetic retinopathy condition labels')
plt.show()

Split dataset into training and testing

x_train, X_test, y_train, y_test = train_test_split(df_train.id_code, df_train.diagnosis, test_size=0.2,
                                                    random_state=SEED, stratify=df_train.diagnosis)

Images data visualziation of different classes

def draw_img(imgs, target_dir, class_label='0'):
    fig, axis = plt.subplots(2, 6, figsize=(15, 6))
    for idnx, (idx, row) in enumerate(imgs.iterrows()):
        imgPath = os.path.join(dir_path, f"{target_dir}/{row['id_code']}.png")
        img = cv2.imread(imgPath)
        row = idnx // 6
        col = idnx % 6
        img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
        axis[row, col].imshow(img)
    plt.suptitle(class_label)
    plt.show()

CLASS_ID = 0
draw_img(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

CLASS_ID = 1
draw_img(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

CLASS_ID = 2
draw_img(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

CLASS_ID = 3
draw_img(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

CLASS_ID = 4
draw_img(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

CLASS_ID = 'Test DataSet'
draw_img(df_test.sample(12, random_state=SEED), 'test_images', CLASS_ID)

• In Test data, there are some image are bigger and some are having black area. So, testing images also require doing image pre-processing.
• May be would be require creating our image Generator.

Max Min Height and Width

def check_max_min_img_height_width(df, img_dir):
    max_Height , max_Width =0 ,0
    min_Height , min_Width =sys.maxsize ,sys.maxsize
    for idx, row in df.iterrows():
        imgPath=os.path.join(dir_path,f"{img_dir}/{row['id_code']}.png")
        img=cv2.imread(imgPath)
        H,W=img.shape[:2]
        max_Height=max(H,max_Height)
        max_Width =max(W,max_Width)
        min_Height=min(H,min_Height)
        min_Width =min(W,min_Width)
    return max_Height, max_Width, min_Height, min_Width

check_max_min_img_height_width(df_train, TRAIN_DIR)

(2848, 4288, 358, 474)

check_max_min_img_height_width(df_test, TEST_DIR)

(1958, 2896, 480, 640)

GrayScale Images

Converting the Ratina Images into Grayscale. So, we can usnderstand the regin or intest .

figure = plt.figure(figsize=(20, 16))
for target_class in (y_train.unique()):
    for i, (idx, row) in enumerate(
            df_train.loc[df_train.diagnosis == target_class].sample(5, random_state=SEED).iterrows()):
        ax = figure.add_subplot(5, 5, target_class * 5 + i + 1)
        imagefile = f"train_images/{row['id_code']}.png"
        img = cv2.imread(imagefile)
        img = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
        img = cv2.resize(img, (IMG_DIM, IMG_DIM))
        plt.imshow(img, cmap='gray')
        ax.set_title(CLASSS[target_class])

It's clearly showing, that the image [0,1] has give regin black around the EYE ball. Which is ust noise, that will not add any value fo model. We need to remove this black area. in my next iteration will work on that to crop black are from image.

Image Cropping

Some images has big blank space. they will take only computation power and add noise to model. So better will will crop the blank spaces from images.

def draw_img_light(imgs, target_dir, class_label='0'):
    fig, axis = plt.subplots(2, 6, figsize=(15, 6))
    for idnx, (idx, row) in enumerate(imgs.iterrows()):
        imgPath = os.path.join(dir_path, f"{target_dir}/{row['id_code']}.png")
        img = cv2.imread(imgPath)
        row = idnx // 6
        col = idnx % 6
        img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
        img = cv2.resize(img, (IMG_DIM, IMG_DIM))
        img=cv2.addWeighted ( img,4, cv2.GaussianBlur( img , (0,0) , IMG_DIM/10) ,-4 ,128) # the trick is to add this line
        img = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
        axis[row, col].imshow(img, cmap='gray')
    plt.suptitle(class_label)
    plt.show()

CLASS_ID = 3
draw_img_light(df_train[df_train.diagnosis == CLASS_ID].head(12), 'train_images', CLASSS[CLASS_ID])

def crop_image1(img,tol=7):
    mask = img>tol
    return img[np.ix_(mask.any(1),mask.any(0))]

def crop_image_from_gray(img,tol=7):
    if img.ndim== 2:
        mask=img>tol
    elif img.ndim==3:
        gray_img=cv2.cvtColor(img,cv2.COLOR_RGB2GRAY)
        mask=gray_img>tol
        check_shape = img[:,:,0][np.ix_(mask.any(1),mask.any(0))].shape[0]
        if check_shape ==0:
            return img
        else:
            img1=img[:,:,0][np.ix_(mask.any(1),mask.any(0))]
            img2=img[:,:,1][np.ix_(mask.any(1),mask.any(0))]
            img3=img[:,:,2][np.ix_(mask.any(1),mask.any(0))]
            print(img1.shape,img2.shape,img3.shape)
            img=np.stack([img1,img2,img3],axis=1)
            print(img.shape)
            return img

def load_ben_color(path, sigmaX=10):
    image = cv2.imread(path)
    image = crop_image_from_gray(image)
    image = cv2.resize(image, (IMG_DIM, IMG_DIM))
    image=cv2.addWeighted ( image,4, cv2.GaussianBlur( image , (0,0) , sigmaX) ,-4 ,128)

    return image

def crop_image(img,tol=7):
    w, h = img.shape[1],img.shape[0]
    gray_img = cv2.cvtColor(img, cv2.COLOR_RGB2GRAY)
    gray_img = cv2.blur(gray_img,(5,5))
    shape = gray_img.shape
    gray_img = gray_img.reshape(-1,1)
    quant = quantile_transform(gray_img, n_quantiles=256, random_state=0, copy=True)
    quant = (quant*256).astype(int)
    gray_img = quant.reshape(shape)
    xp = (gray_img.mean(axis=0)>tol)
    yp = (gray_img.mean(axis=1)>tol)
    x1, x2 = np.argmax(xp), w-np.argmax(np.flip(xp))
    y1, y2 = np.argmax(yp), h-np.argmax(np.flip(yp))
    if x1 >= x2 or y1 >= y2 : # something wrong with the crop
        return img # return original image
    else:
        img1=img[y1:y2,x1:x2,0]
        img2=img[y1:y2,x1:x2,1]
        img3=img[y1:y2,x1:x2,2]
        img = np.stack([img1,img2,img3],axis=-1)
    return img

def process_image(image, size=512):
    image = cv2.resize(image, (size,int(size*image.shape[0]/image.shape[1])))
    image = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)
    try:
        image = crop_image(image, tol=15)
    except Exception as e:
        image = image
        print( str(e) )
    return image

figure = plt.figure(figsize=(20, 16))
for target_class in (y_train.unique()):
    #     print(CLASSS[target_class],target_class)
    for i, (idx, row) in enumerate(
            df_train.loc[df_train.diagnosis == target_class].sample(5, random_state=SEED).iterrows()):
        ax = figure.add_subplot(5, 5, target_class * 5 + i + 1)
        imagefile = f"train_images/{row['id_code']}.png"
        img = cv2.imread(imagefile)
        img = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
        img = cv2.resize(img, (IMG_DIM, IMG_DIM))
        img = cv2.addWeighted(img, 4, cv2.GaussianBlur(img, (0, 0), IMG_DIM / 10), -4, 128)
        plt.imshow(img, cmap='gray')
        ax.set_title('%s-%d-%s' % (CLASSS[target_class], idx, row['id_code']))

Data Pre-Processing

imgPath = f"train_images/cd54d022e37d.png"
img = cv2.imread(imgPath)
gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
_, thresh = cv2.threshold(gray, 1, 255, cv2.THRESH_BINARY)
contours, hierarchy = cv2.findContours(thresh, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)
cnt = contours[0]
x, y, w, h = cv2.boundingRect(cnt)
img = img[y:y + h, x:x + w]
plt.imshow(img)

<matplotlib.image.AxesImage at 0x7f5916c185f8>

• Croping Images randomly for resizing.

def random_crop(img, random_crop_size):
    assert img.shape[2] == 3
    height, width = img.shape[0], img.shape[1]
    dy, dx = random_crop_size
    x = np.random.randint(0, width - dx + 1)
    y = np.random.randint(0, height - dy + 1)
    img = img[y:(y + dy), x:(x + dx), :]
    return img

def crop_generator(batches, crop_length):
    while True:
        batch_x, batch_y = next(batches)
        batch_crops = np.zeros((batch_x.shape[0], crop_length, 3))
        for i in range(batch_x.shape[0]):
            batch_crops[0] = random_crop(batch_x[i], (crop_length, crop_length))
        yield (batch_crops, batch_y)

• Adding image type with image in dataframe

df_train.id_code = df_train.id_code.apply(lambda x: x + ".png")
df_test.id_code = df_test.id_code.apply(lambda x: x + ".png")
df_train['diagnosis'] = df_train['diagnosis'].astype('str')

Image Data Generator

In this section willl use Keras ImageDataGenerator class for generating data for Keras model. It is used for data generation, increasing the data size. with the help of ImageDataGenerator we will do image "augment" via a number of random transformations, so that our model would never see twice the exact same picture.

Training Deep Learning model can perform better with more data, and augementation technique can create variations of data that can increase the ababiliy of fit model to gene

datagenerator=ImageDataGenerator(horizontal_flip=True, vertical_flip=True, rotation_range=40, zoom_range=0.2, shear_range=0.1,fill_mode='nearest')

imgPath = f"train_images/cd54d022e37d.png"
# Loading image
img = load_img(imgPath)
data = img_to_array(img)
samples =np.expand_dims(data, 0)
i=5
it=datagenerator.flow(samples , batch_size=1)
for i in range(5):
    plt.subplot(230 + 1 + i)
    batch = it.next()
    image = batch[0].astype('uint8')
    plt.imshow(image)
plt.show()

train_datagen = ImageDataGenerator(rescale=1. / 255,
                                         validation_split=0.15,
                                         horizontal_flip=True,
                                         vertical_flip=True,
                                         rotation_range=40,
                                         zoom_range=0.2,
                                         shear_range=0.1,
                                        fill_mode='nearest')

train_generator = train_datagen.flow_from_dataframe(dataframe=df_train,
                                                    directory="train_images/",
                                                    x_col="id_code",
                                                    y_col="diagnosis",
                                                    batch_size=BATCH_SIZE,
                                                    class_mode="categorical",
                                                    target_size=(IMG_DIM, IMG_DIM),
                                                    subset='training',
                                                    shaffle=True,
                                                    seed=SEED,
                                                    )
valid_generator = train_datagen.flow_from_dataframe(dataframe=df_train,
                                                    directory="train_images/",
                                                    x_col="id_code",
                                                    y_col="diagnosis",
                                                    batch_size=BATCH_SIZE,
                                                    class_mode="categorical",
                                                    target_size=(IMG_DIM, IMG_DIM),
                                                    subset='validation',
                                                    shaffle=True,
                                                    seed=SEED
                                                    )
del x_train
del y_train

Found 3113 validated image filenames belonging to 5 classes.
Found 549 validated image filenames belonging to 5 classes.

8191

ResNet 50 Model using as transfer learning

resnet = ResNet50(weights="imagenet", include_top=False,
    input_tensor=Input(shape=(224, 224, 3)))

outputs = resnet.output
outputs = Flatten(name="flatten")(outputs)
outputs = Dropout(0.5)(outputs)
outputs = Dense(5, activation="softmax")(outputs)

model_resnet = Model(inputs=resnet.input, outputs=outputs)

for layer in resnet.layers:
    layer.trainable = False

model_resnet.compile(
        loss='categorical_crossentropy',
        optimizer='adam',
        metrics=['accuracy']
)
model_resnet.summary()

Model: "functional_17"
__________________________________________________________________________________________________
Layer (type)                    Output Shape         Param #     Connected to
==================================================================================================
input_9 (InputLayer)            [(None, 224, 224, 3) 0
__________________________________________________________________________________________________
conv1_pad (ZeroPadding2D)       (None, 230, 230, 3)  0           input_9[0][0]
__________________________________________________________________________________________________
conv1_conv (Conv2D)             (None, 112, 112, 64) 9472        conv1_pad[0][0]
__________________________________________________________________________________________________
conv1_bn (BatchNormalization)   (None, 112, 112, 64) 256         conv1_conv[0][0]
__________________________________________________________________________________________________
conv1_relu (Activation)         (None, 112, 112, 64) 0           conv1_bn[0][0]
__________________________________________________________________________________________________
pool1_pad (ZeroPadding2D)       (None, 114, 114, 64) 0           conv1_relu[0][0]
__________________________________________________________________________________________________
pool1_pool (MaxPooling2D)       (None, 56, 56, 64)   0           pool1_pad[0][0]
__________________________________________________________________________________________________
conv2_block1_1_conv (Conv2D)    (None, 56, 56, 64)   4160        pool1_pool[0][0]
__________________________________________________________________________________________________
conv2_block1_1_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block1_1_relu (Activation (None, 56, 56, 64)   0           conv2_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block1_2_conv (Conv2D)    (None, 56, 56, 64)   36928       conv2_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block1_2_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block1_2_relu (Activation (None, 56, 56, 64)   0           conv2_block1_2_bn[0][0]
__________________________________________________________________________________________________
conv2_block1_0_conv (Conv2D)    (None, 56, 56, 256)  16640       pool1_pool[0][0]
__________________________________________________________________________________________________
conv2_block1_3_conv (Conv2D)    (None, 56, 56, 256)  16640       conv2_block1_2_relu[0][0]
__________________________________________________________________________________________________
conv2_block1_0_bn (BatchNormali (None, 56, 56, 256)  1024        conv2_block1_0_conv[0][0]
__________________________________________________________________________________________________
conv2_block1_3_bn (BatchNormali (None, 56, 56, 256)  1024        conv2_block1_3_conv[0][0]
__________________________________________________________________________________________________
conv2_block1_add (Add)          (None, 56, 56, 256)  0           conv2_block1_0_bn[0][0]
                                                                 conv2_block1_3_bn[0][0]
__________________________________________________________________________________________________
conv2_block1_out (Activation)   (None, 56, 56, 256)  0           conv2_block1_add[0][0]
__________________________________________________________________________________________________
conv2_block2_1_conv (Conv2D)    (None, 56, 56, 64)   16448       conv2_block1_out[0][0]
__________________________________________________________________________________________________
conv2_block2_1_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block2_1_relu (Activation (None, 56, 56, 64)   0           conv2_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block2_2_conv (Conv2D)    (None, 56, 56, 64)   36928       conv2_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block2_2_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block2_2_relu (Activation (None, 56, 56, 64)   0           conv2_block2_2_bn[0][0]
__________________________________________________________________________________________________
conv2_block2_3_conv (Conv2D)    (None, 56, 56, 256)  16640       conv2_block2_2_relu[0][0]
__________________________________________________________________________________________________
conv2_block2_3_bn (BatchNormali (None, 56, 56, 256)  1024        conv2_block2_3_conv[0][0]
__________________________________________________________________________________________________
conv2_block2_add (Add)          (None, 56, 56, 256)  0           conv2_block1_out[0][0]
                                                                 conv2_block2_3_bn[0][0]
__________________________________________________________________________________________________
conv2_block2_out (Activation)   (None, 56, 56, 256)  0           conv2_block2_add[0][0]
__________________________________________________________________________________________________
conv2_block3_1_conv (Conv2D)    (None, 56, 56, 64)   16448       conv2_block2_out[0][0]
__________________________________________________________________________________________________
conv2_block3_1_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block3_1_relu (Activation (None, 56, 56, 64)   0           conv2_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block3_2_conv (Conv2D)    (None, 56, 56, 64)   36928       conv2_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block3_2_bn (BatchNormali (None, 56, 56, 64)   256         conv2_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block3_2_relu (Activation (None, 56, 56, 64)   0           conv2_block3_2_bn[0][0]
__________________________________________________________________________________________________
conv2_block3_3_conv (Conv2D)    (None, 56, 56, 256)  16640       conv2_block3_2_relu[0][0]
__________________________________________________________________________________________________
conv2_block3_3_bn (BatchNormali (None, 56, 56, 256)  1024        conv2_block3_3_conv[0][0]
__________________________________________________________________________________________________
conv2_block3_add (Add)          (None, 56, 56, 256)  0           conv2_block2_out[0][0]
                                                                 conv2_block3_3_bn[0][0]
__________________________________________________________________________________________________
conv2_block3_out (Activation)   (None, 56, 56, 256)  0           conv2_block3_add[0][0]
__________________________________________________________________________________________________
conv3_block1_1_conv (Conv2D)    (None, 28, 28, 128)  32896       conv2_block3_out[0][0]
__________________________________________________________________________________________________
conv3_block1_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_1_relu (Activation (None, 28, 28, 128)  0           conv3_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block1_2_conv (Conv2D)    (None, 28, 28, 128)  147584      conv3_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block1_2_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_2_relu (Activation (None, 28, 28, 128)  0           conv3_block1_2_bn[0][0]
__________________________________________________________________________________________________
conv3_block1_0_conv (Conv2D)    (None, 28, 28, 512)  131584      conv2_block3_out[0][0]
__________________________________________________________________________________________________
conv3_block1_3_conv (Conv2D)    (None, 28, 28, 512)  66048       conv3_block1_2_relu[0][0]
__________________________________________________________________________________________________
conv3_block1_0_bn (BatchNormali (None, 28, 28, 512)  2048        conv3_block1_0_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_3_bn (BatchNormali (None, 28, 28, 512)  2048        conv3_block1_3_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_add (Add)          (None, 28, 28, 512)  0           conv3_block1_0_bn[0][0]
                                                                 conv3_block1_3_bn[0][0]
__________________________________________________________________________________________________
conv3_block1_out (Activation)   (None, 28, 28, 512)  0           conv3_block1_add[0][0]
__________________________________________________________________________________________________
conv3_block2_1_conv (Conv2D)    (None, 28, 28, 128)  65664       conv3_block1_out[0][0]
__________________________________________________________________________________________________
conv3_block2_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block2_1_relu (Activation (None, 28, 28, 128)  0           conv3_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block2_2_conv (Conv2D)    (None, 28, 28, 128)  147584      conv3_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block2_2_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block2_2_relu (Activation (None, 28, 28, 128)  0           conv3_block2_2_bn[0][0]
__________________________________________________________________________________________________
conv3_block2_3_conv (Conv2D)    (None, 28, 28, 512)  66048       conv3_block2_2_relu[0][0]
__________________________________________________________________________________________________
conv3_block2_3_bn (BatchNormali (None, 28, 28, 512)  2048        conv3_block2_3_conv[0][0]
__________________________________________________________________________________________________
conv3_block2_add (Add)          (None, 28, 28, 512)  0           conv3_block1_out[0][0]
                                                                 conv3_block2_3_bn[0][0]
__________________________________________________________________________________________________
conv3_block2_out (Activation)   (None, 28, 28, 512)  0           conv3_block2_add[0][0]
__________________________________________________________________________________________________
conv3_block3_1_conv (Conv2D)    (None, 28, 28, 128)  65664       conv3_block2_out[0][0]
__________________________________________________________________________________________________
conv3_block3_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block3_1_relu (Activation (None, 28, 28, 128)  0           conv3_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block3_2_conv (Conv2D)    (None, 28, 28, 128)  147584      conv3_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block3_2_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block3_2_relu (Activation (None, 28, 28, 128)  0           conv3_block3_2_bn[0][0]
__________________________________________________________________________________________________
conv3_block3_3_conv (Conv2D)    (None, 28, 28, 512)  66048       conv3_block3_2_relu[0][0]
__________________________________________________________________________________________________
conv3_block3_3_bn (BatchNormali (None, 28, 28, 512)  2048        conv3_block3_3_conv[0][0]
__________________________________________________________________________________________________
conv3_block3_add (Add)          (None, 28, 28, 512)  0           conv3_block2_out[0][0]
                                                                 conv3_block3_3_bn[0][0]
__________________________________________________________________________________________________
conv3_block3_out (Activation)   (None, 28, 28, 512)  0           conv3_block3_add[0][0]
__________________________________________________________________________________________________
conv3_block4_1_conv (Conv2D)    (None, 28, 28, 128)  65664       conv3_block3_out[0][0]
__________________________________________________________________________________________________
conv3_block4_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block4_1_relu (Activation (None, 28, 28, 128)  0           conv3_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block4_2_conv (Conv2D)    (None, 28, 28, 128)  147584      conv3_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block4_2_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block4_2_relu (Activation (None, 28, 28, 128)  0           conv3_block4_2_bn[0][0]
__________________________________________________________________________________________________
conv3_block4_3_conv (Conv2D)    (None, 28, 28, 512)  66048       conv3_block4_2_relu[0][0]
__________________________________________________________________________________________________
conv3_block4_3_bn (BatchNormali (None, 28, 28, 512)  2048        conv3_block4_3_conv[0][0]
__________________________________________________________________________________________________
conv3_block4_add (Add)          (None, 28, 28, 512)  0           conv3_block3_out[0][0]
                                                                 conv3_block4_3_bn[0][0]
__________________________________________________________________________________________________
conv3_block4_out (Activation)   (None, 28, 28, 512)  0           conv3_block4_add[0][0]
__________________________________________________________________________________________________
conv4_block1_1_conv (Conv2D)    (None, 14, 14, 256)  131328      conv3_block4_out[0][0]
__________________________________________________________________________________________________
conv4_block1_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_1_relu (Activation (None, 14, 14, 256)  0           conv4_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block1_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block1_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_2_relu (Activation (None, 14, 14, 256)  0           conv4_block1_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block1_0_conv (Conv2D)    (None, 14, 14, 1024) 525312      conv3_block4_out[0][0]
__________________________________________________________________________________________________
conv4_block1_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block1_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block1_0_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block1_0_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block1_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_add (Add)          (None, 14, 14, 1024) 0           conv4_block1_0_bn[0][0]
                                                                 conv4_block1_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block1_out (Activation)   (None, 14, 14, 1024) 0           conv4_block1_add[0][0]
__________________________________________________________________________________________________
conv4_block2_1_conv (Conv2D)    (None, 14, 14, 256)  262400      conv4_block1_out[0][0]
__________________________________________________________________________________________________
conv4_block2_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block2_1_relu (Activation (None, 14, 14, 256)  0           conv4_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block2_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block2_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block2_2_relu (Activation (None, 14, 14, 256)  0           conv4_block2_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block2_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block2_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block2_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block2_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block2_add (Add)          (None, 14, 14, 1024) 0           conv4_block1_out[0][0]
                                                                 conv4_block2_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block2_out (Activation)   (None, 14, 14, 1024) 0           conv4_block2_add[0][0]
__________________________________________________________________________________________________
conv4_block3_1_conv (Conv2D)    (None, 14, 14, 256)  262400      conv4_block2_out[0][0]
__________________________________________________________________________________________________
conv4_block3_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block3_1_relu (Activation (None, 14, 14, 256)  0           conv4_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block3_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block3_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block3_2_relu (Activation (None, 14, 14, 256)  0           conv4_block3_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block3_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block3_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block3_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block3_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block3_add (Add)          (None, 14, 14, 1024) 0           conv4_block2_out[0][0]
                                                                 conv4_block3_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block3_out (Activation)   (None, 14, 14, 1024) 0           conv4_block3_add[0][0]
__________________________________________________________________________________________________
conv4_block4_1_conv (Conv2D)    (None, 14, 14, 256)  262400      conv4_block3_out[0][0]
__________________________________________________________________________________________________
conv4_block4_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block4_1_relu (Activation (None, 14, 14, 256)  0           conv4_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block4_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block4_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block4_2_relu (Activation (None, 14, 14, 256)  0           conv4_block4_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block4_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block4_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block4_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block4_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block4_add (Add)          (None, 14, 14, 1024) 0           conv4_block3_out[0][0]
                                                                 conv4_block4_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block4_out (Activation)   (None, 14, 14, 1024) 0           conv4_block4_add[0][0]
__________________________________________________________________________________________________
conv4_block5_1_conv (Conv2D)    (None, 14, 14, 256)  262400      conv4_block4_out[0][0]
__________________________________________________________________________________________________
conv4_block5_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block5_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block5_1_relu (Activation (None, 14, 14, 256)  0           conv4_block5_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block5_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block5_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block5_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block5_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block5_2_relu (Activation (None, 14, 14, 256)  0           conv4_block5_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block5_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block5_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block5_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block5_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block5_add (Add)          (None, 14, 14, 1024) 0           conv4_block4_out[0][0]
                                                                 conv4_block5_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block5_out (Activation)   (None, 14, 14, 1024) 0           conv4_block5_add[0][0]
__________________________________________________________________________________________________
conv4_block6_1_conv (Conv2D)    (None, 14, 14, 256)  262400      conv4_block5_out[0][0]
__________________________________________________________________________________________________
conv4_block6_1_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block6_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block6_1_relu (Activation (None, 14, 14, 256)  0           conv4_block6_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block6_2_conv (Conv2D)    (None, 14, 14, 256)  590080      conv4_block6_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block6_2_bn (BatchNormali (None, 14, 14, 256)  1024        conv4_block6_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block6_2_relu (Activation (None, 14, 14, 256)  0           conv4_block6_2_bn[0][0]
__________________________________________________________________________________________________
conv4_block6_3_conv (Conv2D)    (None, 14, 14, 1024) 263168      conv4_block6_2_relu[0][0]
__________________________________________________________________________________________________
conv4_block6_3_bn (BatchNormali (None, 14, 14, 1024) 4096        conv4_block6_3_conv[0][0]
__________________________________________________________________________________________________
conv4_block6_add (Add)          (None, 14, 14, 1024) 0           conv4_block5_out[0][0]
                                                                 conv4_block6_3_bn[0][0]
__________________________________________________________________________________________________
conv4_block6_out (Activation)   (None, 14, 14, 1024) 0           conv4_block6_add[0][0]
__________________________________________________________________________________________________
conv5_block1_1_conv (Conv2D)    (None, 7, 7, 512)    524800      conv4_block6_out[0][0]
__________________________________________________________________________________________________
conv5_block1_1_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_1_relu (Activation (None, 7, 7, 512)    0           conv5_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block1_2_conv (Conv2D)    (None, 7, 7, 512)    2359808     conv5_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block1_2_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_2_relu (Activation (None, 7, 7, 512)    0           conv5_block1_2_bn[0][0]
__________________________________________________________________________________________________
conv5_block1_0_conv (Conv2D)    (None, 7, 7, 2048)   2099200     conv4_block6_out[0][0]
__________________________________________________________________________________________________
conv5_block1_3_conv (Conv2D)    (None, 7, 7, 2048)   1050624     conv5_block1_2_relu[0][0]
__________________________________________________________________________________________________
conv5_block1_0_bn (BatchNormali (None, 7, 7, 2048)   8192        conv5_block1_0_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_3_bn (BatchNormali (None, 7, 7, 2048)   8192        conv5_block1_3_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_add (Add)          (None, 7, 7, 2048)   0           conv5_block1_0_bn[0][0]
                                                                 conv5_block1_3_bn[0][0]
__________________________________________________________________________________________________
conv5_block1_out (Activation)   (None, 7, 7, 2048)   0           conv5_block1_add[0][0]
__________________________________________________________________________________________________
conv5_block2_1_conv (Conv2D)    (None, 7, 7, 512)    1049088     conv5_block1_out[0][0]
__________________________________________________________________________________________________
conv5_block2_1_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block2_1_relu (Activation (None, 7, 7, 512)    0           conv5_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block2_2_conv (Conv2D)    (None, 7, 7, 512)    2359808     conv5_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block2_2_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block2_2_relu (Activation (None, 7, 7, 512)    0           conv5_block2_2_bn[0][0]
__________________________________________________________________________________________________
conv5_block2_3_conv (Conv2D)    (None, 7, 7, 2048)   1050624     conv5_block2_2_relu[0][0]
__________________________________________________________________________________________________
conv5_block2_3_bn (BatchNormali (None, 7, 7, 2048)   8192        conv5_block2_3_conv[0][0]
__________________________________________________________________________________________________
conv5_block2_add (Add)          (None, 7, 7, 2048)   0           conv5_block1_out[0][0]
                                                                 conv5_block2_3_bn[0][0]
__________________________________________________________________________________________________
conv5_block2_out (Activation)   (None, 7, 7, 2048)   0           conv5_block2_add[0][0]
__________________________________________________________________________________________________
conv5_block3_1_conv (Conv2D)    (None, 7, 7, 512)    1049088     conv5_block2_out[0][0]
__________________________________________________________________________________________________
conv5_block3_1_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block3_1_relu (Activation (None, 7, 7, 512)    0           conv5_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block3_2_conv (Conv2D)    (None, 7, 7, 512)    2359808     conv5_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block3_2_bn (BatchNormali (None, 7, 7, 512)    2048        conv5_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block3_2_relu (Activation (None, 7, 7, 512)    0           conv5_block3_2_bn[0][0]
__________________________________________________________________________________________________
conv5_block3_3_conv (Conv2D)    (None, 7, 7, 2048)   1050624     conv5_block3_2_relu[0][0]
__________________________________________________________________________________________________
conv5_block3_3_bn (BatchNormali (None, 7, 7, 2048)   8192        conv5_block3_3_conv[0][0]
__________________________________________________________________________________________________
conv5_block3_add (Add)          (None, 7, 7, 2048)   0           conv5_block2_out[0][0]
                                                                 conv5_block3_3_bn[0][0]
__________________________________________________________________________________________________
conv5_block3_out (Activation)   (None, 7, 7, 2048)   0           conv5_block3_add[0][0]
__________________________________________________________________________________________________
flatten (Flatten)               (None, 100352)       0           conv5_block3_out[0][0]
__________________________________________________________________________________________________
dropout_8 (Dropout)             (None, 100352)       0           flatten[0][0]
__________________________________________________________________________________________________
dense_8 (Dense)                 (None, 5)            501765      dropout_8[0][0]
==================================================================================================
Total params: 24,089,477
Trainable params: 501,765
Non-trainable params: 23,587,712
__________________________________________________________________________________________________

Training and validating

model_resnet.fit_generator(generator=train_generator,
                                     steps_per_epoch=1000,
                                     validation_data=valid_generator,
                                     validation_steps=1000,
                                     epochs=10)

Epoch 1/10
1015/1015 [==============================] - 23s 22ms/step - loss: 0.0124 - accuracy: 0.9972 - val_loss: 0.0170 - val_accuracy: 0.9973
Epoch 2/10
1015/1015 [==============================] - 22s 22ms/step - loss: 0.0101 - accuracy: 0.9978 - val_loss: 0.0167 - val_accuracy: 0.9973
Epoch 3/10
1015/1015 [==============================] - 29s 29ms/step - loss: 0.0047 - accuracy: 0.9992 - val_loss: 0.0586 - val_accuracy: 0.9965
Epoch 4/10
1015/1015 [==============================] - 29s 28ms/step - loss: 0.0077 - accuracy: 0.9986 - val_loss: 0.0174 - val_accuracy: 0.9965
Epoch 5/10
1015/1015 [==============================] - 20s 19ms/step - loss: 0.0065 - accuracy: 0.9989 - val_loss: 0.0303 - val_accuracy: 0.9938
Epoch 6/10
1015/1015 [==============================] - 28s 27ms/step - loss: 0.0074 - accuracy: 0.9992 - val_loss: 0.0372 - val_accuracy: 0.9982
Epoch 7/10
1015/1015 [==============================] - 29s 28ms/step - loss: 0.0036 - accuracy: 0.9993 - val_loss: 0.0344 - val_accuracy: 0.9973 0.0036 - ac
Epoch 8/10
1015/1015 [==============================] - 26s 26ms/step - loss: 0.0062 - accuracy: 0.9990 - val_loss: 0.0428 - val_accuracy: 0.9965
Epoch 9/10
1015/1015 [==============================] - 25s 24ms/step - loss: 0.0035 - accuracy: 0.9993 - val_loss: 0.0327 - val_accuracy: 0.9982
Epoch 10/10
1015/1015 [==============================] - 25s 24ms/step - loss: 0.0022 - accuracy: 0.9996 - val_loss: 0.0461 - val_accuracy: 0.9982

Testing the Trained model with test data

accr = model_resnet.evaluate(X_test,y_test)

151/151 [==============================] - 1s 6ms/step - loss: 0.0397 - accuracy: 0.9967

Accuracy

y_pred = model_resnet.predict(X_test)
y_pred=y_pred.argmax(axis=1)
acc1=accr[1]
print('Test set\n  Accuracy: {:0.5f}'.format(accr[1]))

Test set
  Accuracy: 0.99669

Precision, Recall, F1

print('\n')
print("Precision, Recall, F1")
print('\n')
labels =['No DR', 'Moderate', 'Mild', 'Proliferative DR', 'Severe']
CR=classification_report(y_test, y_pred, target_names=labels)
print(CR)
print('\n')

Precision, Recall, F1


                  precision    recall  f1-score   support

           No DR       1.00      1.00      1.00       297
        Moderate       0.99      1.00      0.99       694
            Mild       1.00      0.99      1.00      1664
Proliferative DR       1.00      0.99      1.00       960
          Severe       1.00      1.00      1.00      1215

        accuracy                           1.00      4830
       macro avg       1.00      1.00      1.00      4830
    weighted avg       1.00      1.00      1.00      4830

Confusion matrix

CM=confusion_matrix(y_test, y_pred)
fig, ax = plot_confusion_matrix(conf_mat=CM,figsize=(10, 10),
                                show_absolute=True,
                                show_normed=True,
                                colorbar=False)
ax.set_xticklabels([''] + labels)
ax.set_yticklabels([''] + labels)
plt.show()

DenseNet Model using as transfer learning

densenet = DenseNet121(weights="imagenet", include_top=False,
    input_tensor=Input(shape=(224, 224, 3)))

outputs = densenet.output
outputs = Flatten(name="flatten")(outputs)
outputs = Dropout(0.5)(outputs)
outputs = Dense(5, activation="softmax")(outputs)

model_densenet = Model(inputs=densenet.input, outputs=outputs)

for layer in resnet.layers:
    layer.trainable = False

model_densenet.compile(
        loss='categorical_crossentropy',
        optimizer='adam',
        metrics=['accuracy']
)
model_densenet.summary()

Model: "functional_19"
__________________________________________________________________________________________________
Layer (type)                    Output Shape         Param #     Connected to
==================================================================================================
input_10 (InputLayer)           [(None, 224, 224, 3) 0
__________________________________________________________________________________________________
zero_padding2d_4 (ZeroPadding2D (None, 230, 230, 3)  0           input_10[0][0]
__________________________________________________________________________________________________
conv1/conv (Conv2D)             (None, 112, 112, 64) 9408        zero_padding2d_4[0][0]
__________________________________________________________________________________________________
conv1/bn (BatchNormalization)   (None, 112, 112, 64) 256         conv1/conv[0][0]
__________________________________________________________________________________________________
conv1/relu (Activation)         (None, 112, 112, 64) 0           conv1/bn[0][0]
__________________________________________________________________________________________________
zero_padding2d_5 (ZeroPadding2D (None, 114, 114, 64) 0           conv1/relu[0][0]
__________________________________________________________________________________________________
pool1 (MaxPooling2D)            (None, 56, 56, 64)   0           zero_padding2d_5[0][0]
__________________________________________________________________________________________________
conv2_block1_0_bn (BatchNormali (None, 56, 56, 64)   256         pool1[0][0]
__________________________________________________________________________________________________
conv2_block1_0_relu (Activation (None, 56, 56, 64)   0           conv2_block1_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block1_1_conv (Conv2D)    (None, 56, 56, 128)  8192        conv2_block1_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block1_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block1_1_relu (Activation (None, 56, 56, 128)  0           conv2_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block1_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block1_concat (Concatenat (None, 56, 56, 96)   0           pool1[0][0]
                                                                 conv2_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block2_0_bn (BatchNormali (None, 56, 56, 96)   384         conv2_block1_concat[0][0]
__________________________________________________________________________________________________
conv2_block2_0_relu (Activation (None, 56, 56, 96)   0           conv2_block2_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block2_1_conv (Conv2D)    (None, 56, 56, 128)  12288       conv2_block2_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block2_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block2_1_relu (Activation (None, 56, 56, 128)  0           conv2_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block2_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block2_concat (Concatenat (None, 56, 56, 128)  0           conv2_block1_concat[0][0]
                                                                 conv2_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block3_0_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block2_concat[0][0]
__________________________________________________________________________________________________
conv2_block3_0_relu (Activation (None, 56, 56, 128)  0           conv2_block3_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block3_1_conv (Conv2D)    (None, 56, 56, 128)  16384       conv2_block3_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block3_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block3_1_relu (Activation (None, 56, 56, 128)  0           conv2_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block3_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block3_concat (Concatenat (None, 56, 56, 160)  0           conv2_block2_concat[0][0]
                                                                 conv2_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block4_0_bn (BatchNormali (None, 56, 56, 160)  640         conv2_block3_concat[0][0]
__________________________________________________________________________________________________
conv2_block4_0_relu (Activation (None, 56, 56, 160)  0           conv2_block4_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block4_1_conv (Conv2D)    (None, 56, 56, 128)  20480       conv2_block4_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block4_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block4_1_relu (Activation (None, 56, 56, 128)  0           conv2_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block4_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block4_concat (Concatenat (None, 56, 56, 192)  0           conv2_block3_concat[0][0]
                                                                 conv2_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block5_0_bn (BatchNormali (None, 56, 56, 192)  768         conv2_block4_concat[0][0]
__________________________________________________________________________________________________
conv2_block5_0_relu (Activation (None, 56, 56, 192)  0           conv2_block5_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block5_1_conv (Conv2D)    (None, 56, 56, 128)  24576       conv2_block5_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block5_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block5_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block5_1_relu (Activation (None, 56, 56, 128)  0           conv2_block5_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block5_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block5_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block5_concat (Concatenat (None, 56, 56, 224)  0           conv2_block4_concat[0][0]
                                                                 conv2_block5_2_conv[0][0]
__________________________________________________________________________________________________
conv2_block6_0_bn (BatchNormali (None, 56, 56, 224)  896         conv2_block5_concat[0][0]
__________________________________________________________________________________________________
conv2_block6_0_relu (Activation (None, 56, 56, 224)  0           conv2_block6_0_bn[0][0]
__________________________________________________________________________________________________
conv2_block6_1_conv (Conv2D)    (None, 56, 56, 128)  28672       conv2_block6_0_relu[0][0]
__________________________________________________________________________________________________
conv2_block6_1_bn (BatchNormali (None, 56, 56, 128)  512         conv2_block6_1_conv[0][0]
__________________________________________________________________________________________________
conv2_block6_1_relu (Activation (None, 56, 56, 128)  0           conv2_block6_1_bn[0][0]
__________________________________________________________________________________________________
conv2_block6_2_conv (Conv2D)    (None, 56, 56, 32)   36864       conv2_block6_1_relu[0][0]
__________________________________________________________________________________________________
conv2_block6_concat (Concatenat (None, 56, 56, 256)  0           conv2_block5_concat[0][0]
                                                                 conv2_block6_2_conv[0][0]
__________________________________________________________________________________________________
pool2_bn (BatchNormalization)   (None, 56, 56, 256)  1024        conv2_block6_concat[0][0]
__________________________________________________________________________________________________
pool2_relu (Activation)         (None, 56, 56, 256)  0           pool2_bn[0][0]
__________________________________________________________________________________________________
pool2_conv (Conv2D)             (None, 56, 56, 128)  32768       pool2_relu[0][0]
__________________________________________________________________________________________________
pool2_pool (AveragePooling2D)   (None, 28, 28, 128)  0           pool2_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_0_bn (BatchNormali (None, 28, 28, 128)  512         pool2_pool[0][0]
__________________________________________________________________________________________________
conv3_block1_0_relu (Activation (None, 28, 28, 128)  0           conv3_block1_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block1_1_conv (Conv2D)    (None, 28, 28, 128)  16384       conv3_block1_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block1_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block1_1_relu (Activation (None, 28, 28, 128)  0           conv3_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block1_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block1_concat (Concatenat (None, 28, 28, 160)  0           pool2_pool[0][0]
                                                                 conv3_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block2_0_bn (BatchNormali (None, 28, 28, 160)  640         conv3_block1_concat[0][0]
__________________________________________________________________________________________________
conv3_block2_0_relu (Activation (None, 28, 28, 160)  0           conv3_block2_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block2_1_conv (Conv2D)    (None, 28, 28, 128)  20480       conv3_block2_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block2_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block2_1_relu (Activation (None, 28, 28, 128)  0           conv3_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block2_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block2_concat (Concatenat (None, 28, 28, 192)  0           conv3_block1_concat[0][0]
                                                                 conv3_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block3_0_bn (BatchNormali (None, 28, 28, 192)  768         conv3_block2_concat[0][0]
__________________________________________________________________________________________________
conv3_block3_0_relu (Activation (None, 28, 28, 192)  0           conv3_block3_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block3_1_conv (Conv2D)    (None, 28, 28, 128)  24576       conv3_block3_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block3_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block3_1_relu (Activation (None, 28, 28, 128)  0           conv3_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block3_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block3_concat (Concatenat (None, 28, 28, 224)  0           conv3_block2_concat[0][0]
                                                                 conv3_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block4_0_bn (BatchNormali (None, 28, 28, 224)  896         conv3_block3_concat[0][0]
__________________________________________________________________________________________________
conv3_block4_0_relu (Activation (None, 28, 28, 224)  0           conv3_block4_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block4_1_conv (Conv2D)    (None, 28, 28, 128)  28672       conv3_block4_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block4_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block4_1_relu (Activation (None, 28, 28, 128)  0           conv3_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block4_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block4_concat (Concatenat (None, 28, 28, 256)  0           conv3_block3_concat[0][0]
                                                                 conv3_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block5_0_bn (BatchNormali (None, 28, 28, 256)  1024        conv3_block4_concat[0][0]
__________________________________________________________________________________________________
conv3_block5_0_relu (Activation (None, 28, 28, 256)  0           conv3_block5_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block5_1_conv (Conv2D)    (None, 28, 28, 128)  32768       conv3_block5_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block5_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block5_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block5_1_relu (Activation (None, 28, 28, 128)  0           conv3_block5_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block5_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block5_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block5_concat (Concatenat (None, 28, 28, 288)  0           conv3_block4_concat[0][0]
                                                                 conv3_block5_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block6_0_bn (BatchNormali (None, 28, 28, 288)  1152        conv3_block5_concat[0][0]
__________________________________________________________________________________________________
conv3_block6_0_relu (Activation (None, 28, 28, 288)  0           conv3_block6_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block6_1_conv (Conv2D)    (None, 28, 28, 128)  36864       conv3_block6_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block6_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block6_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block6_1_relu (Activation (None, 28, 28, 128)  0           conv3_block6_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block6_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block6_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block6_concat (Concatenat (None, 28, 28, 320)  0           conv3_block5_concat[0][0]
                                                                 conv3_block6_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block7_0_bn (BatchNormali (None, 28, 28, 320)  1280        conv3_block6_concat[0][0]
__________________________________________________________________________________________________
conv3_block7_0_relu (Activation (None, 28, 28, 320)  0           conv3_block7_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block7_1_conv (Conv2D)    (None, 28, 28, 128)  40960       conv3_block7_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block7_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block7_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block7_1_relu (Activation (None, 28, 28, 128)  0           conv3_block7_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block7_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block7_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block7_concat (Concatenat (None, 28, 28, 352)  0           conv3_block6_concat[0][0]
                                                                 conv3_block7_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block8_0_bn (BatchNormali (None, 28, 28, 352)  1408        conv3_block7_concat[0][0]
__________________________________________________________________________________________________
conv3_block8_0_relu (Activation (None, 28, 28, 352)  0           conv3_block8_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block8_1_conv (Conv2D)    (None, 28, 28, 128)  45056       conv3_block8_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block8_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block8_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block8_1_relu (Activation (None, 28, 28, 128)  0           conv3_block8_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block8_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block8_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block8_concat (Concatenat (None, 28, 28, 384)  0           conv3_block7_concat[0][0]
                                                                 conv3_block8_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block9_0_bn (BatchNormali (None, 28, 28, 384)  1536        conv3_block8_concat[0][0]
__________________________________________________________________________________________________
conv3_block9_0_relu (Activation (None, 28, 28, 384)  0           conv3_block9_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block9_1_conv (Conv2D)    (None, 28, 28, 128)  49152       conv3_block9_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block9_1_bn (BatchNormali (None, 28, 28, 128)  512         conv3_block9_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block9_1_relu (Activation (None, 28, 28, 128)  0           conv3_block9_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block9_2_conv (Conv2D)    (None, 28, 28, 32)   36864       conv3_block9_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block9_concat (Concatenat (None, 28, 28, 416)  0           conv3_block8_concat[0][0]
                                                                 conv3_block9_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block10_0_bn (BatchNormal (None, 28, 28, 416)  1664        conv3_block9_concat[0][0]
__________________________________________________________________________________________________
conv3_block10_0_relu (Activatio (None, 28, 28, 416)  0           conv3_block10_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block10_1_conv (Conv2D)   (None, 28, 28, 128)  53248       conv3_block10_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block10_1_bn (BatchNormal (None, 28, 28, 128)  512         conv3_block10_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block10_1_relu (Activatio (None, 28, 28, 128)  0           conv3_block10_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block10_2_conv (Conv2D)   (None, 28, 28, 32)   36864       conv3_block10_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block10_concat (Concatena (None, 28, 28, 448)  0           conv3_block9_concat[0][0]
                                                                 conv3_block10_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block11_0_bn (BatchNormal (None, 28, 28, 448)  1792        conv3_block10_concat[0][0]
__________________________________________________________________________________________________
conv3_block11_0_relu (Activatio (None, 28, 28, 448)  0           conv3_block11_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block11_1_conv (Conv2D)   (None, 28, 28, 128)  57344       conv3_block11_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block11_1_bn (BatchNormal (None, 28, 28, 128)  512         conv3_block11_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block11_1_relu (Activatio (None, 28, 28, 128)  0           conv3_block11_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block11_2_conv (Conv2D)   (None, 28, 28, 32)   36864       conv3_block11_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block11_concat (Concatena (None, 28, 28, 480)  0           conv3_block10_concat[0][0]
                                                                 conv3_block11_2_conv[0][0]
__________________________________________________________________________________________________
conv3_block12_0_bn (BatchNormal (None, 28, 28, 480)  1920        conv3_block11_concat[0][0]
__________________________________________________________________________________________________
conv3_block12_0_relu (Activatio (None, 28, 28, 480)  0           conv3_block12_0_bn[0][0]
__________________________________________________________________________________________________
conv3_block12_1_conv (Conv2D)   (None, 28, 28, 128)  61440       conv3_block12_0_relu[0][0]
__________________________________________________________________________________________________
conv3_block12_1_bn (BatchNormal (None, 28, 28, 128)  512         conv3_block12_1_conv[0][0]
__________________________________________________________________________________________________
conv3_block12_1_relu (Activatio (None, 28, 28, 128)  0           conv3_block12_1_bn[0][0]
__________________________________________________________________________________________________
conv3_block12_2_conv (Conv2D)   (None, 28, 28, 32)   36864       conv3_block12_1_relu[0][0]
__________________________________________________________________________________________________
conv3_block12_concat (Concatena (None, 28, 28, 512)  0           conv3_block11_concat[0][0]
                                                                 conv3_block12_2_conv[0][0]
__________________________________________________________________________________________________
pool3_bn (BatchNormalization)   (None, 28, 28, 512)  2048        conv3_block12_concat[0][0]
__________________________________________________________________________________________________
pool3_relu (Activation)         (None, 28, 28, 512)  0           pool3_bn[0][0]
__________________________________________________________________________________________________
pool3_conv (Conv2D)             (None, 28, 28, 256)  131072      pool3_relu[0][0]
__________________________________________________________________________________________________
pool3_pool (AveragePooling2D)   (None, 14, 14, 256)  0           pool3_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_0_bn (BatchNormali (None, 14, 14, 256)  1024        pool3_pool[0][0]
__________________________________________________________________________________________________
conv4_block1_0_relu (Activation (None, 14, 14, 256)  0           conv4_block1_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block1_1_conv (Conv2D)    (None, 14, 14, 128)  32768       conv4_block1_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block1_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block1_1_relu (Activation (None, 14, 14, 128)  0           conv4_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block1_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block1_concat (Concatenat (None, 14, 14, 288)  0           pool3_pool[0][0]
                                                                 conv4_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block2_0_bn (BatchNormali (None, 14, 14, 288)  1152        conv4_block1_concat[0][0]
__________________________________________________________________________________________________
conv4_block2_0_relu (Activation (None, 14, 14, 288)  0           conv4_block2_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block2_1_conv (Conv2D)    (None, 14, 14, 128)  36864       conv4_block2_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block2_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block2_1_relu (Activation (None, 14, 14, 128)  0           conv4_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block2_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block2_concat (Concatenat (None, 14, 14, 320)  0           conv4_block1_concat[0][0]
                                                                 conv4_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block3_0_bn (BatchNormali (None, 14, 14, 320)  1280        conv4_block2_concat[0][0]
__________________________________________________________________________________________________
conv4_block3_0_relu (Activation (None, 14, 14, 320)  0           conv4_block3_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block3_1_conv (Conv2D)    (None, 14, 14, 128)  40960       conv4_block3_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block3_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block3_1_relu (Activation (None, 14, 14, 128)  0           conv4_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block3_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block3_concat (Concatenat (None, 14, 14, 352)  0           conv4_block2_concat[0][0]
                                                                 conv4_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block4_0_bn (BatchNormali (None, 14, 14, 352)  1408        conv4_block3_concat[0][0]
__________________________________________________________________________________________________
conv4_block4_0_relu (Activation (None, 14, 14, 352)  0           conv4_block4_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block4_1_conv (Conv2D)    (None, 14, 14, 128)  45056       conv4_block4_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block4_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block4_1_relu (Activation (None, 14, 14, 128)  0           conv4_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block4_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block4_concat (Concatenat (None, 14, 14, 384)  0           conv4_block3_concat[0][0]
                                                                 conv4_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block5_0_bn (BatchNormali (None, 14, 14, 384)  1536        conv4_block4_concat[0][0]
__________________________________________________________________________________________________
conv4_block5_0_relu (Activation (None, 14, 14, 384)  0           conv4_block5_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block5_1_conv (Conv2D)    (None, 14, 14, 128)  49152       conv4_block5_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block5_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block5_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block5_1_relu (Activation (None, 14, 14, 128)  0           conv4_block5_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block5_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block5_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block5_concat (Concatenat (None, 14, 14, 416)  0           conv4_block4_concat[0][0]
                                                                 conv4_block5_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block6_0_bn (BatchNormali (None, 14, 14, 416)  1664        conv4_block5_concat[0][0]
__________________________________________________________________________________________________
conv4_block6_0_relu (Activation (None, 14, 14, 416)  0           conv4_block6_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block6_1_conv (Conv2D)    (None, 14, 14, 128)  53248       conv4_block6_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block6_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block6_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block6_1_relu (Activation (None, 14, 14, 128)  0           conv4_block6_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block6_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block6_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block6_concat (Concatenat (None, 14, 14, 448)  0           conv4_block5_concat[0][0]
                                                                 conv4_block6_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block7_0_bn (BatchNormali (None, 14, 14, 448)  1792        conv4_block6_concat[0][0]
__________________________________________________________________________________________________
conv4_block7_0_relu (Activation (None, 14, 14, 448)  0           conv4_block7_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block7_1_conv (Conv2D)    (None, 14, 14, 128)  57344       conv4_block7_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block7_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block7_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block7_1_relu (Activation (None, 14, 14, 128)  0           conv4_block7_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block7_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block7_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block7_concat (Concatenat (None, 14, 14, 480)  0           conv4_block6_concat[0][0]
                                                                 conv4_block7_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block8_0_bn (BatchNormali (None, 14, 14, 480)  1920        conv4_block7_concat[0][0]
__________________________________________________________________________________________________
conv4_block8_0_relu (Activation (None, 14, 14, 480)  0           conv4_block8_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block8_1_conv (Conv2D)    (None, 14, 14, 128)  61440       conv4_block8_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block8_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block8_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block8_1_relu (Activation (None, 14, 14, 128)  0           conv4_block8_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block8_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block8_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block8_concat (Concatenat (None, 14, 14, 512)  0           conv4_block7_concat[0][0]
                                                                 conv4_block8_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block9_0_bn (BatchNormali (None, 14, 14, 512)  2048        conv4_block8_concat[0][0]
__________________________________________________________________________________________________
conv4_block9_0_relu (Activation (None, 14, 14, 512)  0           conv4_block9_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block9_1_conv (Conv2D)    (None, 14, 14, 128)  65536       conv4_block9_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block9_1_bn (BatchNormali (None, 14, 14, 128)  512         conv4_block9_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block9_1_relu (Activation (None, 14, 14, 128)  0           conv4_block9_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block9_2_conv (Conv2D)    (None, 14, 14, 32)   36864       conv4_block9_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block9_concat (Concatenat (None, 14, 14, 544)  0           conv4_block8_concat[0][0]
                                                                 conv4_block9_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block10_0_bn (BatchNormal (None, 14, 14, 544)  2176        conv4_block9_concat[0][0]
__________________________________________________________________________________________________
conv4_block10_0_relu (Activatio (None, 14, 14, 544)  0           conv4_block10_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block10_1_conv (Conv2D)   (None, 14, 14, 128)  69632       conv4_block10_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block10_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block10_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block10_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block10_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block10_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block10_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block10_concat (Concatena (None, 14, 14, 576)  0           conv4_block9_concat[0][0]
                                                                 conv4_block10_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block11_0_bn (BatchNormal (None, 14, 14, 576)  2304        conv4_block10_concat[0][0]
__________________________________________________________________________________________________
conv4_block11_0_relu (Activatio (None, 14, 14, 576)  0           conv4_block11_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block11_1_conv (Conv2D)   (None, 14, 14, 128)  73728       conv4_block11_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block11_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block11_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block11_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block11_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block11_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block11_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block11_concat (Concatena (None, 14, 14, 608)  0           conv4_block10_concat[0][0]
                                                                 conv4_block11_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block12_0_bn (BatchNormal (None, 14, 14, 608)  2432        conv4_block11_concat[0][0]
__________________________________________________________________________________________________
conv4_block12_0_relu (Activatio (None, 14, 14, 608)  0           conv4_block12_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block12_1_conv (Conv2D)   (None, 14, 14, 128)  77824       conv4_block12_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block12_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block12_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block12_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block12_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block12_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block12_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block12_concat (Concatena (None, 14, 14, 640)  0           conv4_block11_concat[0][0]
                                                                 conv4_block12_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block13_0_bn (BatchNormal (None, 14, 14, 640)  2560        conv4_block12_concat[0][0]
__________________________________________________________________________________________________
conv4_block13_0_relu (Activatio (None, 14, 14, 640)  0           conv4_block13_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block13_1_conv (Conv2D)   (None, 14, 14, 128)  81920       conv4_block13_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block13_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block13_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block13_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block13_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block13_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block13_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block13_concat (Concatena (None, 14, 14, 672)  0           conv4_block12_concat[0][0]
                                                                 conv4_block13_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block14_0_bn (BatchNormal (None, 14, 14, 672)  2688        conv4_block13_concat[0][0]
__________________________________________________________________________________________________
conv4_block14_0_relu (Activatio (None, 14, 14, 672)  0           conv4_block14_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block14_1_conv (Conv2D)   (None, 14, 14, 128)  86016       conv4_block14_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block14_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block14_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block14_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block14_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block14_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block14_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block14_concat (Concatena (None, 14, 14, 704)  0           conv4_block13_concat[0][0]
                                                                 conv4_block14_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block15_0_bn (BatchNormal (None, 14, 14, 704)  2816        conv4_block14_concat[0][0]
__________________________________________________________________________________________________
conv4_block15_0_relu (Activatio (None, 14, 14, 704)  0           conv4_block15_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block15_1_conv (Conv2D)   (None, 14, 14, 128)  90112       conv4_block15_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block15_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block15_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block15_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block15_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block15_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block15_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block15_concat (Concatena (None, 14, 14, 736)  0           conv4_block14_concat[0][0]
                                                                 conv4_block15_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block16_0_bn (BatchNormal (None, 14, 14, 736)  2944        conv4_block15_concat[0][0]
__________________________________________________________________________________________________
conv4_block16_0_relu (Activatio (None, 14, 14, 736)  0           conv4_block16_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block16_1_conv (Conv2D)   (None, 14, 14, 128)  94208       conv4_block16_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block16_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block16_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block16_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block16_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block16_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block16_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block16_concat (Concatena (None, 14, 14, 768)  0           conv4_block15_concat[0][0]
                                                                 conv4_block16_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block17_0_bn (BatchNormal (None, 14, 14, 768)  3072        conv4_block16_concat[0][0]
__________________________________________________________________________________________________
conv4_block17_0_relu (Activatio (None, 14, 14, 768)  0           conv4_block17_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block17_1_conv (Conv2D)   (None, 14, 14, 128)  98304       conv4_block17_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block17_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block17_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block17_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block17_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block17_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block17_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block17_concat (Concatena (None, 14, 14, 800)  0           conv4_block16_concat[0][0]
                                                                 conv4_block17_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block18_0_bn (BatchNormal (None, 14, 14, 800)  3200        conv4_block17_concat[0][0]
__________________________________________________________________________________________________
conv4_block18_0_relu (Activatio (None, 14, 14, 800)  0           conv4_block18_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block18_1_conv (Conv2D)   (None, 14, 14, 128)  102400      conv4_block18_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block18_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block18_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block18_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block18_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block18_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block18_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block18_concat (Concatena (None, 14, 14, 832)  0           conv4_block17_concat[0][0]
                                                                 conv4_block18_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block19_0_bn (BatchNormal (None, 14, 14, 832)  3328        conv4_block18_concat[0][0]
__________________________________________________________________________________________________
conv4_block19_0_relu (Activatio (None, 14, 14, 832)  0           conv4_block19_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block19_1_conv (Conv2D)   (None, 14, 14, 128)  106496      conv4_block19_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block19_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block19_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block19_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block19_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block19_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block19_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block19_concat (Concatena (None, 14, 14, 864)  0           conv4_block18_concat[0][0]
                                                                 conv4_block19_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block20_0_bn (BatchNormal (None, 14, 14, 864)  3456        conv4_block19_concat[0][0]
__________________________________________________________________________________________________
conv4_block20_0_relu (Activatio (None, 14, 14, 864)  0           conv4_block20_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block20_1_conv (Conv2D)   (None, 14, 14, 128)  110592      conv4_block20_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block20_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block20_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block20_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block20_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block20_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block20_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block20_concat (Concatena (None, 14, 14, 896)  0           conv4_block19_concat[0][0]
                                                                 conv4_block20_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block21_0_bn (BatchNormal (None, 14, 14, 896)  3584        conv4_block20_concat[0][0]
__________________________________________________________________________________________________
conv4_block21_0_relu (Activatio (None, 14, 14, 896)  0           conv4_block21_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block21_1_conv (Conv2D)   (None, 14, 14, 128)  114688      conv4_block21_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block21_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block21_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block21_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block21_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block21_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block21_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block21_concat (Concatena (None, 14, 14, 928)  0           conv4_block20_concat[0][0]
                                                                 conv4_block21_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block22_0_bn (BatchNormal (None, 14, 14, 928)  3712        conv4_block21_concat[0][0]
__________________________________________________________________________________________________
conv4_block22_0_relu (Activatio (None, 14, 14, 928)  0           conv4_block22_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block22_1_conv (Conv2D)   (None, 14, 14, 128)  118784      conv4_block22_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block22_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block22_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block22_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block22_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block22_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block22_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block22_concat (Concatena (None, 14, 14, 960)  0           conv4_block21_concat[0][0]
                                                                 conv4_block22_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block23_0_bn (BatchNormal (None, 14, 14, 960)  3840        conv4_block22_concat[0][0]
__________________________________________________________________________________________________
conv4_block23_0_relu (Activatio (None, 14, 14, 960)  0           conv4_block23_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block23_1_conv (Conv2D)   (None, 14, 14, 128)  122880      conv4_block23_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block23_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block23_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block23_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block23_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block23_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block23_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block23_concat (Concatena (None, 14, 14, 992)  0           conv4_block22_concat[0][0]
                                                                 conv4_block23_2_conv[0][0]
__________________________________________________________________________________________________
conv4_block24_0_bn (BatchNormal (None, 14, 14, 992)  3968        conv4_block23_concat[0][0]
__________________________________________________________________________________________________
conv4_block24_0_relu (Activatio (None, 14, 14, 992)  0           conv4_block24_0_bn[0][0]
__________________________________________________________________________________________________
conv4_block24_1_conv (Conv2D)   (None, 14, 14, 128)  126976      conv4_block24_0_relu[0][0]
__________________________________________________________________________________________________
conv4_block24_1_bn (BatchNormal (None, 14, 14, 128)  512         conv4_block24_1_conv[0][0]
__________________________________________________________________________________________________
conv4_block24_1_relu (Activatio (None, 14, 14, 128)  0           conv4_block24_1_bn[0][0]
__________________________________________________________________________________________________
conv4_block24_2_conv (Conv2D)   (None, 14, 14, 32)   36864       conv4_block24_1_relu[0][0]
__________________________________________________________________________________________________
conv4_block24_concat (Concatena (None, 14, 14, 1024) 0           conv4_block23_concat[0][0]
                                                                 conv4_block24_2_conv[0][0]
__________________________________________________________________________________________________
pool4_bn (BatchNormalization)   (None, 14, 14, 1024) 4096        conv4_block24_concat[0][0]
__________________________________________________________________________________________________
pool4_relu (Activation)         (None, 14, 14, 1024) 0           pool4_bn[0][0]
__________________________________________________________________________________________________
pool4_conv (Conv2D)             (None, 14, 14, 512)  524288      pool4_relu[0][0]
__________________________________________________________________________________________________
pool4_pool (AveragePooling2D)   (None, 7, 7, 512)    0           pool4_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_0_bn (BatchNormali (None, 7, 7, 512)    2048        pool4_pool[0][0]
__________________________________________________________________________________________________
conv5_block1_0_relu (Activation (None, 7, 7, 512)    0           conv5_block1_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block1_1_conv (Conv2D)    (None, 7, 7, 128)    65536       conv5_block1_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block1_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block1_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block1_1_relu (Activation (None, 7, 7, 128)    0           conv5_block1_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block1_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block1_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block1_concat (Concatenat (None, 7, 7, 544)    0           pool4_pool[0][0]
                                                                 conv5_block1_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block2_0_bn (BatchNormali (None, 7, 7, 544)    2176        conv5_block1_concat[0][0]
__________________________________________________________________________________________________
conv5_block2_0_relu (Activation (None, 7, 7, 544)    0           conv5_block2_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block2_1_conv (Conv2D)    (None, 7, 7, 128)    69632       conv5_block2_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block2_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block2_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block2_1_relu (Activation (None, 7, 7, 128)    0           conv5_block2_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block2_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block2_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block2_concat (Concatenat (None, 7, 7, 576)    0           conv5_block1_concat[0][0]
                                                                 conv5_block2_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block3_0_bn (BatchNormali (None, 7, 7, 576)    2304        conv5_block2_concat[0][0]
__________________________________________________________________________________________________
conv5_block3_0_relu (Activation (None, 7, 7, 576)    0           conv5_block3_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block3_1_conv (Conv2D)    (None, 7, 7, 128)    73728       conv5_block3_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block3_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block3_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block3_1_relu (Activation (None, 7, 7, 128)    0           conv5_block3_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block3_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block3_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block3_concat (Concatenat (None, 7, 7, 608)    0           conv5_block2_concat[0][0]
                                                                 conv5_block3_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block4_0_bn (BatchNormali (None, 7, 7, 608)    2432        conv5_block3_concat[0][0]
__________________________________________________________________________________________________
conv5_block4_0_relu (Activation (None, 7, 7, 608)    0           conv5_block4_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block4_1_conv (Conv2D)    (None, 7, 7, 128)    77824       conv5_block4_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block4_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block4_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block4_1_relu (Activation (None, 7, 7, 128)    0           conv5_block4_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block4_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block4_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block4_concat (Concatenat (None, 7, 7, 640)    0           conv5_block3_concat[0][0]
                                                                 conv5_block4_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block5_0_bn (BatchNormali (None, 7, 7, 640)    2560        conv5_block4_concat[0][0]
__________________________________________________________________________________________________
conv5_block5_0_relu (Activation (None, 7, 7, 640)    0           conv5_block5_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block5_1_conv (Conv2D)    (None, 7, 7, 128)    81920       conv5_block5_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block5_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block5_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block5_1_relu (Activation (None, 7, 7, 128)    0           conv5_block5_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block5_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block5_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block5_concat (Concatenat (None, 7, 7, 672)    0           conv5_block4_concat[0][0]
                                                                 conv5_block5_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block6_0_bn (BatchNormali (None, 7, 7, 672)    2688        conv5_block5_concat[0][0]
__________________________________________________________________________________________________
conv5_block6_0_relu (Activation (None, 7, 7, 672)    0           conv5_block6_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block6_1_conv (Conv2D)    (None, 7, 7, 128)    86016       conv5_block6_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block6_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block6_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block6_1_relu (Activation (None, 7, 7, 128)    0           conv5_block6_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block6_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block6_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block6_concat (Concatenat (None, 7, 7, 704)    0           conv5_block5_concat[0][0]
                                                                 conv5_block6_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block7_0_bn (BatchNormali (None, 7, 7, 704)    2816        conv5_block6_concat[0][0]
__________________________________________________________________________________________________
conv5_block7_0_relu (Activation (None, 7, 7, 704)    0           conv5_block7_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block7_1_conv (Conv2D)    (None, 7, 7, 128)    90112       conv5_block7_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block7_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block7_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block7_1_relu (Activation (None, 7, 7, 128)    0           conv5_block7_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block7_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block7_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block7_concat (Concatenat (None, 7, 7, 736)    0           conv5_block6_concat[0][0]
                                                                 conv5_block7_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block8_0_bn (BatchNormali (None, 7, 7, 736)    2944        conv5_block7_concat[0][0]
__________________________________________________________________________________________________
conv5_block8_0_relu (Activation (None, 7, 7, 736)    0           conv5_block8_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block8_1_conv (Conv2D)    (None, 7, 7, 128)    94208       conv5_block8_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block8_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block8_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block8_1_relu (Activation (None, 7, 7, 128)    0           conv5_block8_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block8_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block8_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block8_concat (Concatenat (None, 7, 7, 768)    0           conv5_block7_concat[0][0]
                                                                 conv5_block8_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block9_0_bn (BatchNormali (None, 7, 7, 768)    3072        conv5_block8_concat[0][0]
__________________________________________________________________________________________________
conv5_block9_0_relu (Activation (None, 7, 7, 768)    0           conv5_block9_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block9_1_conv (Conv2D)    (None, 7, 7, 128)    98304       conv5_block9_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block9_1_bn (BatchNormali (None, 7, 7, 128)    512         conv5_block9_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block9_1_relu (Activation (None, 7, 7, 128)    0           conv5_block9_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block9_2_conv (Conv2D)    (None, 7, 7, 32)     36864       conv5_block9_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block9_concat (Concatenat (None, 7, 7, 800)    0           conv5_block8_concat[0][0]
                                                                 conv5_block9_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block10_0_bn (BatchNormal (None, 7, 7, 800)    3200        conv5_block9_concat[0][0]
__________________________________________________________________________________________________
conv5_block10_0_relu (Activatio (None, 7, 7, 800)    0           conv5_block10_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block10_1_conv (Conv2D)   (None, 7, 7, 128)    102400      conv5_block10_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block10_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block10_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block10_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block10_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block10_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block10_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block10_concat (Concatena (None, 7, 7, 832)    0           conv5_block9_concat[0][0]
                                                                 conv5_block10_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block11_0_bn (BatchNormal (None, 7, 7, 832)    3328        conv5_block10_concat[0][0]
__________________________________________________________________________________________________
conv5_block11_0_relu (Activatio (None, 7, 7, 832)    0           conv5_block11_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block11_1_conv (Conv2D)   (None, 7, 7, 128)    106496      conv5_block11_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block11_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block11_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block11_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block11_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block11_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block11_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block11_concat (Concatena (None, 7, 7, 864)    0           conv5_block10_concat[0][0]
                                                                 conv5_block11_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block12_0_bn (BatchNormal (None, 7, 7, 864)    3456        conv5_block11_concat[0][0]
__________________________________________________________________________________________________
conv5_block12_0_relu (Activatio (None, 7, 7, 864)    0           conv5_block12_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block12_1_conv (Conv2D)   (None, 7, 7, 128)    110592      conv5_block12_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block12_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block12_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block12_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block12_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block12_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block12_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block12_concat (Concatena (None, 7, 7, 896)    0           conv5_block11_concat[0][0]
                                                                 conv5_block12_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block13_0_bn (BatchNormal (None, 7, 7, 896)    3584        conv5_block12_concat[0][0]
__________________________________________________________________________________________________
conv5_block13_0_relu (Activatio (None, 7, 7, 896)    0           conv5_block13_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block13_1_conv (Conv2D)   (None, 7, 7, 128)    114688      conv5_block13_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block13_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block13_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block13_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block13_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block13_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block13_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block13_concat (Concatena (None, 7, 7, 928)    0           conv5_block12_concat[0][0]
                                                                 conv5_block13_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block14_0_bn (BatchNormal (None, 7, 7, 928)    3712        conv5_block13_concat[0][0]
__________________________________________________________________________________________________
conv5_block14_0_relu (Activatio (None, 7, 7, 928)    0           conv5_block14_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block14_1_conv (Conv2D)   (None, 7, 7, 128)    118784      conv5_block14_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block14_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block14_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block14_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block14_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block14_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block14_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block14_concat (Concatena (None, 7, 7, 960)    0           conv5_block13_concat[0][0]
                                                                 conv5_block14_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block15_0_bn (BatchNormal (None, 7, 7, 960)    3840        conv5_block14_concat[0][0]
__________________________________________________________________________________________________
conv5_block15_0_relu (Activatio (None, 7, 7, 960)    0           conv5_block15_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block15_1_conv (Conv2D)   (None, 7, 7, 128)    122880      conv5_block15_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block15_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block15_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block15_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block15_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block15_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block15_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block15_concat (Concatena (None, 7, 7, 992)    0           conv5_block14_concat[0][0]
                                                                 conv5_block15_2_conv[0][0]
__________________________________________________________________________________________________
conv5_block16_0_bn (BatchNormal (None, 7, 7, 992)    3968        conv5_block15_concat[0][0]
__________________________________________________________________________________________________
conv5_block16_0_relu (Activatio (None, 7, 7, 992)    0           conv5_block16_0_bn[0][0]
__________________________________________________________________________________________________
conv5_block16_1_conv (Conv2D)   (None, 7, 7, 128)    126976      conv5_block16_0_relu[0][0]
__________________________________________________________________________________________________
conv5_block16_1_bn (BatchNormal (None, 7, 7, 128)    512         conv5_block16_1_conv[0][0]
__________________________________________________________________________________________________
conv5_block16_1_relu (Activatio (None, 7, 7, 128)    0           conv5_block16_1_bn[0][0]
__________________________________________________________________________________________________
conv5_block16_2_conv (Conv2D)   (None, 7, 7, 32)     36864       conv5_block16_1_relu[0][0]
__________________________________________________________________________________________________
conv5_block16_concat (Concatena (None, 7, 7, 1024)   0           conv5_block15_concat[0][0]
                                                                 conv5_block16_2_conv[0][0]
__________________________________________________________________________________________________
bn (BatchNormalization)         (None, 7, 7, 1024)   4096        conv5_block16_concat[0][0]
__________________________________________________________________________________________________
relu (Activation)               (None, 7, 7, 1024)   0           bn[0][0]
__________________________________________________________________________________________________
flatten (Flatten)               (None, 50176)        0           relu[0][0]
__________________________________________________________________________________________________
dropout_9 (Dropout)             (None, 50176)        0           flatten[0][0]
__________________________________________________________________________________________________
dense_9 (Dense)                 (None, 5)            250885      dropout_9[0][0]
==================================================================================================
Total params: 7,288,389
Trainable params: 7,204,741
Non-trainable params: 83,648
__________________________________________________________________________________________________

Training and validating

history= model_densenet.fit_generator(generator=train_generator,
                                     steps_per_epoch=1000,
                                     validation_data=valid_generator,
                                     validation_steps=1000,
                                     epochs=10)

Epoch 1/10
102/102 [==============================] - 11s 104ms/step - loss: 0.1465 - accuracy: 0.9560 - val_loss: 0.0499 - val_accuracy: 0.9902
Epoch 2/10
102/102 [==============================] - 10s 97ms/step - loss: 0.0491 - accuracy: 0.9877 - val_loss: 0.0422 - val_accuracy: 0.9867
Epoch 3/10
102/102 [==============================] - 10s 97ms/step - loss: 0.0303 - accuracy: 0.9908 - val_loss: 0.0324 - val_accuracy: 0.9920
Epoch 4/10
102/102 [==============================] - 9s 93ms/step - loss: 0.0285 - accuracy: 0.9917 - val_loss: 0.0286 - val_accuracy: 0.9902
Epoch 5/10
102/102 [==============================] - 12s 116ms/step - loss: 0.0158 - accuracy: 0.9948 - val_loss: 0.0237 - val_accuracy: 0.9956
Epoch 6/10
102/102 [==============================] - 11s 103ms/step - loss: 0.0142 - accuracy: 0.9953 - val_loss: 0.0301 - val_accuracy: 0.9929
Epoch 7/10
102/102 [==============================] - 11s 105ms/step - loss: 0.0109 - accuracy: 0.9969 - val_loss: 0.0243 - val_accuracy: 0.9911
Epoch 8/10
102/102 [==============================] - 10s 103ms/step - loss: 0.0074 - accuracy: 0.9980 - val_loss: 0.0216 - val_accuracy: 0.9947
Epoch 9/10
102/102 [==============================] - 11s 108ms/step - loss: 0.0100 - accuracy: 0.9969 - val_loss: 0.0237 - val_accuracy: 0.9911
Epoch 10/10
102/102 [==============================] - 12s 121ms/step - loss: 0.0065 - accuracy: 0.9976 - val_loss: 0.0110 - val_accuracy: 0.9982

Testing the Trained model with test data

accr = model_densenet.evaluate(X_test,y_test)

151/151 [==============================] - 2s 12ms/step - loss: 0.0209 - accuracy: 0.9936

Accuracy

y_pred = model_densenet.predict(X_test)
y_pred=y_pred.argmax(axis=1)
acc2=accr[1]
print('Test set\n  Accuracy: {:0.5f}'.format(accr[1]))

Test set
  Accuracy: 0.99358

Precision, Recall, F1

print('\n')
print("Precision, Recall, F1")
print('\n')
labels =['No DR', 'Moderate', 'Mild', 'Proliferative DR', 'Severe']
CR=classification_report(y_test, y_pred, target_names=labels)
print(CR)
print('\n')

Precision, Recall, F1


                  precision    recall  f1-score   support

           No DR       1.00      0.98      0.99       297
        Moderate       1.00      0.99      0.99       694
            Mild       0.99      1.00      0.99      1664
Proliferative DR       0.99      0.99      0.99       960
          Severe       1.00      0.99      0.99      1215

        accuracy                           0.99      4830
       macro avg       0.99      0.99      0.99      4830
    weighted avg       0.99      0.99      0.99      4830

Confusion matrix

CM=confusion_matrix(y_test, y_pred)
fig, ax = plot_confusion_matrix(conf_mat=CM,figsize=(10, 10),
                                show_absolute=True,
                                show_normed=True,
                                colorbar=False)
ax.set_xticklabels([''] + labels)
ax.set_yticklabels([''] + labels)
plt.show()

Xception Model using as transfer learning

exception_model = Xception(weights="imagenet", include_top=False,
    input_tensor=Input(shape=(224, 224, 3)))

outputs = exception_model.output
outputs = Flatten(name="flatten")(outputs)
outputs = Dropout(0.5)(outputs)
outputs = Dense(5, activation="softmax")(outputs)

model_exception = Model(inputs=exception_model.input, outputs=outputs)

for layer in resnet.layers:
    layer.trainable = False

model_exception.compile(
        loss='categorical_crossentropy',
        optimizer='adam',
        metrics=['accuracy']
)
model_exception.summary()

Model: "functional_21"
__________________________________________________________________________________________________
Layer (type)                    Output Shape         Param #     Connected to
==================================================================================================
input_11 (InputLayer)           [(None, 224, 224, 3) 0
__________________________________________________________________________________________________
block1_conv1 (Conv2D)           (None, 111, 111, 32) 864         input_11[0][0]
__________________________________________________________________________________________________
block1_conv1_bn (BatchNormaliza (None, 111, 111, 32) 128         block1_conv1[0][0]
__________________________________________________________________________________________________
block1_conv1_act (Activation)   (None, 111, 111, 32) 0           block1_conv1_bn[0][0]
__________________________________________________________________________________________________
block1_conv2 (Conv2D)           (None, 109, 109, 64) 18432       block1_conv1_act[0][0]
__________________________________________________________________________________________________
block1_conv2_bn (BatchNormaliza (None, 109, 109, 64) 256         block1_conv2[0][0]
__________________________________________________________________________________________________
block1_conv2_act (Activation)   (None, 109, 109, 64) 0           block1_conv2_bn[0][0]
__________________________________________________________________________________________________
block2_sepconv1 (SeparableConv2 (None, 109, 109, 128 8768        block1_conv2_act[0][0]
__________________________________________________________________________________________________
block2_sepconv1_bn (BatchNormal (None, 109, 109, 128 512         block2_sepconv1[0][0]
__________________________________________________________________________________________________
block2_sepconv2_act (Activation (None, 109, 109, 128 0           block2_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block2_sepconv2 (SeparableConv2 (None, 109, 109, 128 17536       block2_sepconv2_act[0][0]
__________________________________________________________________________________________________
block2_sepconv2_bn (BatchNormal (None, 109, 109, 128 512         block2_sepconv2[0][0]
__________________________________________________________________________________________________
conv2d_211 (Conv2D)             (None, 55, 55, 128)  8192        block1_conv2_act[0][0]
__________________________________________________________________________________________________
block2_pool (MaxPooling2D)      (None, 55, 55, 128)  0           block2_sepconv2_bn[0][0]
__________________________________________________________________________________________________
batch_normalization_211 (BatchN (None, 55, 55, 128)  512         conv2d_211[0][0]
__________________________________________________________________________________________________
add_24 (Add)                    (None, 55, 55, 128)  0           block2_pool[0][0]
                                                                 batch_normalization_211[0][0]
__________________________________________________________________________________________________
block3_sepconv1_act (Activation (None, 55, 55, 128)  0           add_24[0][0]
__________________________________________________________________________________________________
block3_sepconv1 (SeparableConv2 (None, 55, 55, 256)  33920       block3_sepconv1_act[0][0]
__________________________________________________________________________________________________
block3_sepconv1_bn (BatchNormal (None, 55, 55, 256)  1024        block3_sepconv1[0][0]
__________________________________________________________________________________________________
block3_sepconv2_act (Activation (None, 55, 55, 256)  0           block3_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block3_sepconv2 (SeparableConv2 (None, 55, 55, 256)  67840       block3_sepconv2_act[0][0]
__________________________________________________________________________________________________
block3_sepconv2_bn (BatchNormal (None, 55, 55, 256)  1024        block3_sepconv2[0][0]
__________________________________________________________________________________________________
conv2d_212 (Conv2D)             (None, 28, 28, 256)  32768       add_24[0][0]
__________________________________________________________________________________________________
block3_pool (MaxPooling2D)      (None, 28, 28, 256)  0           block3_sepconv2_bn[0][0]
__________________________________________________________________________________________________
batch_normalization_212 (BatchN (None, 28, 28, 256)  1024        conv2d_212[0][0]
__________________________________________________________________________________________________
add_25 (Add)                    (None, 28, 28, 256)  0           block3_pool[0][0]
                                                                 batch_normalization_212[0][0]
__________________________________________________________________________________________________
block4_sepconv1_act (Activation (None, 28, 28, 256)  0           add_25[0][0]
__________________________________________________________________________________________________
block4_sepconv1 (SeparableConv2 (None, 28, 28, 728)  188672      block4_sepconv1_act[0][0]
__________________________________________________________________________________________________
block4_sepconv1_bn (BatchNormal (None, 28, 28, 728)  2912        block4_sepconv1[0][0]
__________________________________________________________________________________________________
block4_sepconv2_act (Activation (None, 28, 28, 728)  0           block4_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block4_sepconv2 (SeparableConv2 (None, 28, 28, 728)  536536      block4_sepconv2_act[0][0]
__________________________________________________________________________________________________
block4_sepconv2_bn (BatchNormal (None, 28, 28, 728)  2912        block4_sepconv2[0][0]
__________________________________________________________________________________________________
conv2d_213 (Conv2D)             (None, 14, 14, 728)  186368      add_25[0][0]
__________________________________________________________________________________________________
block4_pool (MaxPooling2D)      (None, 14, 14, 728)  0           block4_sepconv2_bn[0][0]
__________________________________________________________________________________________________
batch_normalization_213 (BatchN (None, 14, 14, 728)  2912        conv2d_213[0][0]
__________________________________________________________________________________________________
add_26 (Add)                    (None, 14, 14, 728)  0           block4_pool[0][0]
                                                                 batch_normalization_213[0][0]
__________________________________________________________________________________________________
block5_sepconv1_act (Activation (None, 14, 14, 728)  0           add_26[0][0]
__________________________________________________________________________________________________
block5_sepconv1 (SeparableConv2 (None, 14, 14, 728)  536536      block5_sepconv1_act[0][0]
__________________________________________________________________________________________________
block5_sepconv1_bn (BatchNormal (None, 14, 14, 728)  2912        block5_sepconv1[0][0]
__________________________________________________________________________________________________
block5_sepconv2_act (Activation (None, 14, 14, 728)  0           block5_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block5_sepconv2 (SeparableConv2 (None, 14, 14, 728)  536536      block5_sepconv2_act[0][0]
__________________________________________________________________________________________________
block5_sepconv2_bn (BatchNormal (None, 14, 14, 728)  2912        block5_sepconv2[0][0]
__________________________________________________________________________________________________
block5_sepconv3_act (Activation (None, 14, 14, 728)  0           block5_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block5_sepconv3 (SeparableConv2 (None, 14, 14, 728)  536536      block5_sepconv3_act[0][0]
__________________________________________________________________________________________________
block5_sepconv3_bn (BatchNormal (None, 14, 14, 728)  2912        block5_sepconv3[0][0]
__________________________________________________________________________________________________
add_27 (Add)                    (None, 14, 14, 728)  0           block5_sepconv3_bn[0][0]
                                                                 add_26[0][0]
__________________________________________________________________________________________________
block6_sepconv1_act (Activation (None, 14, 14, 728)  0           add_27[0][0]
__________________________________________________________________________________________________
block6_sepconv1 (SeparableConv2 (None, 14, 14, 728)  536536      block6_sepconv1_act[0][0]
__________________________________________________________________________________________________
block6_sepconv1_bn (BatchNormal (None, 14, 14, 728)  2912        block6_sepconv1[0][0]
__________________________________________________________________________________________________
block6_sepconv2_act (Activation (None, 14, 14, 728)  0           block6_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block6_sepconv2 (SeparableConv2 (None, 14, 14, 728)  536536      block6_sepconv2_act[0][0]
__________________________________________________________________________________________________
block6_sepconv2_bn (BatchNormal (None, 14, 14, 728)  2912        block6_sepconv2[0][0]
__________________________________________________________________________________________________
block6_sepconv3_act (Activation (None, 14, 14, 728)  0           block6_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block6_sepconv3 (SeparableConv2 (None, 14, 14, 728)  536536      block6_sepconv3_act[0][0]
__________________________________________________________________________________________________
block6_sepconv3_bn (BatchNormal (None, 14, 14, 728)  2912        block6_sepconv3[0][0]
__________________________________________________________________________________________________
add_28 (Add)                    (None, 14, 14, 728)  0           block6_sepconv3_bn[0][0]
                                                                 add_27[0][0]
__________________________________________________________________________________________________
block7_sepconv1_act (Activation (None, 14, 14, 728)  0           add_28[0][0]
__________________________________________________________________________________________________
block7_sepconv1 (SeparableConv2 (None, 14, 14, 728)  536536      block7_sepconv1_act[0][0]
__________________________________________________________________________________________________
block7_sepconv1_bn (BatchNormal (None, 14, 14, 728)  2912        block7_sepconv1[0][0]
__________________________________________________________________________________________________
block7_sepconv2_act (Activation (None, 14, 14, 728)  0           block7_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block7_sepconv2 (SeparableConv2 (None, 14, 14, 728)  536536      block7_sepconv2_act[0][0]
__________________________________________________________________________________________________
block7_sepconv2_bn (BatchNormal (None, 14, 14, 728)  2912        block7_sepconv2[0][0]
__________________________________________________________________________________________________
block7_sepconv3_act (Activation (None, 14, 14, 728)  0           block7_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block7_sepconv3 (SeparableConv2 (None, 14, 14, 728)  536536      block7_sepconv3_act[0][0]
__________________________________________________________________________________________________
block7_sepconv3_bn (BatchNormal (None, 14, 14, 728)  2912        block7_sepconv3[0][0]
__________________________________________________________________________________________________
add_29 (Add)                    (None, 14, 14, 728)  0           block7_sepconv3_bn[0][0]
                                                                 add_28[0][0]
__________________________________________________________________________________________________
block8_sepconv1_act (Activation (None, 14, 14, 728)  0           add_29[0][0]
__________________________________________________________________________________________________
block8_sepconv1 (SeparableConv2 (None, 14, 14, 728)  536536      block8_sepconv1_act[0][0]
__________________________________________________________________________________________________
block8_sepconv1_bn (BatchNormal (None, 14, 14, 728)  2912        block8_sepconv1[0][0]
__________________________________________________________________________________________________
block8_sepconv2_act (Activation (None, 14, 14, 728)  0           block8_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block8_sepconv2 (SeparableConv2 (None, 14, 14, 728)  536536      block8_sepconv2_act[0][0]
__________________________________________________________________________________________________
block8_sepconv2_bn (BatchNormal (None, 14, 14, 728)  2912        block8_sepconv2[0][0]
__________________________________________________________________________________________________
block8_sepconv3_act (Activation (None, 14, 14, 728)  0           block8_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block8_sepconv3 (SeparableConv2 (None, 14, 14, 728)  536536      block8_sepconv3_act[0][0]
__________________________________________________________________________________________________
block8_sepconv3_bn (BatchNormal (None, 14, 14, 728)  2912        block8_sepconv3[0][0]
__________________________________________________________________________________________________
add_30 (Add)                    (None, 14, 14, 728)  0           block8_sepconv3_bn[0][0]
                                                                 add_29[0][0]
__________________________________________________________________________________________________
block9_sepconv1_act (Activation (None, 14, 14, 728)  0           add_30[0][0]
__________________________________________________________________________________________________
block9_sepconv1 (SeparableConv2 (None, 14, 14, 728)  536536      block9_sepconv1_act[0][0]
__________________________________________________________________________________________________
block9_sepconv1_bn (BatchNormal (None, 14, 14, 728)  2912        block9_sepconv1[0][0]
__________________________________________________________________________________________________
block9_sepconv2_act (Activation (None, 14, 14, 728)  0           block9_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block9_sepconv2 (SeparableConv2 (None, 14, 14, 728)  536536      block9_sepconv2_act[0][0]
__________________________________________________________________________________________________
block9_sepconv2_bn (BatchNormal (None, 14, 14, 728)  2912        block9_sepconv2[0][0]
__________________________________________________________________________________________________
block9_sepconv3_act (Activation (None, 14, 14, 728)  0           block9_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block9_sepconv3 (SeparableConv2 (None, 14, 14, 728)  536536      block9_sepconv3_act[0][0]
__________________________________________________________________________________________________
block9_sepconv3_bn (BatchNormal (None, 14, 14, 728)  2912        block9_sepconv3[0][0]
__________________________________________________________________________________________________
add_31 (Add)                    (None, 14, 14, 728)  0           block9_sepconv3_bn[0][0]
                                                                 add_30[0][0]
__________________________________________________________________________________________________
block10_sepconv1_act (Activatio (None, 14, 14, 728)  0           add_31[0][0]
__________________________________________________________________________________________________
block10_sepconv1 (SeparableConv (None, 14, 14, 728)  536536      block10_sepconv1_act[0][0]
__________________________________________________________________________________________________
block10_sepconv1_bn (BatchNorma (None, 14, 14, 728)  2912        block10_sepconv1[0][0]
__________________________________________________________________________________________________
block10_sepconv2_act (Activatio (None, 14, 14, 728)  0           block10_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block10_sepconv2 (SeparableConv (None, 14, 14, 728)  536536      block10_sepconv2_act[0][0]
__________________________________________________________________________________________________
block10_sepconv2_bn (BatchNorma (None, 14, 14, 728)  2912        block10_sepconv2[0][0]
__________________________________________________________________________________________________
block10_sepconv3_act (Activatio (None, 14, 14, 728)  0           block10_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block10_sepconv3 (SeparableConv (None, 14, 14, 728)  536536      block10_sepconv3_act[0][0]
__________________________________________________________________________________________________
block10_sepconv3_bn (BatchNorma (None, 14, 14, 728)  2912        block10_sepconv3[0][0]
__________________________________________________________________________________________________
add_32 (Add)                    (None, 14, 14, 728)  0           block10_sepconv3_bn[0][0]
                                                                 add_31[0][0]
__________________________________________________________________________________________________
block11_sepconv1_act (Activatio (None, 14, 14, 728)  0           add_32[0][0]
__________________________________________________________________________________________________
block11_sepconv1 (SeparableConv (None, 14, 14, 728)  536536      block11_sepconv1_act[0][0]
__________________________________________________________________________________________________
block11_sepconv1_bn (BatchNorma (None, 14, 14, 728)  2912        block11_sepconv1[0][0]
__________________________________________________________________________________________________
block11_sepconv2_act (Activatio (None, 14, 14, 728)  0           block11_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block11_sepconv2 (SeparableConv (None, 14, 14, 728)  536536      block11_sepconv2_act[0][0]
__________________________________________________________________________________________________
block11_sepconv2_bn (BatchNorma (None, 14, 14, 728)  2912        block11_sepconv2[0][0]
__________________________________________________________________________________________________
block11_sepconv3_act (Activatio (None, 14, 14, 728)  0           block11_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block11_sepconv3 (SeparableConv (None, 14, 14, 728)  536536      block11_sepconv3_act[0][0]
__________________________________________________________________________________________________
block11_sepconv3_bn (BatchNorma (None, 14, 14, 728)  2912        block11_sepconv3[0][0]
__________________________________________________________________________________________________
add_33 (Add)                    (None, 14, 14, 728)  0           block11_sepconv3_bn[0][0]
                                                                 add_32[0][0]
__________________________________________________________________________________________________
block12_sepconv1_act (Activatio (None, 14, 14, 728)  0           add_33[0][0]
__________________________________________________________________________________________________
block12_sepconv1 (SeparableConv (None, 14, 14, 728)  536536      block12_sepconv1_act[0][0]
__________________________________________________________________________________________________
block12_sepconv1_bn (BatchNorma (None, 14, 14, 728)  2912        block12_sepconv1[0][0]
__________________________________________________________________________________________________
block12_sepconv2_act (Activatio (None, 14, 14, 728)  0           block12_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block12_sepconv2 (SeparableConv (None, 14, 14, 728)  536536      block12_sepconv2_act[0][0]
__________________________________________________________________________________________________
block12_sepconv2_bn (BatchNorma (None, 14, 14, 728)  2912        block12_sepconv2[0][0]
__________________________________________________________________________________________________
block12_sepconv3_act (Activatio (None, 14, 14, 728)  0           block12_sepconv2_bn[0][0]
__________________________________________________________________________________________________
block12_sepconv3 (SeparableConv (None, 14, 14, 728)  536536      block12_sepconv3_act[0][0]
__________________________________________________________________________________________________
block12_sepconv3_bn (BatchNorma (None, 14, 14, 728)  2912        block12_sepconv3[0][0]
__________________________________________________________________________________________________
add_34 (Add)                    (None, 14, 14, 728)  0           block12_sepconv3_bn[0][0]
                                                                 add_33[0][0]
__________________________________________________________________________________________________
block13_sepconv1_act (Activatio (None, 14, 14, 728)  0           add_34[0][0]
__________________________________________________________________________________________________
block13_sepconv1 (SeparableConv (None, 14, 14, 728)  536536      block13_sepconv1_act[0][0]
__________________________________________________________________________________________________
block13_sepconv1_bn (BatchNorma (None, 14, 14, 728)  2912        block13_sepconv1[0][0]
__________________________________________________________________________________________________
block13_sepconv2_act (Activatio (None, 14, 14, 728)  0           block13_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block13_sepconv2 (SeparableConv (None, 14, 14, 1024) 752024      block13_sepconv2_act[0][0]
__________________________________________________________________________________________________
block13_sepconv2_bn (BatchNorma (None, 14, 14, 1024) 4096        block13_sepconv2[0][0]
__________________________________________________________________________________________________
conv2d_214 (Conv2D)             (None, 7, 7, 1024)   745472      add_34[0][0]
__________________________________________________________________________________________________
block13_pool (MaxPooling2D)     (None, 7, 7, 1024)   0           block13_sepconv2_bn[0][0]
__________________________________________________________________________________________________
batch_normalization_214 (BatchN (None, 7, 7, 1024)   4096        conv2d_214[0][0]
__________________________________________________________________________________________________
add_35 (Add)                    (None, 7, 7, 1024)   0           block13_pool[0][0]
                                                                 batch_normalization_214[0][0]
__________________________________________________________________________________________________
block14_sepconv1 (SeparableConv (None, 7, 7, 1536)   1582080     add_35[0][0]
__________________________________________________________________________________________________
block14_sepconv1_bn (BatchNorma (None, 7, 7, 1536)   6144        block14_sepconv1[0][0]
__________________________________________________________________________________________________
block14_sepconv1_act (Activatio (None, 7, 7, 1536)   0           block14_sepconv1_bn[0][0]
__________________________________________________________________________________________________
block14_sepconv2 (SeparableConv (None, 7, 7, 2048)   3159552     block14_sepconv1_act[0][0]
__________________________________________________________________________________________________
block14_sepconv2_bn (BatchNorma (None, 7, 7, 2048)   8192        block14_sepconv2[0][0]
__________________________________________________________________________________________________
block14_sepconv2_act (Activatio (None, 7, 7, 2048)   0           block14_sepconv2_bn[0][0]
__________________________________________________________________________________________________
flatten (Flatten)               (None, 100352)       0           block14_sepconv2_act[0][0]
__________________________________________________________________________________________________
dropout_10 (Dropout)            (None, 100352)       0           flatten[0][0]
__________________________________________________________________________________________________
dense_10 (Dense)                (None, 5)            501765      dropout_10[0][0]
==================================================================================================
Total params: 21,363,245
Trainable params: 21,308,717
Non-trainable params: 54,528
__________________________________________________________________________________________________

Training and validating

history= model_exception.fit_generator(generator=train_generator,
                                     steps_per_epoch=1000,
                                     validation_data=valid_generator,
                                     validation_steps=1000,
                                     epochs=10)

Epoch 1/10
102/102 [==============================] - 8s 82ms/step - loss: 0.4837 - accuracy: 0.8429 - val_loss: 0.0748 - val_accuracy: 0.9787
Epoch 2/10
102/102 [==============================] - 9s 84ms/step - loss: 0.0579 - accuracy: 0.9845 - val_loss: 0.0358 - val_accuracy: 0.9876
Epoch 3/10
102/102 [==============================] - 9s 84ms/step - loss: 0.0337 - accuracy: 0.9908 - val_loss: 0.0377 - val_accuracy: 0.9929
Epoch 4/10
102/102 [==============================] - 9s 87ms/step - loss: 0.0202 - accuracy: 0.9943 - val_loss: 0.0420 - val_accuracy: 0.9894
Epoch 5/10
102/102 [==============================] - 10s 96ms/step - loss: 0.0301 - accuracy: 0.9925 - val_loss: 0.0444 - val_accuracy: 0.9849
Epoch 6/10
102/102 [==============================] - 9s 84ms/step - loss: 0.0159 - accuracy: 0.9960 - val_loss: 0.0134 - val_accuracy: 0.9982
Epoch 7/10
102/102 [==============================] - 10s 95ms/step - loss: 0.0073 - accuracy: 0.9976 - val_loss: 0.0139 - val_accuracy: 0.9956
Epoch 8/10
102/102 [==============================] - 8s 83ms/step - loss: 0.0285 - accuracy: 0.9920 - val_loss: 0.0315 - val_accuracy: 0.9902
Epoch 9/10
102/102 [==============================] - 8s 82ms/step - loss: 0.0120 - accuracy: 0.9965 - val_loss: 0.0229 - val_accuracy: 0.9965
Epoch 10/10
102/102 [==============================] - 8s 83ms/step - loss: 0.0083 - accuracy: 0.9979 - val_loss: 0.0140 - val_accuracy: 0.9965

Testing the Trained model with test data

accr = model_exception.evaluate(X_test,y_test)

151/151 [==============================] - 3s 18ms/step - loss: 0.0194 - accuracy: 0.9963

Accuracy

y_pred = model_exception.predict(X_test)
y_pred=y_pred.argmax(axis=1)
acc3=accr[1]
print('Test set\n  Accuracy: {:0.5f}'.format(accr[1]))

Test set
  Accuracy: 0.99627

Precision, Recall, F1

print('\n')
print("Precision, Recall, F1")
print('\n')
labels =['No DR', 'Moderate', 'Mild', 'Proliferative DR', 'Severe']
CR=classification_report(y_test, y_pred, target_names=labels)
print(CR)
print('\n')

Precision, Recall, F1


                  precision    recall  f1-score   support

           No DR       1.00      0.99      0.99       297
        Moderate       0.99      1.00      0.99       694
            Mild       1.00      0.99      1.00      1664
Proliferative DR       1.00      1.00      1.00       960
          Severe       0.99      1.00      1.00      1215

        accuracy                           1.00      4830
       macro avg       1.00      1.00      1.00      4830
    weighted avg       1.00      1.00      1.00      4830

Confusion matrix

CM=confusion_matrix(y_test, y_pred)
fig, ax = plot_confusion_matrix(conf_mat=CM,figsize=(10, 10),
                                show_absolute=True,
                                show_normed=True,
                                colorbar=False)
ax.set_xticklabels([''] + labels)
ax.set_yticklabels([''] + labels)
plt.show()

InceptionResNet Model using as transfer learning

inceptionRe = InceptionResNetV2(weights="imagenet", include_top=False,
    input_tensor=Input(shape=(224, 224, 3)))

outputs = inceptionRe.output
outputs = Flatten(name="flatten")(outputs)
outputs = Dropout(0.5)(outputs)
outputs = Dense(5, activation="softmax")(outputs)

model_inceptionNet = Model(inputs=inceptionRe.input, outputs=outputs)

for layer in resnet.layers:
    layer.trainable = False

model_inceptionNet.compile(
        loss='categorical_crossentropy',
        optimizer='adam',
        metrics=['accuracy']
)
model_inceptionNet.summary()

Model: "functional_23"
__________________________________________________________________________________________________
Layer (type)                    Output Shape         Param #     Connected to
==================================================================================================
input_12 (InputLayer)           [(None, 224, 224, 3) 0
__________________________________________________________________________________________________
conv2d_215 (Conv2D)             (None, 111, 111, 32) 864         input_12[0][0]
__________________________________________________________________________________________________
batch_normalization_215 (BatchN (None, 111, 111, 32) 96          conv2d_215[0][0]
__________________________________________________________________________________________________
activation_203 (Activation)     (None, 111, 111, 32) 0           batch_normalization_215[0][0]
__________________________________________________________________________________________________
conv2d_216 (Conv2D)             (None, 109, 109, 32) 9216        activation_203[0][0]
__________________________________________________________________________________________________
batch_normalization_216 (BatchN (None, 109, 109, 32) 96          conv2d_216[0][0]
__________________________________________________________________________________________________
activation_204 (Activation)     (None, 109, 109, 32) 0           batch_normalization_216[0][0]
__________________________________________________________________________________________________
conv2d_217 (Conv2D)             (None, 109, 109, 64) 18432       activation_204[0][0]
__________________________________________________________________________________________________
batch_normalization_217 (BatchN (None, 109, 109, 64) 192         conv2d_217[0][0]
__________________________________________________________________________________________________
activation_205 (Activation)     (None, 109, 109, 64) 0           batch_normalization_217[0][0]
__________________________________________________________________________________________________
max_pooling2d_4 (MaxPooling2D)  (None, 54, 54, 64)   0           activation_205[0][0]
__________________________________________________________________________________________________
conv2d_218 (Conv2D)             (None, 54, 54, 80)   5120        max_pooling2d_4[0][0]
__________________________________________________________________________________________________
batch_normalization_218 (BatchN (None, 54, 54, 80)   240         conv2d_218[0][0]
__________________________________________________________________________________________________
activation_206 (Activation)     (None, 54, 54, 80)   0           batch_normalization_218[0][0]
__________________________________________________________________________________________________
conv2d_219 (Conv2D)             (None, 52, 52, 192)  138240      activation_206[0][0]
__________________________________________________________________________________________________
batch_normalization_219 (BatchN (None, 52, 52, 192)  576         conv2d_219[0][0]
__________________________________________________________________________________________________
activation_207 (Activation)     (None, 52, 52, 192)  0           batch_normalization_219[0][0]
__________________________________________________________________________________________________
max_pooling2d_5 (MaxPooling2D)  (None, 25, 25, 192)  0           activation_207[0][0]
__________________________________________________________________________________________________
conv2d_223 (Conv2D)             (None, 25, 25, 64)   12288       max_pooling2d_5[0][0]
__________________________________________________________________________________________________
batch_normalization_223 (BatchN (None, 25, 25, 64)   192         conv2d_223[0][0]
__________________________________________________________________________________________________
activation_211 (Activation)     (None, 25, 25, 64)   0           batch_normalization_223[0][0]
__________________________________________________________________________________________________
conv2d_221 (Conv2D)             (None, 25, 25, 48)   9216        max_pooling2d_5[0][0]
__________________________________________________________________________________________________
conv2d_224 (Conv2D)             (None, 25, 25, 96)   55296       activation_211[0][0]
__________________________________________________________________________________________________
batch_normalization_221 (BatchN (None, 25, 25, 48)   144         conv2d_221[0][0]
__________________________________________________________________________________________________
batch_normalization_224 (BatchN (None, 25, 25, 96)   288         conv2d_224[0][0]
__________________________________________________________________________________________________
activation_209 (Activation)     (None, 25, 25, 48)   0           batch_normalization_221[0][0]
__________________________________________________________________________________________________
activation_212 (Activation)     (None, 25, 25, 96)   0           batch_normalization_224[0][0]
__________________________________________________________________________________________________
average_pooling2d_1 (AveragePoo (None, 25, 25, 192)  0           max_pooling2d_5[0][0]
__________________________________________________________________________________________________
conv2d_220 (Conv2D)             (None, 25, 25, 96)   18432       max_pooling2d_5[0][0]
__________________________________________________________________________________________________
conv2d_222 (Conv2D)             (None, 25, 25, 64)   76800       activation_209[0][0]
__________________________________________________________________________________________________
conv2d_225 (Conv2D)             (None, 25, 25, 96)   82944       activation_212[0][0]
__________________________________________________________________________________________________
conv2d_226 (Conv2D)             (None, 25, 25, 64)   12288       average_pooling2d_1[0][0]
__________________________________________________________________________________________________
batch_normalization_220 (BatchN (None, 25, 25, 96)   288         conv2d_220[0][0]
__________________________________________________________________________________________________
batch_normalization_222 (BatchN (None, 25, 25, 64)   192         conv2d_222[0][0]
__________________________________________________________________________________________________
batch_normalization_225 (BatchN (None, 25, 25, 96)   288         conv2d_225[0][0]
__________________________________________________________________________________________________
batch_normalization_226 (BatchN (None, 25, 25, 64)   192         conv2d_226[0][0]
__________________________________________________________________________________________________
activation_208 (Activation)     (None, 25, 25, 96)   0           batch_normalization_220[0][0]
__________________________________________________________________________________________________
activation_210 (Activation)     (None, 25, 25, 64)   0           batch_normalization_222[0][0]
__________________________________________________________________________________________________
activation_213 (Activation)     (None, 25, 25, 96)   0           batch_normalization_225[0][0]
__________________________________________________________________________________________________
activation_214 (Activation)     (None, 25, 25, 64)   0           batch_normalization_226[0][0]
__________________________________________________________________________________________________
mixed_5b (Concatenate)          (None, 25, 25, 320)  0           activation_208[0][0]
                                                                 activation_210[0][0]
                                                                 activation_213[0][0]
                                                                 activation_214[0][0]
__________________________________________________________________________________________________
conv2d_230 (Conv2D)             (None, 25, 25, 32)   10240       mixed_5b[0][0]
__________________________________________________________________________________________________
batch_normalization_230 (BatchN (None, 25, 25, 32)   96          conv2d_230[0][0]
__________________________________________________________________________________________________
activation_218 (Activation)     (None, 25, 25, 32)   0           batch_normalization_230[0][0]
__________________________________________________________________________________________________
conv2d_228 (Conv2D)             (None, 25, 25, 32)   10240       mixed_5b[0][0]
__________________________________________________________________________________________________
conv2d_231 (Conv2D)             (None, 25, 25, 48)   13824       activation_218[0][0]
__________________________________________________________________________________________________
batch_normalization_228 (BatchN (None, 25, 25, 32)   96          conv2d_228[0][0]
__________________________________________________________________________________________________
batch_normalization_231 (BatchN (None, 25, 25, 48)   144         conv2d_231[0][0]
__________________________________________________________________________________________________
activation_216 (Activation)     (None, 25, 25, 32)   0           batch_normalization_228[0][0]
__________________________________________________________________________________________________
activation_219 (Activation)     (None, 25, 25, 48)   0           batch_normalization_231[0][0]
__________________________________________________________________________________________________
conv2d_227 (Conv2D)             (None, 25, 25, 32)   10240       mixed_5b[0][0]
__________________________________________________________________________________________________
conv2d_229 (Conv2D)             (None, 25, 25, 32)   9216        activation_216[0][0]
__________________________________________________________________________________________________
conv2d_232 (Conv2D)             (None, 25, 25, 64)   27648       activation_219[0][0]
__________________________________________________________________________________________________
batch_normalization_227 (BatchN (None, 25, 25, 32)   96          conv2d_227[0][0]
__________________________________________________________________________________________________
batch_normalization_229 (BatchN (None, 25, 25, 32)   96          conv2d_229[0][0]
__________________________________________________________________________________________________
batch_normalization_232 (BatchN (None, 25, 25, 64)   192         conv2d_232[0][0]
__________________________________________________________________________________________________
activation_215 (Activation)     (None, 25, 25, 32)   0           batch_normalization_227[0][0]
__________________________________________________________________________________________________
activation_217 (Activation)     (None, 25, 25, 32)   0           batch_normalization_229[0][0]
__________________________________________________________________________________________________
activation_220 (Activation)     (None, 25, 25, 64)   0           batch_normalization_232[0][0]
__________________________________________________________________________________________________
block35_1_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_215[0][0]
                                                                 activation_217[0][0]
                                                                 activation_220[0][0]
__________________________________________________________________________________________________
block35_1_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_1_mixed[0][0]
__________________________________________________________________________________________________
block35_1 (Lambda)              (None, 25, 25, 320)  0           mixed_5b[0][0]
                                                                 block35_1_conv[0][0]
__________________________________________________________________________________________________
block35_1_ac (Activation)       (None, 25, 25, 320)  0           block35_1[0][0]
__________________________________________________________________________________________________
conv2d_236 (Conv2D)             (None, 25, 25, 32)   10240       block35_1_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_236 (BatchN (None, 25, 25, 32)   96          conv2d_236[0][0]
__________________________________________________________________________________________________
activation_224 (Activation)     (None, 25, 25, 32)   0           batch_normalization_236[0][0]
__________________________________________________________________________________________________
conv2d_234 (Conv2D)             (None, 25, 25, 32)   10240       block35_1_ac[0][0]
__________________________________________________________________________________________________
conv2d_237 (Conv2D)             (None, 25, 25, 48)   13824       activation_224[0][0]
__________________________________________________________________________________________________
batch_normalization_234 (BatchN (None, 25, 25, 32)   96          conv2d_234[0][0]
__________________________________________________________________________________________________
batch_normalization_237 (BatchN (None, 25, 25, 48)   144         conv2d_237[0][0]
__________________________________________________________________________________________________
activation_222 (Activation)     (None, 25, 25, 32)   0           batch_normalization_234[0][0]
__________________________________________________________________________________________________
activation_225 (Activation)     (None, 25, 25, 48)   0           batch_normalization_237[0][0]
__________________________________________________________________________________________________
conv2d_233 (Conv2D)             (None, 25, 25, 32)   10240       block35_1_ac[0][0]
__________________________________________________________________________________________________
conv2d_235 (Conv2D)             (None, 25, 25, 32)   9216        activation_222[0][0]
__________________________________________________________________________________________________
conv2d_238 (Conv2D)             (None, 25, 25, 64)   27648       activation_225[0][0]
__________________________________________________________________________________________________
batch_normalization_233 (BatchN (None, 25, 25, 32)   96          conv2d_233[0][0]
__________________________________________________________________________________________________
batch_normalization_235 (BatchN (None, 25, 25, 32)   96          conv2d_235[0][0]
__________________________________________________________________________________________________
batch_normalization_238 (BatchN (None, 25, 25, 64)   192         conv2d_238[0][0]
__________________________________________________________________________________________________
activation_221 (Activation)     (None, 25, 25, 32)   0           batch_normalization_233[0][0]
__________________________________________________________________________________________________
activation_223 (Activation)     (None, 25, 25, 32)   0           batch_normalization_235[0][0]
__________________________________________________________________________________________________
activation_226 (Activation)     (None, 25, 25, 64)   0           batch_normalization_238[0][0]
__________________________________________________________________________________________________
block35_2_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_221[0][0]
                                                                 activation_223[0][0]
                                                                 activation_226[0][0]
__________________________________________________________________________________________________
block35_2_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_2_mixed[0][0]
__________________________________________________________________________________________________
block35_2 (Lambda)              (None, 25, 25, 320)  0           block35_1_ac[0][0]
                                                                 block35_2_conv[0][0]
__________________________________________________________________________________________________
block35_2_ac (Activation)       (None, 25, 25, 320)  0           block35_2[0][0]
__________________________________________________________________________________________________
conv2d_242 (Conv2D)             (None, 25, 25, 32)   10240       block35_2_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_242 (BatchN (None, 25, 25, 32)   96          conv2d_242[0][0]
__________________________________________________________________________________________________
activation_230 (Activation)     (None, 25, 25, 32)   0           batch_normalization_242[0][0]
__________________________________________________________________________________________________
conv2d_240 (Conv2D)             (None, 25, 25, 32)   10240       block35_2_ac[0][0]
__________________________________________________________________________________________________
conv2d_243 (Conv2D)             (None, 25, 25, 48)   13824       activation_230[0][0]
__________________________________________________________________________________________________
batch_normalization_240 (BatchN (None, 25, 25, 32)   96          conv2d_240[0][0]
__________________________________________________________________________________________________
batch_normalization_243 (BatchN (None, 25, 25, 48)   144         conv2d_243[0][0]
__________________________________________________________________________________________________
activation_228 (Activation)     (None, 25, 25, 32)   0           batch_normalization_240[0][0]
__________________________________________________________________________________________________
activation_231 (Activation)     (None, 25, 25, 48)   0           batch_normalization_243[0][0]
__________________________________________________________________________________________________
conv2d_239 (Conv2D)             (None, 25, 25, 32)   10240       block35_2_ac[0][0]
__________________________________________________________________________________________________
conv2d_241 (Conv2D)             (None, 25, 25, 32)   9216        activation_228[0][0]
__________________________________________________________________________________________________
conv2d_244 (Conv2D)             (None, 25, 25, 64)   27648       activation_231[0][0]
__________________________________________________________________________________________________
batch_normalization_239 (BatchN (None, 25, 25, 32)   96          conv2d_239[0][0]
__________________________________________________________________________________________________
batch_normalization_241 (BatchN (None, 25, 25, 32)   96          conv2d_241[0][0]
__________________________________________________________________________________________________
batch_normalization_244 (BatchN (None, 25, 25, 64)   192         conv2d_244[0][0]
__________________________________________________________________________________________________
activation_227 (Activation)     (None, 25, 25, 32)   0           batch_normalization_239[0][0]
__________________________________________________________________________________________________
activation_229 (Activation)     (None, 25, 25, 32)   0           batch_normalization_241[0][0]
__________________________________________________________________________________________________
activation_232 (Activation)     (None, 25, 25, 64)   0           batch_normalization_244[0][0]
__________________________________________________________________________________________________
block35_3_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_227[0][0]
                                                                 activation_229[0][0]
                                                                 activation_232[0][0]
__________________________________________________________________________________________________
block35_3_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_3_mixed[0][0]
__________________________________________________________________________________________________
block35_3 (Lambda)              (None, 25, 25, 320)  0           block35_2_ac[0][0]
                                                                 block35_3_conv[0][0]
__________________________________________________________________________________________________
block35_3_ac (Activation)       (None, 25, 25, 320)  0           block35_3[0][0]
__________________________________________________________________________________________________
conv2d_248 (Conv2D)             (None, 25, 25, 32)   10240       block35_3_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_248 (BatchN (None, 25, 25, 32)   96          conv2d_248[0][0]
__________________________________________________________________________________________________
activation_236 (Activation)     (None, 25, 25, 32)   0           batch_normalization_248[0][0]
__________________________________________________________________________________________________
conv2d_246 (Conv2D)             (None, 25, 25, 32)   10240       block35_3_ac[0][0]
__________________________________________________________________________________________________
conv2d_249 (Conv2D)             (None, 25, 25, 48)   13824       activation_236[0][0]
__________________________________________________________________________________________________
batch_normalization_246 (BatchN (None, 25, 25, 32)   96          conv2d_246[0][0]
__________________________________________________________________________________________________
batch_normalization_249 (BatchN (None, 25, 25, 48)   144         conv2d_249[0][0]
__________________________________________________________________________________________________
activation_234 (Activation)     (None, 25, 25, 32)   0           batch_normalization_246[0][0]
__________________________________________________________________________________________________
activation_237 (Activation)     (None, 25, 25, 48)   0           batch_normalization_249[0][0]
__________________________________________________________________________________________________
conv2d_245 (Conv2D)             (None, 25, 25, 32)   10240       block35_3_ac[0][0]
__________________________________________________________________________________________________
conv2d_247 (Conv2D)             (None, 25, 25, 32)   9216        activation_234[0][0]
__________________________________________________________________________________________________
conv2d_250 (Conv2D)             (None, 25, 25, 64)   27648       activation_237[0][0]
__________________________________________________________________________________________________
batch_normalization_245 (BatchN (None, 25, 25, 32)   96          conv2d_245[0][0]
__________________________________________________________________________________________________
batch_normalization_247 (BatchN (None, 25, 25, 32)   96          conv2d_247[0][0]
__________________________________________________________________________________________________
batch_normalization_250 (BatchN (None, 25, 25, 64)   192         conv2d_250[0][0]
__________________________________________________________________________________________________
activation_233 (Activation)     (None, 25, 25, 32)   0           batch_normalization_245[0][0]
__________________________________________________________________________________________________
activation_235 (Activation)     (None, 25, 25, 32)   0           batch_normalization_247[0][0]
__________________________________________________________________________________________________
activation_238 (Activation)     (None, 25, 25, 64)   0           batch_normalization_250[0][0]
__________________________________________________________________________________________________
block35_4_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_233[0][0]
                                                                 activation_235[0][0]
                                                                 activation_238[0][0]
__________________________________________________________________________________________________
block35_4_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_4_mixed[0][0]
__________________________________________________________________________________________________
block35_4 (Lambda)              (None, 25, 25, 320)  0           block35_3_ac[0][0]
                                                                 block35_4_conv[0][0]
__________________________________________________________________________________________________
block35_4_ac (Activation)       (None, 25, 25, 320)  0           block35_4[0][0]
__________________________________________________________________________________________________
conv2d_254 (Conv2D)             (None, 25, 25, 32)   10240       block35_4_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_254 (BatchN (None, 25, 25, 32)   96          conv2d_254[0][0]
__________________________________________________________________________________________________
activation_242 (Activation)     (None, 25, 25, 32)   0           batch_normalization_254[0][0]
__________________________________________________________________________________________________
conv2d_252 (Conv2D)             (None, 25, 25, 32)   10240       block35_4_ac[0][0]
__________________________________________________________________________________________________
conv2d_255 (Conv2D)             (None, 25, 25, 48)   13824       activation_242[0][0]
__________________________________________________________________________________________________
batch_normalization_252 (BatchN (None, 25, 25, 32)   96          conv2d_252[0][0]
__________________________________________________________________________________________________
batch_normalization_255 (BatchN (None, 25, 25, 48)   144         conv2d_255[0][0]
__________________________________________________________________________________________________
activation_240 (Activation)     (None, 25, 25, 32)   0           batch_normalization_252[0][0]
__________________________________________________________________________________________________
activation_243 (Activation)     (None, 25, 25, 48)   0           batch_normalization_255[0][0]
__________________________________________________________________________________________________
conv2d_251 (Conv2D)             (None, 25, 25, 32)   10240       block35_4_ac[0][0]
__________________________________________________________________________________________________
conv2d_253 (Conv2D)             (None, 25, 25, 32)   9216        activation_240[0][0]
__________________________________________________________________________________________________
conv2d_256 (Conv2D)             (None, 25, 25, 64)   27648       activation_243[0][0]
__________________________________________________________________________________________________
batch_normalization_251 (BatchN (None, 25, 25, 32)   96          conv2d_251[0][0]
__________________________________________________________________________________________________
batch_normalization_253 (BatchN (None, 25, 25, 32)   96          conv2d_253[0][0]
__________________________________________________________________________________________________
batch_normalization_256 (BatchN (None, 25, 25, 64)   192         conv2d_256[0][0]
__________________________________________________________________________________________________
activation_239 (Activation)     (None, 25, 25, 32)   0           batch_normalization_251[0][0]
__________________________________________________________________________________________________
activation_241 (Activation)     (None, 25, 25, 32)   0           batch_normalization_253[0][0]
__________________________________________________________________________________________________
activation_244 (Activation)     (None, 25, 25, 64)   0           batch_normalization_256[0][0]
__________________________________________________________________________________________________
block35_5_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_239[0][0]
                                                                 activation_241[0][0]
                                                                 activation_244[0][0]
__________________________________________________________________________________________________
block35_5_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_5_mixed[0][0]
__________________________________________________________________________________________________
block35_5 (Lambda)              (None, 25, 25, 320)  0           block35_4_ac[0][0]
                                                                 block35_5_conv[0][0]
__________________________________________________________________________________________________
block35_5_ac (Activation)       (None, 25, 25, 320)  0           block35_5[0][0]
__________________________________________________________________________________________________
conv2d_260 (Conv2D)             (None, 25, 25, 32)   10240       block35_5_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_260 (BatchN (None, 25, 25, 32)   96          conv2d_260[0][0]
__________________________________________________________________________________________________
activation_248 (Activation)     (None, 25, 25, 32)   0           batch_normalization_260[0][0]
__________________________________________________________________________________________________
conv2d_258 (Conv2D)             (None, 25, 25, 32)   10240       block35_5_ac[0][0]
__________________________________________________________________________________________________
conv2d_261 (Conv2D)             (None, 25, 25, 48)   13824       activation_248[0][0]
__________________________________________________________________________________________________
batch_normalization_258 (BatchN (None, 25, 25, 32)   96          conv2d_258[0][0]
__________________________________________________________________________________________________
batch_normalization_261 (BatchN (None, 25, 25, 48)   144         conv2d_261[0][0]
__________________________________________________________________________________________________
activation_246 (Activation)     (None, 25, 25, 32)   0           batch_normalization_258[0][0]
__________________________________________________________________________________________________
activation_249 (Activation)     (None, 25, 25, 48)   0           batch_normalization_261[0][0]
__________________________________________________________________________________________________
conv2d_257 (Conv2D)             (None, 25, 25, 32)   10240       block35_5_ac[0][0]
__________________________________________________________________________________________________
conv2d_259 (Conv2D)             (None, 25, 25, 32)   9216        activation_246[0][0]
__________________________________________________________________________________________________
conv2d_262 (Conv2D)             (None, 25, 25, 64)   27648       activation_249[0][0]
__________________________________________________________________________________________________
batch_normalization_257 (BatchN (None, 25, 25, 32)   96          conv2d_257[0][0]
__________________________________________________________________________________________________
batch_normalization_259 (BatchN (None, 25, 25, 32)   96          conv2d_259[0][0]
__________________________________________________________________________________________________
batch_normalization_262 (BatchN (None, 25, 25, 64)   192         conv2d_262[0][0]
__________________________________________________________________________________________________
activation_245 (Activation)     (None, 25, 25, 32)   0           batch_normalization_257[0][0]
__________________________________________________________________________________________________
activation_247 (Activation)     (None, 25, 25, 32)   0           batch_normalization_259[0][0]
__________________________________________________________________________________________________
activation_250 (Activation)     (None, 25, 25, 64)   0           batch_normalization_262[0][0]
__________________________________________________________________________________________________
block35_6_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_245[0][0]
                                                                 activation_247[0][0]
                                                                 activation_250[0][0]
__________________________________________________________________________________________________
block35_6_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_6_mixed[0][0]
__________________________________________________________________________________________________
block35_6 (Lambda)              (None, 25, 25, 320)  0           block35_5_ac[0][0]
                                                                 block35_6_conv[0][0]
__________________________________________________________________________________________________
block35_6_ac (Activation)       (None, 25, 25, 320)  0           block35_6[0][0]
__________________________________________________________________________________________________
conv2d_266 (Conv2D)             (None, 25, 25, 32)   10240       block35_6_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_266 (BatchN (None, 25, 25, 32)   96          conv2d_266[0][0]
__________________________________________________________________________________________________
activation_254 (Activation)     (None, 25, 25, 32)   0           batch_normalization_266[0][0]
__________________________________________________________________________________________________
conv2d_264 (Conv2D)             (None, 25, 25, 32)   10240       block35_6_ac[0][0]
__________________________________________________________________________________________________
conv2d_267 (Conv2D)             (None, 25, 25, 48)   13824       activation_254[0][0]
__________________________________________________________________________________________________
batch_normalization_264 (BatchN (None, 25, 25, 32)   96          conv2d_264[0][0]
__________________________________________________________________________________________________
batch_normalization_267 (BatchN (None, 25, 25, 48)   144         conv2d_267[0][0]
__________________________________________________________________________________________________
activation_252 (Activation)     (None, 25, 25, 32)   0           batch_normalization_264[0][0]
__________________________________________________________________________________________________
activation_255 (Activation)     (None, 25, 25, 48)   0           batch_normalization_267[0][0]
__________________________________________________________________________________________________
conv2d_263 (Conv2D)             (None, 25, 25, 32)   10240       block35_6_ac[0][0]
__________________________________________________________________________________________________
conv2d_265 (Conv2D)             (None, 25, 25, 32)   9216        activation_252[0][0]
__________________________________________________________________________________________________
conv2d_268 (Conv2D)             (None, 25, 25, 64)   27648       activation_255[0][0]
__________________________________________________________________________________________________
batch_normalization_263 (BatchN (None, 25, 25, 32)   96          conv2d_263[0][0]
__________________________________________________________________________________________________
batch_normalization_265 (BatchN (None, 25, 25, 32)   96          conv2d_265[0][0]
__________________________________________________________________________________________________
batch_normalization_268 (BatchN (None, 25, 25, 64)   192         conv2d_268[0][0]
__________________________________________________________________________________________________
activation_251 (Activation)     (None, 25, 25, 32)   0           batch_normalization_263[0][0]
__________________________________________________________________________________________________
activation_253 (Activation)     (None, 25, 25, 32)   0           batch_normalization_265[0][0]
__________________________________________________________________________________________________
activation_256 (Activation)     (None, 25, 25, 64)   0           batch_normalization_268[0][0]
__________________________________________________________________________________________________
block35_7_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_251[0][0]
                                                                 activation_253[0][0]
                                                                 activation_256[0][0]
__________________________________________________________________________________________________
block35_7_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_7_mixed[0][0]
__________________________________________________________________________________________________
block35_7 (Lambda)              (None, 25, 25, 320)  0           block35_6_ac[0][0]
                                                                 block35_7_conv[0][0]
__________________________________________________________________________________________________
block35_7_ac (Activation)       (None, 25, 25, 320)  0           block35_7[0][0]
__________________________________________________________________________________________________
conv2d_272 (Conv2D)             (None, 25, 25, 32)   10240       block35_7_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_272 (BatchN (None, 25, 25, 32)   96          conv2d_272[0][0]
__________________________________________________________________________________________________
activation_260 (Activation)     (None, 25, 25, 32)   0           batch_normalization_272[0][0]
__________________________________________________________________________________________________
conv2d_270 (Conv2D)             (None, 25, 25, 32)   10240       block35_7_ac[0][0]
__________________________________________________________________________________________________
conv2d_273 (Conv2D)             (None, 25, 25, 48)   13824       activation_260[0][0]
__________________________________________________________________________________________________
batch_normalization_270 (BatchN (None, 25, 25, 32)   96          conv2d_270[0][0]
__________________________________________________________________________________________________
batch_normalization_273 (BatchN (None, 25, 25, 48)   144         conv2d_273[0][0]
__________________________________________________________________________________________________
activation_258 (Activation)     (None, 25, 25, 32)   0           batch_normalization_270[0][0]
__________________________________________________________________________________________________
activation_261 (Activation)     (None, 25, 25, 48)   0           batch_normalization_273[0][0]
__________________________________________________________________________________________________
conv2d_269 (Conv2D)             (None, 25, 25, 32)   10240       block35_7_ac[0][0]
__________________________________________________________________________________________________
conv2d_271 (Conv2D)             (None, 25, 25, 32)   9216        activation_258[0][0]
__________________________________________________________________________________________________
conv2d_274 (Conv2D)             (None, 25, 25, 64)   27648       activation_261[0][0]
__________________________________________________________________________________________________
batch_normalization_269 (BatchN (None, 25, 25, 32)   96          conv2d_269[0][0]
__________________________________________________________________________________________________
batch_normalization_271 (BatchN (None, 25, 25, 32)   96          conv2d_271[0][0]
__________________________________________________________________________________________________
batch_normalization_274 (BatchN (None, 25, 25, 64)   192         conv2d_274[0][0]
__________________________________________________________________________________________________
activation_257 (Activation)     (None, 25, 25, 32)   0           batch_normalization_269[0][0]
__________________________________________________________________________________________________
activation_259 (Activation)     (None, 25, 25, 32)   0           batch_normalization_271[0][0]
__________________________________________________________________________________________________
activation_262 (Activation)     (None, 25, 25, 64)   0           batch_normalization_274[0][0]
__________________________________________________________________________________________________
block35_8_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_257[0][0]
                                                                 activation_259[0][0]
                                                                 activation_262[0][0]
__________________________________________________________________________________________________
block35_8_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_8_mixed[0][0]
__________________________________________________________________________________________________
block35_8 (Lambda)              (None, 25, 25, 320)  0           block35_7_ac[0][0]
                                                                 block35_8_conv[0][0]
__________________________________________________________________________________________________
block35_8_ac (Activation)       (None, 25, 25, 320)  0           block35_8[0][0]
__________________________________________________________________________________________________
conv2d_278 (Conv2D)             (None, 25, 25, 32)   10240       block35_8_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_278 (BatchN (None, 25, 25, 32)   96          conv2d_278[0][0]
__________________________________________________________________________________________________
activation_266 (Activation)     (None, 25, 25, 32)   0           batch_normalization_278[0][0]
__________________________________________________________________________________________________
conv2d_276 (Conv2D)             (None, 25, 25, 32)   10240       block35_8_ac[0][0]
__________________________________________________________________________________________________
conv2d_279 (Conv2D)             (None, 25, 25, 48)   13824       activation_266[0][0]
__________________________________________________________________________________________________
batch_normalization_276 (BatchN (None, 25, 25, 32)   96          conv2d_276[0][0]
__________________________________________________________________________________________________
batch_normalization_279 (BatchN (None, 25, 25, 48)   144         conv2d_279[0][0]
__________________________________________________________________________________________________
activation_264 (Activation)     (None, 25, 25, 32)   0           batch_normalization_276[0][0]
__________________________________________________________________________________________________
activation_267 (Activation)     (None, 25, 25, 48)   0           batch_normalization_279[0][0]
__________________________________________________________________________________________________
conv2d_275 (Conv2D)             (None, 25, 25, 32)   10240       block35_8_ac[0][0]
__________________________________________________________________________________________________
conv2d_277 (Conv2D)             (None, 25, 25, 32)   9216        activation_264[0][0]
__________________________________________________________________________________________________
conv2d_280 (Conv2D)             (None, 25, 25, 64)   27648       activation_267[0][0]
__________________________________________________________________________________________________
batch_normalization_275 (BatchN (None, 25, 25, 32)   96          conv2d_275[0][0]
__________________________________________________________________________________________________
batch_normalization_277 (BatchN (None, 25, 25, 32)   96          conv2d_277[0][0]
__________________________________________________________________________________________________
batch_normalization_280 (BatchN (None, 25, 25, 64)   192         conv2d_280[0][0]
__________________________________________________________________________________________________
activation_263 (Activation)     (None, 25, 25, 32)   0           batch_normalization_275[0][0]
__________________________________________________________________________________________________
activation_265 (Activation)     (None, 25, 25, 32)   0           batch_normalization_277[0][0]
__________________________________________________________________________________________________
activation_268 (Activation)     (None, 25, 25, 64)   0           batch_normalization_280[0][0]
__________________________________________________________________________________________________
block35_9_mixed (Concatenate)   (None, 25, 25, 128)  0           activation_263[0][0]
                                                                 activation_265[0][0]
                                                                 activation_268[0][0]
__________________________________________________________________________________________________
block35_9_conv (Conv2D)         (None, 25, 25, 320)  41280       block35_9_mixed[0][0]
__________________________________________________________________________________________________
block35_9 (Lambda)              (None, 25, 25, 320)  0           block35_8_ac[0][0]
                                                                 block35_9_conv[0][0]
__________________________________________________________________________________________________
block35_9_ac (Activation)       (None, 25, 25, 320)  0           block35_9[0][0]
__________________________________________________________________________________________________
conv2d_284 (Conv2D)             (None, 25, 25, 32)   10240       block35_9_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_284 (BatchN (None, 25, 25, 32)   96          conv2d_284[0][0]
__________________________________________________________________________________________________
activation_272 (Activation)     (None, 25, 25, 32)   0           batch_normalization_284[0][0]
__________________________________________________________________________________________________
conv2d_282 (Conv2D)             (None, 25, 25, 32)   10240       block35_9_ac[0][0]
__________________________________________________________________________________________________
conv2d_285 (Conv2D)             (None, 25, 25, 48)   13824       activation_272[0][0]
__________________________________________________________________________________________________
batch_normalization_282 (BatchN (None, 25, 25, 32)   96          conv2d_282[0][0]
__________________________________________________________________________________________________
batch_normalization_285 (BatchN (None, 25, 25, 48)   144         conv2d_285[0][0]
__________________________________________________________________________________________________
activation_270 (Activation)     (None, 25, 25, 32)   0           batch_normalization_282[0][0]
__________________________________________________________________________________________________
activation_273 (Activation)     (None, 25, 25, 48)   0           batch_normalization_285[0][0]
__________________________________________________________________________________________________
conv2d_281 (Conv2D)             (None, 25, 25, 32)   10240       block35_9_ac[0][0]
__________________________________________________________________________________________________
conv2d_283 (Conv2D)             (None, 25, 25, 32)   9216        activation_270[0][0]
__________________________________________________________________________________________________
conv2d_286 (Conv2D)             (None, 25, 25, 64)   27648       activation_273[0][0]
__________________________________________________________________________________________________
batch_normalization_281 (BatchN (None, 25, 25, 32)   96          conv2d_281[0][0]
__________________________________________________________________________________________________
batch_normalization_283 (BatchN (None, 25, 25, 32)   96          conv2d_283[0][0]
__________________________________________________________________________________________________
batch_normalization_286 (BatchN (None, 25, 25, 64)   192         conv2d_286[0][0]
__________________________________________________________________________________________________
activation_269 (Activation)     (None, 25, 25, 32)   0           batch_normalization_281[0][0]
__________________________________________________________________________________________________
activation_271 (Activation)     (None, 25, 25, 32)   0           batch_normalization_283[0][0]
__________________________________________________________________________________________________
activation_274 (Activation)     (None, 25, 25, 64)   0           batch_normalization_286[0][0]
__________________________________________________________________________________________________
block35_10_mixed (Concatenate)  (None, 25, 25, 128)  0           activation_269[0][0]
                                                                 activation_271[0][0]
                                                                 activation_274[0][0]
__________________________________________________________________________________________________
block35_10_conv (Conv2D)        (None, 25, 25, 320)  41280       block35_10_mixed[0][0]
__________________________________________________________________________________________________
block35_10 (Lambda)             (None, 25, 25, 320)  0           block35_9_ac[0][0]
                                                                 block35_10_conv[0][0]
__________________________________________________________________________________________________
block35_10_ac (Activation)      (None, 25, 25, 320)  0           block35_10[0][0]
__________________________________________________________________________________________________
conv2d_288 (Conv2D)             (None, 25, 25, 256)  81920       block35_10_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_288 (BatchN (None, 25, 25, 256)  768         conv2d_288[0][0]
__________________________________________________________________________________________________
activation_276 (Activation)     (None, 25, 25, 256)  0           batch_normalization_288[0][0]
__________________________________________________________________________________________________
conv2d_289 (Conv2D)             (None, 25, 25, 256)  589824      activation_276[0][0]
__________________________________________________________________________________________________
batch_normalization_289 (BatchN (None, 25, 25, 256)  768         conv2d_289[0][0]
__________________________________________________________________________________________________
activation_277 (Activation)     (None, 25, 25, 256)  0           batch_normalization_289[0][0]
__________________________________________________________________________________________________
conv2d_287 (Conv2D)             (None, 12, 12, 384)  1105920     block35_10_ac[0][0]
__________________________________________________________________________________________________
conv2d_290 (Conv2D)             (None, 12, 12, 384)  884736      activation_277[0][0]
__________________________________________________________________________________________________
batch_normalization_287 (BatchN (None, 12, 12, 384)  1152        conv2d_287[0][0]
__________________________________________________________________________________________________
batch_normalization_290 (BatchN (None, 12, 12, 384)  1152        conv2d_290[0][0]
__________________________________________________________________________________________________
activation_275 (Activation)     (None, 12, 12, 384)  0           batch_normalization_287[0][0]
__________________________________________________________________________________________________
activation_278 (Activation)     (None, 12, 12, 384)  0           batch_normalization_290[0][0]
__________________________________________________________________________________________________
max_pooling2d_6 (MaxPooling2D)  (None, 12, 12, 320)  0           block35_10_ac[0][0]
__________________________________________________________________________________________________
mixed_6a (Concatenate)          (None, 12, 12, 1088) 0           activation_275[0][0]
                                                                 activation_278[0][0]
                                                                 max_pooling2d_6[0][0]
__________________________________________________________________________________________________
conv2d_292 (Conv2D)             (None, 12, 12, 128)  139264      mixed_6a[0][0]
__________________________________________________________________________________________________
batch_normalization_292 (BatchN (None, 12, 12, 128)  384         conv2d_292[0][0]
__________________________________________________________________________________________________
activation_280 (Activation)     (None, 12, 12, 128)  0           batch_normalization_292[0][0]
__________________________________________________________________________________________________
conv2d_293 (Conv2D)             (None, 12, 12, 160)  143360      activation_280[0][0]
__________________________________________________________________________________________________
batch_normalization_293 (BatchN (None, 12, 12, 160)  480         conv2d_293[0][0]
__________________________________________________________________________________________________
activation_281 (Activation)     (None, 12, 12, 160)  0           batch_normalization_293[0][0]
__________________________________________________________________________________________________
conv2d_291 (Conv2D)             (None, 12, 12, 192)  208896      mixed_6a[0][0]
__________________________________________________________________________________________________
conv2d_294 (Conv2D)             (None, 12, 12, 192)  215040      activation_281[0][0]
__________________________________________________________________________________________________
batch_normalization_291 (BatchN (None, 12, 12, 192)  576         conv2d_291[0][0]
__________________________________________________________________________________________________
batch_normalization_294 (BatchN (None, 12, 12, 192)  576         conv2d_294[0][0]
__________________________________________________________________________________________________
activation_279 (Activation)     (None, 12, 12, 192)  0           batch_normalization_291[0][0]
__________________________________________________________________________________________________
activation_282 (Activation)     (None, 12, 12, 192)  0           batch_normalization_294[0][0]
__________________________________________________________________________________________________
block17_1_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_279[0][0]
                                                                 activation_282[0][0]
__________________________________________________________________________________________________
block17_1_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_1_mixed[0][0]
__________________________________________________________________________________________________
block17_1 (Lambda)              (None, 12, 12, 1088) 0           mixed_6a[0][0]
                                                                 block17_1_conv[0][0]
__________________________________________________________________________________________________
block17_1_ac (Activation)       (None, 12, 12, 1088) 0           block17_1[0][0]
__________________________________________________________________________________________________
conv2d_296 (Conv2D)             (None, 12, 12, 128)  139264      block17_1_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_296 (BatchN (None, 12, 12, 128)  384         conv2d_296[0][0]
__________________________________________________________________________________________________
activation_284 (Activation)     (None, 12, 12, 128)  0           batch_normalization_296[0][0]
__________________________________________________________________________________________________
conv2d_297 (Conv2D)             (None, 12, 12, 160)  143360      activation_284[0][0]
__________________________________________________________________________________________________
batch_normalization_297 (BatchN (None, 12, 12, 160)  480         conv2d_297[0][0]
__________________________________________________________________________________________________
activation_285 (Activation)     (None, 12, 12, 160)  0           batch_normalization_297[0][0]
__________________________________________________________________________________________________
conv2d_295 (Conv2D)             (None, 12, 12, 192)  208896      block17_1_ac[0][0]
__________________________________________________________________________________________________
conv2d_298 (Conv2D)             (None, 12, 12, 192)  215040      activation_285[0][0]
__________________________________________________________________________________________________
batch_normalization_295 (BatchN (None, 12, 12, 192)  576         conv2d_295[0][0]
__________________________________________________________________________________________________
batch_normalization_298 (BatchN (None, 12, 12, 192)  576         conv2d_298[0][0]
__________________________________________________________________________________________________
activation_283 (Activation)     (None, 12, 12, 192)  0           batch_normalization_295[0][0]
__________________________________________________________________________________________________
activation_286 (Activation)     (None, 12, 12, 192)  0           batch_normalization_298[0][0]
__________________________________________________________________________________________________
block17_2_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_283[0][0]
                                                                 activation_286[0][0]
__________________________________________________________________________________________________
block17_2_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_2_mixed[0][0]
__________________________________________________________________________________________________
block17_2 (Lambda)              (None, 12, 12, 1088) 0           block17_1_ac[0][0]
                                                                 block17_2_conv[0][0]
__________________________________________________________________________________________________
block17_2_ac (Activation)       (None, 12, 12, 1088) 0           block17_2[0][0]
__________________________________________________________________________________________________
conv2d_300 (Conv2D)             (None, 12, 12, 128)  139264      block17_2_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_300 (BatchN (None, 12, 12, 128)  384         conv2d_300[0][0]
__________________________________________________________________________________________________
activation_288 (Activation)     (None, 12, 12, 128)  0           batch_normalization_300[0][0]
__________________________________________________________________________________________________
conv2d_301 (Conv2D)             (None, 12, 12, 160)  143360      activation_288[0][0]
__________________________________________________________________________________________________
batch_normalization_301 (BatchN (None, 12, 12, 160)  480         conv2d_301[0][0]
__________________________________________________________________________________________________
activation_289 (Activation)     (None, 12, 12, 160)  0           batch_normalization_301[0][0]
__________________________________________________________________________________________________
conv2d_299 (Conv2D)             (None, 12, 12, 192)  208896      block17_2_ac[0][0]
__________________________________________________________________________________________________
conv2d_302 (Conv2D)             (None, 12, 12, 192)  215040      activation_289[0][0]
__________________________________________________________________________________________________
batch_normalization_299 (BatchN (None, 12, 12, 192)  576         conv2d_299[0][0]
__________________________________________________________________________________________________
batch_normalization_302 (BatchN (None, 12, 12, 192)  576         conv2d_302[0][0]
__________________________________________________________________________________________________
activation_287 (Activation)     (None, 12, 12, 192)  0           batch_normalization_299[0][0]
__________________________________________________________________________________________________
activation_290 (Activation)     (None, 12, 12, 192)  0           batch_normalization_302[0][0]
__________________________________________________________________________________________________
block17_3_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_287[0][0]
                                                                 activation_290[0][0]
__________________________________________________________________________________________________
block17_3_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_3_mixed[0][0]
__________________________________________________________________________________________________
block17_3 (Lambda)              (None, 12, 12, 1088) 0           block17_2_ac[0][0]
                                                                 block17_3_conv[0][0]
__________________________________________________________________________________________________
block17_3_ac (Activation)       (None, 12, 12, 1088) 0           block17_3[0][0]
__________________________________________________________________________________________________
conv2d_304 (Conv2D)             (None, 12, 12, 128)  139264      block17_3_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_304 (BatchN (None, 12, 12, 128)  384         conv2d_304[0][0]
__________________________________________________________________________________________________
activation_292 (Activation)     (None, 12, 12, 128)  0           batch_normalization_304[0][0]
__________________________________________________________________________________________________
conv2d_305 (Conv2D)             (None, 12, 12, 160)  143360      activation_292[0][0]
__________________________________________________________________________________________________
batch_normalization_305 (BatchN (None, 12, 12, 160)  480         conv2d_305[0][0]
__________________________________________________________________________________________________
activation_293 (Activation)     (None, 12, 12, 160)  0           batch_normalization_305[0][0]
__________________________________________________________________________________________________
conv2d_303 (Conv2D)             (None, 12, 12, 192)  208896      block17_3_ac[0][0]
__________________________________________________________________________________________________
conv2d_306 (Conv2D)             (None, 12, 12, 192)  215040      activation_293[0][0]
__________________________________________________________________________________________________
batch_normalization_303 (BatchN (None, 12, 12, 192)  576         conv2d_303[0][0]
__________________________________________________________________________________________________
batch_normalization_306 (BatchN (None, 12, 12, 192)  576         conv2d_306[0][0]
__________________________________________________________________________________________________
activation_291 (Activation)     (None, 12, 12, 192)  0           batch_normalization_303[0][0]
__________________________________________________________________________________________________
activation_294 (Activation)     (None, 12, 12, 192)  0           batch_normalization_306[0][0]
__________________________________________________________________________________________________
block17_4_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_291[0][0]
                                                                 activation_294[0][0]
__________________________________________________________________________________________________
block17_4_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_4_mixed[0][0]
__________________________________________________________________________________________________
block17_4 (Lambda)              (None, 12, 12, 1088) 0           block17_3_ac[0][0]
                                                                 block17_4_conv[0][0]
__________________________________________________________________________________________________
block17_4_ac (Activation)       (None, 12, 12, 1088) 0           block17_4[0][0]
__________________________________________________________________________________________________
conv2d_308 (Conv2D)             (None, 12, 12, 128)  139264      block17_4_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_308 (BatchN (None, 12, 12, 128)  384         conv2d_308[0][0]
__________________________________________________________________________________________________
activation_296 (Activation)     (None, 12, 12, 128)  0           batch_normalization_308[0][0]
__________________________________________________________________________________________________
conv2d_309 (Conv2D)             (None, 12, 12, 160)  143360      activation_296[0][0]
__________________________________________________________________________________________________
batch_normalization_309 (BatchN (None, 12, 12, 160)  480         conv2d_309[0][0]
__________________________________________________________________________________________________
activation_297 (Activation)     (None, 12, 12, 160)  0           batch_normalization_309[0][0]
__________________________________________________________________________________________________
conv2d_307 (Conv2D)             (None, 12, 12, 192)  208896      block17_4_ac[0][0]
__________________________________________________________________________________________________
conv2d_310 (Conv2D)             (None, 12, 12, 192)  215040      activation_297[0][0]
__________________________________________________________________________________________________
batch_normalization_307 (BatchN (None, 12, 12, 192)  576         conv2d_307[0][0]
__________________________________________________________________________________________________
batch_normalization_310 (BatchN (None, 12, 12, 192)  576         conv2d_310[0][0]
__________________________________________________________________________________________________
activation_295 (Activation)     (None, 12, 12, 192)  0           batch_normalization_307[0][0]
__________________________________________________________________________________________________
activation_298 (Activation)     (None, 12, 12, 192)  0           batch_normalization_310[0][0]
__________________________________________________________________________________________________
block17_5_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_295[0][0]
                                                                 activation_298[0][0]
__________________________________________________________________________________________________
block17_5_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_5_mixed[0][0]
__________________________________________________________________________________________________
block17_5 (Lambda)              (None, 12, 12, 1088) 0           block17_4_ac[0][0]
                                                                 block17_5_conv[0][0]
__________________________________________________________________________________________________
block17_5_ac (Activation)       (None, 12, 12, 1088) 0           block17_5[0][0]
__________________________________________________________________________________________________
conv2d_312 (Conv2D)             (None, 12, 12, 128)  139264      block17_5_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_312 (BatchN (None, 12, 12, 128)  384         conv2d_312[0][0]
__________________________________________________________________________________________________
activation_300 (Activation)     (None, 12, 12, 128)  0           batch_normalization_312[0][0]
__________________________________________________________________________________________________
conv2d_313 (Conv2D)             (None, 12, 12, 160)  143360      activation_300[0][0]
__________________________________________________________________________________________________
batch_normalization_313 (BatchN (None, 12, 12, 160)  480         conv2d_313[0][0]
__________________________________________________________________________________________________
activation_301 (Activation)     (None, 12, 12, 160)  0           batch_normalization_313[0][0]
__________________________________________________________________________________________________
conv2d_311 (Conv2D)             (None, 12, 12, 192)  208896      block17_5_ac[0][0]
__________________________________________________________________________________________________
conv2d_314 (Conv2D)             (None, 12, 12, 192)  215040      activation_301[0][0]
__________________________________________________________________________________________________
batch_normalization_311 (BatchN (None, 12, 12, 192)  576         conv2d_311[0][0]
__________________________________________________________________________________________________
batch_normalization_314 (BatchN (None, 12, 12, 192)  576         conv2d_314[0][0]
__________________________________________________________________________________________________
activation_299 (Activation)     (None, 12, 12, 192)  0           batch_normalization_311[0][0]
__________________________________________________________________________________________________
activation_302 (Activation)     (None, 12, 12, 192)  0           batch_normalization_314[0][0]
__________________________________________________________________________________________________
block17_6_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_299[0][0]
                                                                 activation_302[0][0]
__________________________________________________________________________________________________
block17_6_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_6_mixed[0][0]
__________________________________________________________________________________________________
block17_6 (Lambda)              (None, 12, 12, 1088) 0           block17_5_ac[0][0]
                                                                 block17_6_conv[0][0]
__________________________________________________________________________________________________
block17_6_ac (Activation)       (None, 12, 12, 1088) 0           block17_6[0][0]
__________________________________________________________________________________________________
conv2d_316 (Conv2D)             (None, 12, 12, 128)  139264      block17_6_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_316 (BatchN (None, 12, 12, 128)  384         conv2d_316[0][0]
__________________________________________________________________________________________________
activation_304 (Activation)     (None, 12, 12, 128)  0           batch_normalization_316[0][0]
__________________________________________________________________________________________________
conv2d_317 (Conv2D)             (None, 12, 12, 160)  143360      activation_304[0][0]
__________________________________________________________________________________________________
batch_normalization_317 (BatchN (None, 12, 12, 160)  480         conv2d_317[0][0]
__________________________________________________________________________________________________
activation_305 (Activation)     (None, 12, 12, 160)  0           batch_normalization_317[0][0]
__________________________________________________________________________________________________
conv2d_315 (Conv2D)             (None, 12, 12, 192)  208896      block17_6_ac[0][0]
__________________________________________________________________________________________________
conv2d_318 (Conv2D)             (None, 12, 12, 192)  215040      activation_305[0][0]
__________________________________________________________________________________________________
batch_normalization_315 (BatchN (None, 12, 12, 192)  576         conv2d_315[0][0]
__________________________________________________________________________________________________
batch_normalization_318 (BatchN (None, 12, 12, 192)  576         conv2d_318[0][0]
__________________________________________________________________________________________________
activation_303 (Activation)     (None, 12, 12, 192)  0           batch_normalization_315[0][0]
__________________________________________________________________________________________________
activation_306 (Activation)     (None, 12, 12, 192)  0           batch_normalization_318[0][0]
__________________________________________________________________________________________________
block17_7_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_303[0][0]
                                                                 activation_306[0][0]
__________________________________________________________________________________________________
block17_7_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_7_mixed[0][0]
__________________________________________________________________________________________________
block17_7 (Lambda)              (None, 12, 12, 1088) 0           block17_6_ac[0][0]
                                                                 block17_7_conv[0][0]
__________________________________________________________________________________________________
block17_7_ac (Activation)       (None, 12, 12, 1088) 0           block17_7[0][0]
__________________________________________________________________________________________________
conv2d_320 (Conv2D)             (None, 12, 12, 128)  139264      block17_7_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_320 (BatchN (None, 12, 12, 128)  384         conv2d_320[0][0]
__________________________________________________________________________________________________
activation_308 (Activation)     (None, 12, 12, 128)  0           batch_normalization_320[0][0]
__________________________________________________________________________________________________
conv2d_321 (Conv2D)             (None, 12, 12, 160)  143360      activation_308[0][0]
__________________________________________________________________________________________________
batch_normalization_321 (BatchN (None, 12, 12, 160)  480         conv2d_321[0][0]
__________________________________________________________________________________________________
activation_309 (Activation)     (None, 12, 12, 160)  0           batch_normalization_321[0][0]
__________________________________________________________________________________________________
conv2d_319 (Conv2D)             (None, 12, 12, 192)  208896      block17_7_ac[0][0]
__________________________________________________________________________________________________
conv2d_322 (Conv2D)             (None, 12, 12, 192)  215040      activation_309[0][0]
__________________________________________________________________________________________________
batch_normalization_319 (BatchN (None, 12, 12, 192)  576         conv2d_319[0][0]
__________________________________________________________________________________________________
batch_normalization_322 (BatchN (None, 12, 12, 192)  576         conv2d_322[0][0]
__________________________________________________________________________________________________
activation_307 (Activation)     (None, 12, 12, 192)  0           batch_normalization_319[0][0]
__________________________________________________________________________________________________
activation_310 (Activation)     (None, 12, 12, 192)  0           batch_normalization_322[0][0]
__________________________________________________________________________________________________
block17_8_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_307[0][0]
                                                                 activation_310[0][0]
__________________________________________________________________________________________________
block17_8_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_8_mixed[0][0]
__________________________________________________________________________________________________
block17_8 (Lambda)              (None, 12, 12, 1088) 0           block17_7_ac[0][0]
                                                                 block17_8_conv[0][0]
__________________________________________________________________________________________________
block17_8_ac (Activation)       (None, 12, 12, 1088) 0           block17_8[0][0]
__________________________________________________________________________________________________
conv2d_324 (Conv2D)             (None, 12, 12, 128)  139264      block17_8_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_324 (BatchN (None, 12, 12, 128)  384         conv2d_324[0][0]
__________________________________________________________________________________________________
activation_312 (Activation)     (None, 12, 12, 128)  0           batch_normalization_324[0][0]
__________________________________________________________________________________________________
conv2d_325 (Conv2D)             (None, 12, 12, 160)  143360      activation_312[0][0]
__________________________________________________________________________________________________
batch_normalization_325 (BatchN (None, 12, 12, 160)  480         conv2d_325[0][0]
__________________________________________________________________________________________________
activation_313 (Activation)     (None, 12, 12, 160)  0           batch_normalization_325[0][0]
__________________________________________________________________________________________________
conv2d_323 (Conv2D)             (None, 12, 12, 192)  208896      block17_8_ac[0][0]
__________________________________________________________________________________________________
conv2d_326 (Conv2D)             (None, 12, 12, 192)  215040      activation_313[0][0]
__________________________________________________________________________________________________
batch_normalization_323 (BatchN (None, 12, 12, 192)  576         conv2d_323[0][0]
__________________________________________________________________________________________________
batch_normalization_326 (BatchN (None, 12, 12, 192)  576         conv2d_326[0][0]
__________________________________________________________________________________________________
activation_311 (Activation)     (None, 12, 12, 192)  0           batch_normalization_323[0][0]
__________________________________________________________________________________________________
activation_314 (Activation)     (None, 12, 12, 192)  0           batch_normalization_326[0][0]
__________________________________________________________________________________________________
block17_9_mixed (Concatenate)   (None, 12, 12, 384)  0           activation_311[0][0]
                                                                 activation_314[0][0]
__________________________________________________________________________________________________
block17_9_conv (Conv2D)         (None, 12, 12, 1088) 418880      block17_9_mixed[0][0]
__________________________________________________________________________________________________
block17_9 (Lambda)              (None, 12, 12, 1088) 0           block17_8_ac[0][0]
                                                                 block17_9_conv[0][0]
__________________________________________________________________________________________________
block17_9_ac (Activation)       (None, 12, 12, 1088) 0           block17_9[0][0]
__________________________________________________________________________________________________
conv2d_328 (Conv2D)             (None, 12, 12, 128)  139264      block17_9_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_328 (BatchN (None, 12, 12, 128)  384         conv2d_328[0][0]
__________________________________________________________________________________________________
activation_316 (Activation)     (None, 12, 12, 128)  0           batch_normalization_328[0][0]
__________________________________________________________________________________________________
conv2d_329 (Conv2D)             (None, 12, 12, 160)  143360      activation_316[0][0]
__________________________________________________________________________________________________
batch_normalization_329 (BatchN (None, 12, 12, 160)  480         conv2d_329[0][0]
__________________________________________________________________________________________________
activation_317 (Activation)     (None, 12, 12, 160)  0           batch_normalization_329[0][0]
__________________________________________________________________________________________________
conv2d_327 (Conv2D)             (None, 12, 12, 192)  208896      block17_9_ac[0][0]
__________________________________________________________________________________________________
conv2d_330 (Conv2D)             (None, 12, 12, 192)  215040      activation_317[0][0]
__________________________________________________________________________________________________
batch_normalization_327 (BatchN (None, 12, 12, 192)  576         conv2d_327[0][0]
__________________________________________________________________________________________________
batch_normalization_330 (BatchN (None, 12, 12, 192)  576         conv2d_330[0][0]
__________________________________________________________________________________________________
activation_315 (Activation)     (None, 12, 12, 192)  0           batch_normalization_327[0][0]
__________________________________________________________________________________________________
activation_318 (Activation)     (None, 12, 12, 192)  0           batch_normalization_330[0][0]
__________________________________________________________________________________________________
block17_10_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_315[0][0]
                                                                 activation_318[0][0]
__________________________________________________________________________________________________
block17_10_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_10_mixed[0][0]
__________________________________________________________________________________________________
block17_10 (Lambda)             (None, 12, 12, 1088) 0           block17_9_ac[0][0]
                                                                 block17_10_conv[0][0]
__________________________________________________________________________________________________
block17_10_ac (Activation)      (None, 12, 12, 1088) 0           block17_10[0][0]
__________________________________________________________________________________________________
conv2d_332 (Conv2D)             (None, 12, 12, 128)  139264      block17_10_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_332 (BatchN (None, 12, 12, 128)  384         conv2d_332[0][0]
__________________________________________________________________________________________________
activation_320 (Activation)     (None, 12, 12, 128)  0           batch_normalization_332[0][0]
__________________________________________________________________________________________________
conv2d_333 (Conv2D)             (None, 12, 12, 160)  143360      activation_320[0][0]
__________________________________________________________________________________________________
batch_normalization_333 (BatchN (None, 12, 12, 160)  480         conv2d_333[0][0]
__________________________________________________________________________________________________
activation_321 (Activation)     (None, 12, 12, 160)  0           batch_normalization_333[0][0]
__________________________________________________________________________________________________
conv2d_331 (Conv2D)             (None, 12, 12, 192)  208896      block17_10_ac[0][0]
__________________________________________________________________________________________________
conv2d_334 (Conv2D)             (None, 12, 12, 192)  215040      activation_321[0][0]
__________________________________________________________________________________________________
batch_normalization_331 (BatchN (None, 12, 12, 192)  576         conv2d_331[0][0]
__________________________________________________________________________________________________
batch_normalization_334 (BatchN (None, 12, 12, 192)  576         conv2d_334[0][0]
__________________________________________________________________________________________________
activation_319 (Activation)     (None, 12, 12, 192)  0           batch_normalization_331[0][0]
__________________________________________________________________________________________________
activation_322 (Activation)     (None, 12, 12, 192)  0           batch_normalization_334[0][0]
__________________________________________________________________________________________________
block17_11_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_319[0][0]
                                                                 activation_322[0][0]
__________________________________________________________________________________________________
block17_11_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_11_mixed[0][0]
__________________________________________________________________________________________________
block17_11 (Lambda)             (None, 12, 12, 1088) 0           block17_10_ac[0][0]
                                                                 block17_11_conv[0][0]
__________________________________________________________________________________________________
block17_11_ac (Activation)      (None, 12, 12, 1088) 0           block17_11[0][0]
__________________________________________________________________________________________________
conv2d_336 (Conv2D)             (None, 12, 12, 128)  139264      block17_11_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_336 (BatchN (None, 12, 12, 128)  384         conv2d_336[0][0]
__________________________________________________________________________________________________
activation_324 (Activation)     (None, 12, 12, 128)  0           batch_normalization_336[0][0]
__________________________________________________________________________________________________
conv2d_337 (Conv2D)             (None, 12, 12, 160)  143360      activation_324[0][0]
__________________________________________________________________________________________________
batch_normalization_337 (BatchN (None, 12, 12, 160)  480         conv2d_337[0][0]
__________________________________________________________________________________________________
activation_325 (Activation)     (None, 12, 12, 160)  0           batch_normalization_337[0][0]
__________________________________________________________________________________________________
conv2d_335 (Conv2D)             (None, 12, 12, 192)  208896      block17_11_ac[0][0]
__________________________________________________________________________________________________
conv2d_338 (Conv2D)             (None, 12, 12, 192)  215040      activation_325[0][0]
__________________________________________________________________________________________________
batch_normalization_335 (BatchN (None, 12, 12, 192)  576         conv2d_335[0][0]
__________________________________________________________________________________________________
batch_normalization_338 (BatchN (None, 12, 12, 192)  576         conv2d_338[0][0]
__________________________________________________________________________________________________
activation_323 (Activation)     (None, 12, 12, 192)  0           batch_normalization_335[0][0]
__________________________________________________________________________________________________
activation_326 (Activation)     (None, 12, 12, 192)  0           batch_normalization_338[0][0]
__________________________________________________________________________________________________
block17_12_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_323[0][0]
                                                                 activation_326[0][0]
__________________________________________________________________________________________________
block17_12_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_12_mixed[0][0]
__________________________________________________________________________________________________
block17_12 (Lambda)             (None, 12, 12, 1088) 0           block17_11_ac[0][0]
                                                                 block17_12_conv[0][0]
__________________________________________________________________________________________________
block17_12_ac (Activation)      (None, 12, 12, 1088) 0           block17_12[0][0]
__________________________________________________________________________________________________
conv2d_340 (Conv2D)             (None, 12, 12, 128)  139264      block17_12_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_340 (BatchN (None, 12, 12, 128)  384         conv2d_340[0][0]
__________________________________________________________________________________________________
activation_328 (Activation)     (None, 12, 12, 128)  0           batch_normalization_340[0][0]
__________________________________________________________________________________________________
conv2d_341 (Conv2D)             (None, 12, 12, 160)  143360      activation_328[0][0]
__________________________________________________________________________________________________
batch_normalization_341 (BatchN (None, 12, 12, 160)  480         conv2d_341[0][0]
__________________________________________________________________________________________________
activation_329 (Activation)     (None, 12, 12, 160)  0           batch_normalization_341[0][0]
__________________________________________________________________________________________________
conv2d_339 (Conv2D)             (None, 12, 12, 192)  208896      block17_12_ac[0][0]
__________________________________________________________________________________________________
conv2d_342 (Conv2D)             (None, 12, 12, 192)  215040      activation_329[0][0]
__________________________________________________________________________________________________
batch_normalization_339 (BatchN (None, 12, 12, 192)  576         conv2d_339[0][0]
__________________________________________________________________________________________________
batch_normalization_342 (BatchN (None, 12, 12, 192)  576         conv2d_342[0][0]
__________________________________________________________________________________________________
activation_327 (Activation)     (None, 12, 12, 192)  0           batch_normalization_339[0][0]
__________________________________________________________________________________________________
activation_330 (Activation)     (None, 12, 12, 192)  0           batch_normalization_342[0][0]
__________________________________________________________________________________________________
block17_13_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_327[0][0]
                                                                 activation_330[0][0]
__________________________________________________________________________________________________
block17_13_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_13_mixed[0][0]
__________________________________________________________________________________________________
block17_13 (Lambda)             (None, 12, 12, 1088) 0           block17_12_ac[0][0]
                                                                 block17_13_conv[0][0]
__________________________________________________________________________________________________
block17_13_ac (Activation)      (None, 12, 12, 1088) 0           block17_13[0][0]
__________________________________________________________________________________________________
conv2d_344 (Conv2D)             (None, 12, 12, 128)  139264      block17_13_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_344 (BatchN (None, 12, 12, 128)  384         conv2d_344[0][0]
__________________________________________________________________________________________________
activation_332 (Activation)     (None, 12, 12, 128)  0           batch_normalization_344[0][0]
__________________________________________________________________________________________________
conv2d_345 (Conv2D)             (None, 12, 12, 160)  143360      activation_332[0][0]
__________________________________________________________________________________________________
batch_normalization_345 (BatchN (None, 12, 12, 160)  480         conv2d_345[0][0]
__________________________________________________________________________________________________
activation_333 (Activation)     (None, 12, 12, 160)  0           batch_normalization_345[0][0]
__________________________________________________________________________________________________
conv2d_343 (Conv2D)             (None, 12, 12, 192)  208896      block17_13_ac[0][0]
__________________________________________________________________________________________________
conv2d_346 (Conv2D)             (None, 12, 12, 192)  215040      activation_333[0][0]
__________________________________________________________________________________________________
batch_normalization_343 (BatchN (None, 12, 12, 192)  576         conv2d_343[0][0]
__________________________________________________________________________________________________
batch_normalization_346 (BatchN (None, 12, 12, 192)  576         conv2d_346[0][0]
__________________________________________________________________________________________________
activation_331 (Activation)     (None, 12, 12, 192)  0           batch_normalization_343[0][0]
__________________________________________________________________________________________________
activation_334 (Activation)     (None, 12, 12, 192)  0           batch_normalization_346[0][0]
__________________________________________________________________________________________________
block17_14_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_331[0][0]
                                                                 activation_334[0][0]
__________________________________________________________________________________________________
block17_14_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_14_mixed[0][0]
__________________________________________________________________________________________________
block17_14 (Lambda)             (None, 12, 12, 1088) 0           block17_13_ac[0][0]
                                                                 block17_14_conv[0][0]
__________________________________________________________________________________________________
block17_14_ac (Activation)      (None, 12, 12, 1088) 0           block17_14[0][0]
__________________________________________________________________________________________________
conv2d_348 (Conv2D)             (None, 12, 12, 128)  139264      block17_14_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_348 (BatchN (None, 12, 12, 128)  384         conv2d_348[0][0]
__________________________________________________________________________________________________
activation_336 (Activation)     (None, 12, 12, 128)  0           batch_normalization_348[0][0]
__________________________________________________________________________________________________
conv2d_349 (Conv2D)             (None, 12, 12, 160)  143360      activation_336[0][0]
__________________________________________________________________________________________________
batch_normalization_349 (BatchN (None, 12, 12, 160)  480         conv2d_349[0][0]
__________________________________________________________________________________________________
activation_337 (Activation)     (None, 12, 12, 160)  0           batch_normalization_349[0][0]
__________________________________________________________________________________________________
conv2d_347 (Conv2D)             (None, 12, 12, 192)  208896      block17_14_ac[0][0]
__________________________________________________________________________________________________
conv2d_350 (Conv2D)             (None, 12, 12, 192)  215040      activation_337[0][0]
__________________________________________________________________________________________________
batch_normalization_347 (BatchN (None, 12, 12, 192)  576         conv2d_347[0][0]
__________________________________________________________________________________________________
batch_normalization_350 (BatchN (None, 12, 12, 192)  576         conv2d_350[0][0]
__________________________________________________________________________________________________
activation_335 (Activation)     (None, 12, 12, 192)  0           batch_normalization_347[0][0]
__________________________________________________________________________________________________
activation_338 (Activation)     (None, 12, 12, 192)  0           batch_normalization_350[0][0]
__________________________________________________________________________________________________
block17_15_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_335[0][0]
                                                                 activation_338[0][0]
__________________________________________________________________________________________________
block17_15_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_15_mixed[0][0]
__________________________________________________________________________________________________
block17_15 (Lambda)             (None, 12, 12, 1088) 0           block17_14_ac[0][0]
                                                                 block17_15_conv[0][0]
__________________________________________________________________________________________________
block17_15_ac (Activation)      (None, 12, 12, 1088) 0           block17_15[0][0]
__________________________________________________________________________________________________
conv2d_352 (Conv2D)             (None, 12, 12, 128)  139264      block17_15_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_352 (BatchN (None, 12, 12, 128)  384         conv2d_352[0][0]
__________________________________________________________________________________________________
activation_340 (Activation)     (None, 12, 12, 128)  0           batch_normalization_352[0][0]
__________________________________________________________________________________________________
conv2d_353 (Conv2D)             (None, 12, 12, 160)  143360      activation_340[0][0]
__________________________________________________________________________________________________
batch_normalization_353 (BatchN (None, 12, 12, 160)  480         conv2d_353[0][0]
__________________________________________________________________________________________________
activation_341 (Activation)     (None, 12, 12, 160)  0           batch_normalization_353[0][0]
__________________________________________________________________________________________________
conv2d_351 (Conv2D)             (None, 12, 12, 192)  208896      block17_15_ac[0][0]
__________________________________________________________________________________________________
conv2d_354 (Conv2D)             (None, 12, 12, 192)  215040      activation_341[0][0]
__________________________________________________________________________________________________
batch_normalization_351 (BatchN (None, 12, 12, 192)  576         conv2d_351[0][0]
__________________________________________________________________________________________________
batch_normalization_354 (BatchN (None, 12, 12, 192)  576         conv2d_354[0][0]
__________________________________________________________________________________________________
activation_339 (Activation)     (None, 12, 12, 192)  0           batch_normalization_351[0][0]
__________________________________________________________________________________________________
activation_342 (Activation)     (None, 12, 12, 192)  0           batch_normalization_354[0][0]
__________________________________________________________________________________________________
block17_16_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_339[0][0]
                                                                 activation_342[0][0]
__________________________________________________________________________________________________
block17_16_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_16_mixed[0][0]
__________________________________________________________________________________________________
block17_16 (Lambda)             (None, 12, 12, 1088) 0           block17_15_ac[0][0]
                                                                 block17_16_conv[0][0]
__________________________________________________________________________________________________
block17_16_ac (Activation)      (None, 12, 12, 1088) 0           block17_16[0][0]
__________________________________________________________________________________________________
conv2d_356 (Conv2D)             (None, 12, 12, 128)  139264      block17_16_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_356 (BatchN (None, 12, 12, 128)  384         conv2d_356[0][0]
__________________________________________________________________________________________________
activation_344 (Activation)     (None, 12, 12, 128)  0           batch_normalization_356[0][0]
__________________________________________________________________________________________________
conv2d_357 (Conv2D)             (None, 12, 12, 160)  143360      activation_344[0][0]
__________________________________________________________________________________________________
batch_normalization_357 (BatchN (None, 12, 12, 160)  480         conv2d_357[0][0]
__________________________________________________________________________________________________
activation_345 (Activation)     (None, 12, 12, 160)  0           batch_normalization_357[0][0]
__________________________________________________________________________________________________
conv2d_355 (Conv2D)             (None, 12, 12, 192)  208896      block17_16_ac[0][0]
__________________________________________________________________________________________________
conv2d_358 (Conv2D)             (None, 12, 12, 192)  215040      activation_345[0][0]
__________________________________________________________________________________________________
batch_normalization_355 (BatchN (None, 12, 12, 192)  576         conv2d_355[0][0]
__________________________________________________________________________________________________
batch_normalization_358 (BatchN (None, 12, 12, 192)  576         conv2d_358[0][0]
__________________________________________________________________________________________________
activation_343 (Activation)     (None, 12, 12, 192)  0           batch_normalization_355[0][0]
__________________________________________________________________________________________________
activation_346 (Activation)     (None, 12, 12, 192)  0           batch_normalization_358[0][0]
__________________________________________________________________________________________________
block17_17_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_343[0][0]
                                                                 activation_346[0][0]
__________________________________________________________________________________________________
block17_17_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_17_mixed[0][0]
__________________________________________________________________________________________________
block17_17 (Lambda)             (None, 12, 12, 1088) 0           block17_16_ac[0][0]
                                                                 block17_17_conv[0][0]
__________________________________________________________________________________________________
block17_17_ac (Activation)      (None, 12, 12, 1088) 0           block17_17[0][0]
__________________________________________________________________________________________________
conv2d_360 (Conv2D)             (None, 12, 12, 128)  139264      block17_17_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_360 (BatchN (None, 12, 12, 128)  384         conv2d_360[0][0]
__________________________________________________________________________________________________
activation_348 (Activation)     (None, 12, 12, 128)  0           batch_normalization_360[0][0]
__________________________________________________________________________________________________
conv2d_361 (Conv2D)             (None, 12, 12, 160)  143360      activation_348[0][0]
__________________________________________________________________________________________________
batch_normalization_361 (BatchN (None, 12, 12, 160)  480         conv2d_361[0][0]
__________________________________________________________________________________________________
activation_349 (Activation)     (None, 12, 12, 160)  0           batch_normalization_361[0][0]
__________________________________________________________________________________________________
conv2d_359 (Conv2D)             (None, 12, 12, 192)  208896      block17_17_ac[0][0]
__________________________________________________________________________________________________
conv2d_362 (Conv2D)             (None, 12, 12, 192)  215040      activation_349[0][0]
__________________________________________________________________________________________________
batch_normalization_359 (BatchN (None, 12, 12, 192)  576         conv2d_359[0][0]
__________________________________________________________________________________________________
batch_normalization_362 (BatchN (None, 12, 12, 192)  576         conv2d_362[0][0]
__________________________________________________________________________________________________
activation_347 (Activation)     (None, 12, 12, 192)  0           batch_normalization_359[0][0]
__________________________________________________________________________________________________
activation_350 (Activation)     (None, 12, 12, 192)  0           batch_normalization_362[0][0]
__________________________________________________________________________________________________
block17_18_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_347[0][0]
                                                                 activation_350[0][0]
__________________________________________________________________________________________________
block17_18_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_18_mixed[0][0]
__________________________________________________________________________________________________
block17_18 (Lambda)             (None, 12, 12, 1088) 0           block17_17_ac[0][0]
                                                                 block17_18_conv[0][0]
__________________________________________________________________________________________________
block17_18_ac (Activation)      (None, 12, 12, 1088) 0           block17_18[0][0]
__________________________________________________________________________________________________
conv2d_364 (Conv2D)             (None, 12, 12, 128)  139264      block17_18_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_364 (BatchN (None, 12, 12, 128)  384         conv2d_364[0][0]
__________________________________________________________________________________________________
activation_352 (Activation)     (None, 12, 12, 128)  0           batch_normalization_364[0][0]
__________________________________________________________________________________________________
conv2d_365 (Conv2D)             (None, 12, 12, 160)  143360      activation_352[0][0]
__________________________________________________________________________________________________
batch_normalization_365 (BatchN (None, 12, 12, 160)  480         conv2d_365[0][0]
__________________________________________________________________________________________________
activation_353 (Activation)     (None, 12, 12, 160)  0           batch_normalization_365[0][0]
__________________________________________________________________________________________________
conv2d_363 (Conv2D)             (None, 12, 12, 192)  208896      block17_18_ac[0][0]
__________________________________________________________________________________________________
conv2d_366 (Conv2D)             (None, 12, 12, 192)  215040      activation_353[0][0]
__________________________________________________________________________________________________
batch_normalization_363 (BatchN (None, 12, 12, 192)  576         conv2d_363[0][0]
__________________________________________________________________________________________________
batch_normalization_366 (BatchN (None, 12, 12, 192)  576         conv2d_366[0][0]
__________________________________________________________________________________________________
activation_351 (Activation)     (None, 12, 12, 192)  0           batch_normalization_363[0][0]
__________________________________________________________________________________________________
activation_354 (Activation)     (None, 12, 12, 192)  0           batch_normalization_366[0][0]
__________________________________________________________________________________________________
block17_19_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_351[0][0]
                                                                 activation_354[0][0]
__________________________________________________________________________________________________
block17_19_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_19_mixed[0][0]
__________________________________________________________________________________________________
block17_19 (Lambda)             (None, 12, 12, 1088) 0           block17_18_ac[0][0]
                                                                 block17_19_conv[0][0]
__________________________________________________________________________________________________
block17_19_ac (Activation)      (None, 12, 12, 1088) 0           block17_19[0][0]
__________________________________________________________________________________________________
conv2d_368 (Conv2D)             (None, 12, 12, 128)  139264      block17_19_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_368 (BatchN (None, 12, 12, 128)  384         conv2d_368[0][0]
__________________________________________________________________________________________________
activation_356 (Activation)     (None, 12, 12, 128)  0           batch_normalization_368[0][0]
__________________________________________________________________________________________________
conv2d_369 (Conv2D)             (None, 12, 12, 160)  143360      activation_356[0][0]
__________________________________________________________________________________________________
batch_normalization_369 (BatchN (None, 12, 12, 160)  480         conv2d_369[0][0]
__________________________________________________________________________________________________
activation_357 (Activation)     (None, 12, 12, 160)  0           batch_normalization_369[0][0]
__________________________________________________________________________________________________
conv2d_367 (Conv2D)             (None, 12, 12, 192)  208896      block17_19_ac[0][0]
__________________________________________________________________________________________________
conv2d_370 (Conv2D)             (None, 12, 12, 192)  215040      activation_357[0][0]
__________________________________________________________________________________________________
batch_normalization_367 (BatchN (None, 12, 12, 192)  576         conv2d_367[0][0]
__________________________________________________________________________________________________
batch_normalization_370 (BatchN (None, 12, 12, 192)  576         conv2d_370[0][0]
__________________________________________________________________________________________________
activation_355 (Activation)     (None, 12, 12, 192)  0           batch_normalization_367[0][0]
__________________________________________________________________________________________________
activation_358 (Activation)     (None, 12, 12, 192)  0           batch_normalization_370[0][0]
__________________________________________________________________________________________________
block17_20_mixed (Concatenate)  (None, 12, 12, 384)  0           activation_355[0][0]
                                                                 activation_358[0][0]
__________________________________________________________________________________________________
block17_20_conv (Conv2D)        (None, 12, 12, 1088) 418880      block17_20_mixed[0][0]
__________________________________________________________________________________________________
block17_20 (Lambda)             (None, 12, 12, 1088) 0           block17_19_ac[0][0]
                                                                 block17_20_conv[0][0]
__________________________________________________________________________________________________
block17_20_ac (Activation)      (None, 12, 12, 1088) 0           block17_20[0][0]
__________________________________________________________________________________________________
conv2d_375 (Conv2D)             (None, 12, 12, 256)  278528      block17_20_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_375 (BatchN (None, 12, 12, 256)  768         conv2d_375[0][0]
__________________________________________________________________________________________________
activation_363 (Activation)     (None, 12, 12, 256)  0           batch_normalization_375[0][0]
__________________________________________________________________________________________________
conv2d_371 (Conv2D)             (None, 12, 12, 256)  278528      block17_20_ac[0][0]
__________________________________________________________________________________________________
conv2d_373 (Conv2D)             (None, 12, 12, 256)  278528      block17_20_ac[0][0]
__________________________________________________________________________________________________
conv2d_376 (Conv2D)             (None, 12, 12, 288)  663552      activation_363[0][0]
__________________________________________________________________________________________________
batch_normalization_371 (BatchN (None, 12, 12, 256)  768         conv2d_371[0][0]
__________________________________________________________________________________________________
batch_normalization_373 (BatchN (None, 12, 12, 256)  768         conv2d_373[0][0]
__________________________________________________________________________________________________
batch_normalization_376 (BatchN (None, 12, 12, 288)  864         conv2d_376[0][0]
__________________________________________________________________________________________________
activation_359 (Activation)     (None, 12, 12, 256)  0           batch_normalization_371[0][0]
__________________________________________________________________________________________________
activation_361 (Activation)     (None, 12, 12, 256)  0           batch_normalization_373[0][0]
__________________________________________________________________________________________________
activation_364 (Activation)     (None, 12, 12, 288)  0           batch_normalization_376[0][0]
__________________________________________________________________________________________________
conv2d_372 (Conv2D)             (None, 5, 5, 384)    884736      activation_359[0][0]
__________________________________________________________________________________________________
conv2d_374 (Conv2D)             (None, 5, 5, 288)    663552      activation_361[0][0]
__________________________________________________________________________________________________
conv2d_377 (Conv2D)             (None, 5, 5, 320)    829440      activation_364[0][0]
__________________________________________________________________________________________________
batch_normalization_372 (BatchN (None, 5, 5, 384)    1152        conv2d_372[0][0]
__________________________________________________________________________________________________
batch_normalization_374 (BatchN (None, 5, 5, 288)    864         conv2d_374[0][0]
__________________________________________________________________________________________________
batch_normalization_377 (BatchN (None, 5, 5, 320)    960         conv2d_377[0][0]
__________________________________________________________________________________________________
activation_360 (Activation)     (None, 5, 5, 384)    0           batch_normalization_372[0][0]
__________________________________________________________________________________________________
activation_362 (Activation)     (None, 5, 5, 288)    0           batch_normalization_374[0][0]
__________________________________________________________________________________________________
activation_365 (Activation)     (None, 5, 5, 320)    0           batch_normalization_377[0][0]
__________________________________________________________________________________________________
max_pooling2d_7 (MaxPooling2D)  (None, 5, 5, 1088)   0           block17_20_ac[0][0]
__________________________________________________________________________________________________
mixed_7a (Concatenate)          (None, 5, 5, 2080)   0           activation_360[0][0]
                                                                 activation_362[0][0]
                                                                 activation_365[0][0]
                                                                 max_pooling2d_7[0][0]
__________________________________________________________________________________________________
conv2d_379 (Conv2D)             (None, 5, 5, 192)    399360      mixed_7a[0][0]
__________________________________________________________________________________________________
batch_normalization_379 (BatchN (None, 5, 5, 192)    576         conv2d_379[0][0]
__________________________________________________________________________________________________
activation_367 (Activation)     (None, 5, 5, 192)    0           batch_normalization_379[0][0]
__________________________________________________________________________________________________
conv2d_380 (Conv2D)             (None, 5, 5, 224)    129024      activation_367[0][0]
__________________________________________________________________________________________________
batch_normalization_380 (BatchN (None, 5, 5, 224)    672         conv2d_380[0][0]
__________________________________________________________________________________________________
activation_368 (Activation)     (None, 5, 5, 224)    0           batch_normalization_380[0][0]
__________________________________________________________________________________________________
conv2d_378 (Conv2D)             (None, 5, 5, 192)    399360      mixed_7a[0][0]
__________________________________________________________________________________________________
conv2d_381 (Conv2D)             (None, 5, 5, 256)    172032      activation_368[0][0]
__________________________________________________________________________________________________
batch_normalization_378 (BatchN (None, 5, 5, 192)    576         conv2d_378[0][0]
__________________________________________________________________________________________________
batch_normalization_381 (BatchN (None, 5, 5, 256)    768         conv2d_381[0][0]
__________________________________________________________________________________________________
activation_366 (Activation)     (None, 5, 5, 192)    0           batch_normalization_378[0][0]
__________________________________________________________________________________________________
activation_369 (Activation)     (None, 5, 5, 256)    0           batch_normalization_381[0][0]
__________________________________________________________________________________________________
block8_1_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_366[0][0]
                                                                 activation_369[0][0]
__________________________________________________________________________________________________
block8_1_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_1_mixed[0][0]
__________________________________________________________________________________________________
block8_1 (Lambda)               (None, 5, 5, 2080)   0           mixed_7a[0][0]
                                                                 block8_1_conv[0][0]
__________________________________________________________________________________________________
block8_1_ac (Activation)        (None, 5, 5, 2080)   0           block8_1[0][0]
__________________________________________________________________________________________________
conv2d_383 (Conv2D)             (None, 5, 5, 192)    399360      block8_1_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_383 (BatchN (None, 5, 5, 192)    576         conv2d_383[0][0]
__________________________________________________________________________________________________
activation_371 (Activation)     (None, 5, 5, 192)    0           batch_normalization_383[0][0]
__________________________________________________________________________________________________
conv2d_384 (Conv2D)             (None, 5, 5, 224)    129024      activation_371[0][0]
__________________________________________________________________________________________________
batch_normalization_384 (BatchN (None, 5, 5, 224)    672         conv2d_384[0][0]
__________________________________________________________________________________________________
activation_372 (Activation)     (None, 5, 5, 224)    0           batch_normalization_384[0][0]
__________________________________________________________________________________________________
conv2d_382 (Conv2D)             (None, 5, 5, 192)    399360      block8_1_ac[0][0]
__________________________________________________________________________________________________
conv2d_385 (Conv2D)             (None, 5, 5, 256)    172032      activation_372[0][0]
__________________________________________________________________________________________________
batch_normalization_382 (BatchN (None, 5, 5, 192)    576         conv2d_382[0][0]
__________________________________________________________________________________________________
batch_normalization_385 (BatchN (None, 5, 5, 256)    768         conv2d_385[0][0]
__________________________________________________________________________________________________
activation_370 (Activation)     (None, 5, 5, 192)    0           batch_normalization_382[0][0]
__________________________________________________________________________________________________
activation_373 (Activation)     (None, 5, 5, 256)    0           batch_normalization_385[0][0]
__________________________________________________________________________________________________
block8_2_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_370[0][0]
                                                                 activation_373[0][0]
__________________________________________________________________________________________________
block8_2_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_2_mixed[0][0]
__________________________________________________________________________________________________
block8_2 (Lambda)               (None, 5, 5, 2080)   0           block8_1_ac[0][0]
                                                                 block8_2_conv[0][0]
__________________________________________________________________________________________________
block8_2_ac (Activation)        (None, 5, 5, 2080)   0           block8_2[0][0]
__________________________________________________________________________________________________
conv2d_387 (Conv2D)             (None, 5, 5, 192)    399360      block8_2_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_387 (BatchN (None, 5, 5, 192)    576         conv2d_387[0][0]
__________________________________________________________________________________________________
activation_375 (Activation)     (None, 5, 5, 192)    0           batch_normalization_387[0][0]
__________________________________________________________________________________________________
conv2d_388 (Conv2D)             (None, 5, 5, 224)    129024      activation_375[0][0]
__________________________________________________________________________________________________
batch_normalization_388 (BatchN (None, 5, 5, 224)    672         conv2d_388[0][0]
__________________________________________________________________________________________________
activation_376 (Activation)     (None, 5, 5, 224)    0           batch_normalization_388[0][0]
__________________________________________________________________________________________________
conv2d_386 (Conv2D)             (None, 5, 5, 192)    399360      block8_2_ac[0][0]
__________________________________________________________________________________________________
conv2d_389 (Conv2D)             (None, 5, 5, 256)    172032      activation_376[0][0]
__________________________________________________________________________________________________
batch_normalization_386 (BatchN (None, 5, 5, 192)    576         conv2d_386[0][0]
__________________________________________________________________________________________________
batch_normalization_389 (BatchN (None, 5, 5, 256)    768         conv2d_389[0][0]
__________________________________________________________________________________________________
activation_374 (Activation)     (None, 5, 5, 192)    0           batch_normalization_386[0][0]
__________________________________________________________________________________________________
activation_377 (Activation)     (None, 5, 5, 256)    0           batch_normalization_389[0][0]
__________________________________________________________________________________________________
block8_3_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_374[0][0]
                                                                 activation_377[0][0]
__________________________________________________________________________________________________
block8_3_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_3_mixed[0][0]
__________________________________________________________________________________________________
block8_3 (Lambda)               (None, 5, 5, 2080)   0           block8_2_ac[0][0]
                                                                 block8_3_conv[0][0]
__________________________________________________________________________________________________
block8_3_ac (Activation)        (None, 5, 5, 2080)   0           block8_3[0][0]
__________________________________________________________________________________________________
conv2d_391 (Conv2D)             (None, 5, 5, 192)    399360      block8_3_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_391 (BatchN (None, 5, 5, 192)    576         conv2d_391[0][0]
__________________________________________________________________________________________________
activation_379 (Activation)     (None, 5, 5, 192)    0           batch_normalization_391[0][0]
__________________________________________________________________________________________________
conv2d_392 (Conv2D)             (None, 5, 5, 224)    129024      activation_379[0][0]
__________________________________________________________________________________________________
batch_normalization_392 (BatchN (None, 5, 5, 224)    672         conv2d_392[0][0]
__________________________________________________________________________________________________
activation_380 (Activation)     (None, 5, 5, 224)    0           batch_normalization_392[0][0]
__________________________________________________________________________________________________
conv2d_390 (Conv2D)             (None, 5, 5, 192)    399360      block8_3_ac[0][0]
__________________________________________________________________________________________________
conv2d_393 (Conv2D)             (None, 5, 5, 256)    172032      activation_380[0][0]
__________________________________________________________________________________________________
batch_normalization_390 (BatchN (None, 5, 5, 192)    576         conv2d_390[0][0]
__________________________________________________________________________________________________
batch_normalization_393 (BatchN (None, 5, 5, 256)    768         conv2d_393[0][0]
__________________________________________________________________________________________________
activation_378 (Activation)     (None, 5, 5, 192)    0           batch_normalization_390[0][0]
__________________________________________________________________________________________________
activation_381 (Activation)     (None, 5, 5, 256)    0           batch_normalization_393[0][0]
__________________________________________________________________________________________________
block8_4_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_378[0][0]
                                                                 activation_381[0][0]
__________________________________________________________________________________________________
block8_4_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_4_mixed[0][0]
__________________________________________________________________________________________________
block8_4 (Lambda)               (None, 5, 5, 2080)   0           block8_3_ac[0][0]
                                                                 block8_4_conv[0][0]
__________________________________________________________________________________________________
block8_4_ac (Activation)        (None, 5, 5, 2080)   0           block8_4[0][0]
__________________________________________________________________________________________________
conv2d_395 (Conv2D)             (None, 5, 5, 192)    399360      block8_4_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_395 (BatchN (None, 5, 5, 192)    576         conv2d_395[0][0]
__________________________________________________________________________________________________
activation_383 (Activation)     (None, 5, 5, 192)    0           batch_normalization_395[0][0]
__________________________________________________________________________________________________
conv2d_396 (Conv2D)             (None, 5, 5, 224)    129024      activation_383[0][0]
__________________________________________________________________________________________________
batch_normalization_396 (BatchN (None, 5, 5, 224)    672         conv2d_396[0][0]
__________________________________________________________________________________________________
activation_384 (Activation)     (None, 5, 5, 224)    0           batch_normalization_396[0][0]
__________________________________________________________________________________________________
conv2d_394 (Conv2D)             (None, 5, 5, 192)    399360      block8_4_ac[0][0]
__________________________________________________________________________________________________
conv2d_397 (Conv2D)             (None, 5, 5, 256)    172032      activation_384[0][0]
__________________________________________________________________________________________________
batch_normalization_394 (BatchN (None, 5, 5, 192)    576         conv2d_394[0][0]
__________________________________________________________________________________________________
batch_normalization_397 (BatchN (None, 5, 5, 256)    768         conv2d_397[0][0]
__________________________________________________________________________________________________
activation_382 (Activation)     (None, 5, 5, 192)    0           batch_normalization_394[0][0]
__________________________________________________________________________________________________
activation_385 (Activation)     (None, 5, 5, 256)    0           batch_normalization_397[0][0]
__________________________________________________________________________________________________
block8_5_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_382[0][0]
                                                                 activation_385[0][0]
__________________________________________________________________________________________________
block8_5_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_5_mixed[0][0]
__________________________________________________________________________________________________
block8_5 (Lambda)               (None, 5, 5, 2080)   0           block8_4_ac[0][0]
                                                                 block8_5_conv[0][0]
__________________________________________________________________________________________________
block8_5_ac (Activation)        (None, 5, 5, 2080)   0           block8_5[0][0]
__________________________________________________________________________________________________
conv2d_399 (Conv2D)             (None, 5, 5, 192)    399360      block8_5_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_399 (BatchN (None, 5, 5, 192)    576         conv2d_399[0][0]
__________________________________________________________________________________________________
activation_387 (Activation)     (None, 5, 5, 192)    0           batch_normalization_399[0][0]
__________________________________________________________________________________________________
conv2d_400 (Conv2D)             (None, 5, 5, 224)    129024      activation_387[0][0]
__________________________________________________________________________________________________
batch_normalization_400 (BatchN (None, 5, 5, 224)    672         conv2d_400[0][0]
__________________________________________________________________________________________________
activation_388 (Activation)     (None, 5, 5, 224)    0           batch_normalization_400[0][0]
__________________________________________________________________________________________________
conv2d_398 (Conv2D)             (None, 5, 5, 192)    399360      block8_5_ac[0][0]
__________________________________________________________________________________________________
conv2d_401 (Conv2D)             (None, 5, 5, 256)    172032      activation_388[0][0]
__________________________________________________________________________________________________
batch_normalization_398 (BatchN (None, 5, 5, 192)    576         conv2d_398[0][0]
__________________________________________________________________________________________________
batch_normalization_401 (BatchN (None, 5, 5, 256)    768         conv2d_401[0][0]
__________________________________________________________________________________________________
activation_386 (Activation)     (None, 5, 5, 192)    0           batch_normalization_398[0][0]
__________________________________________________________________________________________________
activation_389 (Activation)     (None, 5, 5, 256)    0           batch_normalization_401[0][0]
__________________________________________________________________________________________________
block8_6_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_386[0][0]
                                                                 activation_389[0][0]
__________________________________________________________________________________________________
block8_6_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_6_mixed[0][0]
__________________________________________________________________________________________________
block8_6 (Lambda)               (None, 5, 5, 2080)   0           block8_5_ac[0][0]
                                                                 block8_6_conv[0][0]
__________________________________________________________________________________________________
block8_6_ac (Activation)        (None, 5, 5, 2080)   0           block8_6[0][0]
__________________________________________________________________________________________________
conv2d_403 (Conv2D)             (None, 5, 5, 192)    399360      block8_6_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_403 (BatchN (None, 5, 5, 192)    576         conv2d_403[0][0]
__________________________________________________________________________________________________
activation_391 (Activation)     (None, 5, 5, 192)    0           batch_normalization_403[0][0]
__________________________________________________________________________________________________
conv2d_404 (Conv2D)             (None, 5, 5, 224)    129024      activation_391[0][0]
__________________________________________________________________________________________________
batch_normalization_404 (BatchN (None, 5, 5, 224)    672         conv2d_404[0][0]
__________________________________________________________________________________________________
activation_392 (Activation)     (None, 5, 5, 224)    0           batch_normalization_404[0][0]
__________________________________________________________________________________________________
conv2d_402 (Conv2D)             (None, 5, 5, 192)    399360      block8_6_ac[0][0]
__________________________________________________________________________________________________
conv2d_405 (Conv2D)             (None, 5, 5, 256)    172032      activation_392[0][0]
__________________________________________________________________________________________________
batch_normalization_402 (BatchN (None, 5, 5, 192)    576         conv2d_402[0][0]
__________________________________________________________________________________________________
batch_normalization_405 (BatchN (None, 5, 5, 256)    768         conv2d_405[0][0]
__________________________________________________________________________________________________
activation_390 (Activation)     (None, 5, 5, 192)    0           batch_normalization_402[0][0]
__________________________________________________________________________________________________
activation_393 (Activation)     (None, 5, 5, 256)    0           batch_normalization_405[0][0]
__________________________________________________________________________________________________
block8_7_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_390[0][0]
                                                                 activation_393[0][0]
__________________________________________________________________________________________________
block8_7_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_7_mixed[0][0]
__________________________________________________________________________________________________
block8_7 (Lambda)               (None, 5, 5, 2080)   0           block8_6_ac[0][0]
                                                                 block8_7_conv[0][0]
__________________________________________________________________________________________________
block8_7_ac (Activation)        (None, 5, 5, 2080)   0           block8_7[0][0]
__________________________________________________________________________________________________
conv2d_407 (Conv2D)             (None, 5, 5, 192)    399360      block8_7_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_407 (BatchN (None, 5, 5, 192)    576         conv2d_407[0][0]
__________________________________________________________________________________________________
activation_395 (Activation)     (None, 5, 5, 192)    0           batch_normalization_407[0][0]
__________________________________________________________________________________________________
conv2d_408 (Conv2D)             (None, 5, 5, 224)    129024      activation_395[0][0]
__________________________________________________________________________________________________
batch_normalization_408 (BatchN (None, 5, 5, 224)    672         conv2d_408[0][0]
__________________________________________________________________________________________________
activation_396 (Activation)     (None, 5, 5, 224)    0           batch_normalization_408[0][0]
__________________________________________________________________________________________________
conv2d_406 (Conv2D)             (None, 5, 5, 192)    399360      block8_7_ac[0][0]
__________________________________________________________________________________________________
conv2d_409 (Conv2D)             (None, 5, 5, 256)    172032      activation_396[0][0]
__________________________________________________________________________________________________
batch_normalization_406 (BatchN (None, 5, 5, 192)    576         conv2d_406[0][0]
__________________________________________________________________________________________________
batch_normalization_409 (BatchN (None, 5, 5, 256)    768         conv2d_409[0][0]
__________________________________________________________________________________________________
activation_394 (Activation)     (None, 5, 5, 192)    0           batch_normalization_406[0][0]
__________________________________________________________________________________________________
activation_397 (Activation)     (None, 5, 5, 256)    0           batch_normalization_409[0][0]
__________________________________________________________________________________________________
block8_8_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_394[0][0]
                                                                 activation_397[0][0]
__________________________________________________________________________________________________
block8_8_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_8_mixed[0][0]
__________________________________________________________________________________________________
block8_8 (Lambda)               (None, 5, 5, 2080)   0           block8_7_ac[0][0]
                                                                 block8_8_conv[0][0]
__________________________________________________________________________________________________
block8_8_ac (Activation)        (None, 5, 5, 2080)   0           block8_8[0][0]
__________________________________________________________________________________________________
conv2d_411 (Conv2D)             (None, 5, 5, 192)    399360      block8_8_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_411 (BatchN (None, 5, 5, 192)    576         conv2d_411[0][0]
__________________________________________________________________________________________________
activation_399 (Activation)     (None, 5, 5, 192)    0           batch_normalization_411[0][0]
__________________________________________________________________________________________________
conv2d_412 (Conv2D)             (None, 5, 5, 224)    129024      activation_399[0][0]
__________________________________________________________________________________________________
batch_normalization_412 (BatchN (None, 5, 5, 224)    672         conv2d_412[0][0]
__________________________________________________________________________________________________
activation_400 (Activation)     (None, 5, 5, 224)    0           batch_normalization_412[0][0]
__________________________________________________________________________________________________
conv2d_410 (Conv2D)             (None, 5, 5, 192)    399360      block8_8_ac[0][0]
__________________________________________________________________________________________________
conv2d_413 (Conv2D)             (None, 5, 5, 256)    172032      activation_400[0][0]
__________________________________________________________________________________________________
batch_normalization_410 (BatchN (None, 5, 5, 192)    576         conv2d_410[0][0]
__________________________________________________________________________________________________
batch_normalization_413 (BatchN (None, 5, 5, 256)    768         conv2d_413[0][0]
__________________________________________________________________________________________________
activation_398 (Activation)     (None, 5, 5, 192)    0           batch_normalization_410[0][0]
__________________________________________________________________________________________________
activation_401 (Activation)     (None, 5, 5, 256)    0           batch_normalization_413[0][0]
__________________________________________________________________________________________________
block8_9_mixed (Concatenate)    (None, 5, 5, 448)    0           activation_398[0][0]
                                                                 activation_401[0][0]
__________________________________________________________________________________________________
block8_9_conv (Conv2D)          (None, 5, 5, 2080)   933920      block8_9_mixed[0][0]
__________________________________________________________________________________________________
block8_9 (Lambda)               (None, 5, 5, 2080)   0           block8_8_ac[0][0]
                                                                 block8_9_conv[0][0]
__________________________________________________________________________________________________
block8_9_ac (Activation)        (None, 5, 5, 2080)   0           block8_9[0][0]
__________________________________________________________________________________________________
conv2d_415 (Conv2D)             (None, 5, 5, 192)    399360      block8_9_ac[0][0]
__________________________________________________________________________________________________
batch_normalization_415 (BatchN (None, 5, 5, 192)    576         conv2d_415[0][0]
__________________________________________________________________________________________________
activation_403 (Activation)     (None, 5, 5, 192)    0           batch_normalization_415[0][0]
__________________________________________________________________________________________________
conv2d_416 (Conv2D)             (None, 5, 5, 224)    129024      activation_403[0][0]
__________________________________________________________________________________________________
batch_normalization_416 (BatchN (None, 5, 5, 224)    672         conv2d_416[0][0]
__________________________________________________________________________________________________
activation_404 (Activation)     (None, 5, 5, 224)    0           batch_normalization_416[0][0]
__________________________________________________________________________________________________
conv2d_414 (Conv2D)             (None, 5, 5, 192)    399360      block8_9_ac[0][0]
__________________________________________________________________________________________________
conv2d_417 (Conv2D)             (None, 5, 5, 256)    172032      activation_404[0][0]
__________________________________________________________________________________________________
batch_normalization_414 (BatchN (None, 5, 5, 192)    576         conv2d_414[0][0]
__________________________________________________________________________________________________
batch_normalization_417 (BatchN (None, 5, 5, 256)    768         conv2d_417[0][0]
__________________________________________________________________________________________________
activation_402 (Activation)     (None, 5, 5, 192)    0           batch_normalization_414[0][0]
__________________________________________________________________________________________________
activation_405 (Activation)     (None, 5, 5, 256)    0           batch_normalization_417[0][0]
__________________________________________________________________________________________________
block8_10_mixed (Concatenate)   (None, 5, 5, 448)    0           activation_402[0][0]
                                                                 activation_405[0][0]
__________________________________________________________________________________________________
block8_10_conv (Conv2D)         (None, 5, 5, 2080)   933920      block8_10_mixed[0][0]
__________________________________________________________________________________________________
block8_10 (Lambda)              (None, 5, 5, 2080)   0           block8_9_ac[0][0]
                                                                 block8_10_conv[0][0]
__________________________________________________________________________________________________
conv_7b (Conv2D)                (None, 5, 5, 1536)   3194880     block8_10[0][0]
__________________________________________________________________________________________________
conv_7b_bn (BatchNormalization) (None, 5, 5, 1536)   4608        conv_7b[0][0]
__________________________________________________________________________________________________
conv_7b_ac (Activation)         (None, 5, 5, 1536)   0           conv_7b_bn[0][0]
__________________________________________________________________________________________________
flatten (Flatten)               (None, 38400)        0           conv_7b_ac[0][0]
__________________________________________________________________________________________________
dropout_11 (Dropout)            (None, 38400)        0           flatten[0][0]
__________________________________________________________________________________________________
dense_11 (Dense)                (None, 5)            192005      dropout_11[0][0]
==================================================================================================
Total params: 54,528,741
Trainable params: 54,468,197
Non-trainable params: 60,544
__________________________________________________________________________________________________

Training and validating

history= model_inceptionNet.fit_generator(generator=train_generator,
                                     steps_per_epoch=1000,
                                     validation_data=valid_generator,
                                     validation_steps=1000,
                                     epochs=10)

Epoch 1/10
91/91 [==============================] - 3s 28ms/step - loss: 0.4890 - accuracy: 0.8415 - val_loss: 0.1080 - val_accuracy: 0.9747
Epoch 2/10
91/91 [==============================] - 2s 21ms/step - loss: 0.0869 - accuracy: 0.9806 - val_loss: 0.0376 - val_accuracy: 0.9898
Epoch 3/10
91/91 [==============================] - 2s 21ms/step - loss: 0.0451 - accuracy: 0.9884 - val_loss: 0.0267 - val_accuracy: 0.9898
Epoch 4/10
91/91 [==============================] - 2s 22ms/step - loss: 0.0312 - accuracy: 0.9896 - val_loss: 0.0226 - val_accuracy: 0.9929
Epoch 5/10
91/91 [==============================] - 2s 22ms/step - loss: 0.0279 - accuracy: 0.9925 - val_loss: 0.0189 - val_accuracy: 0.9947
Epoch 6/10
91/91 [==============================] - 2s 23ms/step - loss: 0.0177 - accuracy: 0.9955 - val_loss: 0.0144 - val_accuracy: 0.9965
Epoch 7/10
91/91 [==============================] - 2s 23ms/step - loss: 0.0142 - accuracy: 0.9965 - val_loss: 0.0119 - val_accuracy: 0.9973
Epoch 8/10
91/91 [==============================] - 3s 31ms/step - loss: 0.0130 - accuracy: 0.9972 - val_loss: 0.0154 - val_accuracy: 0.9973
Epoch 9/10
91/91 [==============================] - 2s 27ms/step - loss: 0.0094 - accuracy: 0.9974 - val_loss: 0.0110 - val_accuracy: 0.9965
Epoch 10/10
91/91 [==============================] - 2s 26ms/step - loss: 0.0088 - accuracy: 0.9980 - val_loss: 0.0085 - val_accuracy: 0.9982

Testing the Trained model with test data

accr = model_inceptionNet.evaluate(X_test,y_test)

151/151 [==============================] - 1s 5ms/step - loss: 0.0192 - accuracy: 0.9944

Accuracy

y_pred = model_inceptionNet.predict(X_test)
y_pred=y_pred.argmax(axis=1)
acc4=accr[1]
print('Test set\n  Accuracy: {:0.5f}'.format(accr[1]))

Test set
  Accuracy: 0.99441

Precision, Recall, F1

print('\n')
print("Precision, Recall, F1")
print('\n')
labels =['No DR', 'Moderate', 'Mild', 'Proliferative DR', 'Severe']
CR=classification_report(y_test, y_pred, target_names=labels)
print(CR)
print('\n')

Precision, Recall, F1


                  precision    recall  f1-score   support

           No DR       1.00      0.98      0.99       297
        Moderate       0.99      1.00      0.99       694
            Mild       1.00      0.99      0.99      1664
Proliferative DR       1.00      0.99      1.00       960
          Severe       0.99      1.00      1.00      1215

        accuracy                           0.99      4830
       macro avg       0.99      0.99      0.99      4830
    weighted avg       0.99      0.99      0.99      4830

Confusion matrix

CM=confusion_matrix(y_test, y_pred)
fig, ax = plot_confusion_matrix(conf_mat=CM,figsize=(10, 10),
                                show_absolute=True,
                                show_normed=True,
                                colorbar=False)
ax.set_xticklabels([''] + labels)
ax.set_yticklabels([''] + labels)
plt.show()

Accuracy Comparison of all models Results

x = PrettyTable()
print('\n')
print("Comparison of all models results")
x.field_names = ["Model", "Accuracy"]

x.add_row(["Resnet Model", round(acc1,5)])
x.add_row(["DenseNet Model", round(acc2,5)])
x.add_row(["Exception Model", round(acc3,5)])
x.add_row(["InceptionResNet Model", round(acc4,5)])
print(x)
print('\n')

Comparison of all models results
+-----------------------+----------+
|         Model         | Accuracy |
+-----------------------+----------+
|      Resnet Model     | 0.99669  |
|     DenseNet Model    | 0.99358  |
|    Exception Model    | 0.99627  |
| InceptionResNet Model | 0.99441  |
+-----------------------+----------+

There is no big difference in the results of all models but overall Resnet model results are higher than other pre-trained models.
